Feature Reference
At a Glance - Continued
System Programming
continued
Maximums
Programmable Routing
Tables
Entries for each table
Factory-set tables
Subpatterns
Routes
Absorbed digits
System-prefixed characters
Factory Settings
ARS dial-out code
FRL (routes assigned to
Default Toll table)
FRL (routes assigned to
Default Local table)
FRL (telephones)
FRL (Remote Access
barrier codes and
trunks)
Time to Start
System-prefixed
characters
Absorbed digits
1 + 7 dialing requirements
Data
64
Automatic Route Selection
Specify the pool routing, FRL, and digits or special
characters that must be added by the system to the number
dialed by the user when calls are routed on the Dial 0 table:
More
Specify whether a route is to be used for voice, data, or both
on a PRI call:
More
Allow or restrict remote access users (without barrier codes)
from using selected trunks:
Allow or restrict remote access users (with barrier codes)
from using selected trunks:
Assign or restrict extensions from using selected trunks:
16 (1–16)
100
4: Dial 0 (table 19), Special Numbers (N11, table 20), Default
Toll (table 17), Default Local (table 18)
2 for each programmable table
6 (1–6) for each subpattern
11 (0–11) for each route
20 (0–9,*, and Pause) for each route
9
3 (0–6; 0 least restrictive, 6 most restrictive)
2 (0–6; 0 least restrictive, 6 most restrictive)
3 (0–6; 0 most restrictive, 6 least restrictive)
0 (0–6; 0 most restrictive, 6 least restrictive)
00:00 (midnight, both Subpattern A and B)
None
0
Not within area code
Voice only
