Controller area network (bxCAN)
CAN filter FIFO assignment register (CAN_FFA1R)
Address offset: 0x214
Reset value: 0x0000 0000
This register can be written only when the filter initialization mode is set (FINIT=1) in the
CAN_FMR register.
31 30 29
Res. Res. Res. Res.
15 14 13
FFA15 FFA14 FFA13 FFA12
rw rw rw
Bits 31:28 Reserved, must be kept at reset value.
Bits 27:0 FFAx
Note: Bits 27:14 are available for dual CAN peripheral configuration and are reserved for
CAN filter activation register (CAN_FA1R)
Address offset: 0x21C
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
FACT1 FACT1 FACT1 FACT1
5 4 3
rw rw rw
Bits 31:28 Reserved, must be kept at reset value.
Bits 27:0 FACTx
The software sets this bit to activate Filter x. To modify the Filter x registers (CAN_FxR[0:7]),
the FACTx bit must be cleared or the FINIT bit of the CAN_FMR register must be set.
0: Filter x is not active
1: Filter x is active
Note: Bits 27:14 are available for dual CAN peripheral configuration and are reserved for
