RM0430
Bit 4 RXFLVL: Rx FIFO non-empty
Indicates that there is at least one packet pending to be read from the Rx FIFO.
Note: Accessible in both host and device modes.
Bit 3 SOF: Start of frame
In host mode, the core sets this bit to indicate that an SOF (FS), or Keep-Alive (LS) is
transmitted on the USB. The application must write a 1 to this bit to clear the interrupt.
In device mode, in the core sets this bit to indicate that an SOF token has been received on
the USB. The application can read the OTG_DSTS register to get the current frame number.
This interrupt is seen only when the core is operating in FS.
Note: This register may return '1' if read immediately after power on reset. If the register bit
Note: Accessible in both host and device modes.
Bit 2 OTGINT: OTG interrupt
The core sets this bit to indicate an OTG protocol event. The application must read the OTG
Interrupt Status (OTG_GOTGINT) register to determine the exact event that caused this
interrupt. The application must clear the appropriate status bit in the OTG_GOTGINT
register to clear this bit.
Note: Accessible in both host and device modes.
Bit 1 MMIS: Mode mismatch interrupt
The core sets this bit when the application is trying to access:
– A host mode register, when the core is operating in device mode
– A device mode register, when the core is operating in host mode
The register access is completed on the AHB with an OKAY response, but is ignored by the
core internally and does not affect the operation of the core.
Note: Accessible in both host and device modes.
Bit 0 CMOD: Current mode of operation
Indicates the current mode.
0: Device mode
1: Host mode
Note: Accessible in both host and device modes.
33.15.7

OTG interrupt mask register (OTG_GINTMSK)

Address offset: 0x018
Reset value: 0x0000 0000
This register works with the Core interrupt register to interrupt the application. When an
interrupt bit is masked, the interrupt associated with that bit is not generated. However, the
Core Interrupt (OTG_GINTSTS) register bit corresponding to that interrupt is still set.
31 30 29
DISCIN CIDSC
WUIM SRQIM
T HGM
rw rw rw
reads '1' immediately after power on reset it does not indicate that an SOF has been
sent (in case of host mode) or SOF has been received (in case of device mode). The
read value of this interrupt is valid only after a valid connection between host and
device is established. If the bit is set after power on reset the application can clear the
bit.
28 27 26 25
LPMIN PTXFE
HCIM
TM M
rw
rw rw rw
DocID029473 Rev 3
USB on-the-go full-speed (OTG_FS)
24 23 22 21
IPXFR
RSTDE M/IISO
PRTIM Res.
TM OXFR
M
rw
r rw
20 19 18 17
IISOIX OEPIN
IEPINT Res.
FRM T
rw rw rw
16
Res.
1137/1284
