Parameter Descriptions
7-06 Speed PID Lowpass Filter Time
Range:
4
4
7-07 Speed PID Feedback Gear Ratio
Range:
1
[0.0001 - 32 ]
*
7-08 Speed PID Feed Forward Factor
Range:
0 %
[0 - 500 %] The reference signal bypasses the speed
*
66
Programming Guide
Function:
Feedback
Disturbed feedback signal
Lowpass lter
f
= 10 Hz
g
Feedback
Filtered feedback signal
Illustration 4.19 Feedback Signal
Function:
Motor
Par 7-07=1.00
Illustration 4.20 Speed PID Feedback Gear
Ratio
Function:
controller by the amount specified. This
feature increases the dynamic performance
of the speed control loop.
Danfoss A/S © Rev. 2014-03-31 All rights reserved.

4.8.2 7-1* Torque PI Control

Parameters for configuring the torque PI control in torque
open loop (1-00 Configuration Mode).
7-12 Torque PID Proportional Gain
Range:
100 %
*
7-13 Torque PID Integration Time
Range:
0.020 s
*
0.6
t (Sec.)

4.8.3 7-2* Process Ctrl. Feedb.

Select the feedback sources for the Process PID Control,
and how this feedback should be handled.
7-20 Process CL Feedback 1 Resource
Option:
0.6
t (Sec.)
[0]
No function
*
[1]
Analog Input 53
[2]
Analog Input 54
[3]
Frequency input
29
[4]
Frequency input
33
n1
n2
7-22 Process CL Feedback 2 Resource
Option:
Par 7-07=n1/n2
[0]
No function
*
[1]
Analog Input 53
[2]
Analog Input 54
[3]
Frequency input
29
Function:
[0 - 500 %] Enter the proportional gain value for the
torque controller. Selection of a high value
makes the contoller react faster. Too high
a setting leads to controller instability.
Function:
[0.002 - 2 s] Enter the integration time for the torque
controller. Selection os a low value make
the controller react faster. Too low a
setting leads to controller instability.
Function:
The effective feedback signal is made up
of the sum of up to 2 different input
signals. Select which input should be
treated as the source of the first of these
signals. The second input signal is
defined in parameter 7-22 Process CL
Feedback 2 Resource.
Function:
The effective feedback signal is made up
of the sum of up to 2 different input
signals. Select which input should be
treated as the source of the second of
these signals. The first input signal is
defined in parameter 7-20 Process CL
Feedback 1 Resource.
MG06C402
