2. Front Exhaust Pipe

1) Remove battery.

2) Remove air cleaner case and air intake duct.

<Ref. to IN(H6)-5, REMOVAL, Air Cleaner.> and

<Ref. to IN(H6)-7, REMOVAL, Air Intake Duct.>

3) Disconnect front oxygen (A/F) sensor connec-

4) Lift-up the vehicle.

5) Remove under cover.

FRONT EXHAUST PIPE

6) Disconnect rear oxygen sensor connector.

7) Separate front exhaust pipe assembly from rear

exhaust pipe.

Be careful, exhaust pipe is hot.

8) Remove nuts which hold front exhaust pipe

onto cylinder heads.

Be careful not to pull down front exhaust pipe
