AT&T MERLIN LEGEND Release 4.0 Feature Reference page 373

Feature Reference
Notify
See "Signal/Notify."
Paging
At a Glance
Users Affected
Reports Affected
Mode
Telephones
Programming Code
MLX Display Label
System Programming
Maximums
Groups
Telephones
Line Jacks
Factory Settings
Extensions
NOTE:
Each extension can belong to up to seven paging groups (for example, each of
the six speakerphone paging groups and the Page All group).
Description
Paging allows users to broadcast announcements using their telephones. There
are two types of paging: Speakerphone Paging and Loudspeaker Paging.
Speakerphone Paging allows broadcasting to specific individuals or designated
groups. Loudspeaker Paging allows broadcasting to specific groups or all
extensions, depending on whether or not the loudspeaker system is a multizone
paging system.
Telephone users, operators
Dial Plan Extension Information
Group Paging System Information
All
All
+ group or Page All ext. no.
[ ]
[ ]
Assign telephones to paging groups:
More
•
Designate a loop-start or ground-start/loop-start line jack as a
paging jack:
•
6 speakerphone paging groups
1 Page All group
10 in each paging group (see Note)
3, programmed as loudspeaker paging ports
793–798 (speakerphone paging groups)
799 (Page All group)
373
Notify
