8.4

Removing Covers from the System Chassis

The system chassis has three covers: the fan cover, the system card
cage cover, and the PCI card cage cover. Remove a cover by loosening
the quarter-turn captive screw, pulling up on the ring, and sliding the
cover from the system chassis.
WARNING: High current area. Currents exceeding
V @ >240VA
240 VA can cause burns or eye injury. Avoid con-
tact with parts or remove power prior to access.
WARNING: Contact with moving fan can cause se-
vere injury to fingers. Avoid contact or remove
power prior to access.
To Gain Access to the System Chassis
1. Open the front door of the cabinet.
2. Pull out the stabilizer bar
3. Extend the leveler foot
4. Snap out the front bezel
5. Remove and set aside the two screws
cure the system to the cabinet.
6. Pull the system out until it locks.
at the bottom of the cabinet until it stops.
at the end of the stabilizer bar to the floor.
.
(one per side), if present, that se-
