Installing a Drive
1. Access the storage drive area and remove the drive blank
available slot (Drives are installed left to right, SCSI ID 0 – 5).
2. Insert the new drive
lease lever in toward the drive.
3. Push the release lever
Replacing a Drive
1. Press the ejector button
tion.
2. Pull out on the drive until it is disconnected from the backplane connector.
CAUTION: Do not remove the drive while the disk is spinning.
3. When you are sure that the disk is no longer spinning, remove the drive
from the enclosure.
4. Insert the replacement drive in until it is against the backplane connector.
Continue to push it while pivoting the release lever
position.
5. Push the release lever in until it engages the ejector button
Observe the drive status LEDs to ensure that the new drive or replacement
drive is functioning properly.
The SRM console polls for SCSI devices every 30 seconds. If the device does not
appear to be working, access the SRM console and enter the show device
command to view a list of the bootable devices.
into the cage and push it in while pivoting the re-
in until it engages the ejector button
in and pivot the release lever
FRU Removal and Replacement
for the next
.
to the open posi-
to the full upright
.
8-27
