D.16 Pchip AGP Error Register (AGPERROR )
The register is used for logging AGP errors.
If any of bits <6:4, 0> are set, then this entire register is frozen and the Pchip output signal
h_err is asserted. Only bit <0> can be set after that. All other values will be held until bits
<6:4> are clear. When an error is detected and one of bits <6:4> is set, the associated cache
block address and AGP bus command are captured in bits <63:16> of this register.
Table D–15 Pchip AGP Error Register
Field Bits
RES <63:60>
FENCE <59>
LENGTH <58:53>
CMD <52:50>
Type Init Description
MBZ 0 Reserved
RO 0 Fence bit, used only if command code
indicates LP transaction.
RO 0
AGJP transaction length in
quadwords
RO 0 AGP Command
Value
000
001
010
011
100,101 Reserved
110
111
Command
Read (low priority)
Read (high priority)
Write (low priority)
Write (high priority)
Flush
Fence
Continued on next page
Registers D-35
