AT&T MERLIN LEGEND Release 4.0 Feature Reference page 301

Feature Reference
The number of voice channels required for AUDIX Voice Power depends on the
number of incoming trunks, the number of subscribers programmed for the
system, and the number of busy-hour calls. Table 22 shows these requirements.
Table 22. Voice Channels Required
Channels Required
2
4
6
8
12
Installation Overview
The qualified technician uses Integrated Administration during installation. The
steps below describe basic tasks, not detailed procedures. (See the AUDIX
Voice Power or FAX Attendant System Manager's Guide for complete
instructions on programming the applications and System Programming for
complete instructions on programming the system.) Note that the sequence of
tasks differs, depending on the installation:
If the communications system and IS III are both being installed for the
first time, the technician must do some initial programming on the system,
as described in Step 1.
If IS III is being installed on an existing system, the technician skips
Step 1.
1. On installation of both the system and IS III , program the following basic
system operating conditions. SPM in surrogate mode is typically used for
this step, but the programming console can also be used.
2. Select
Maintenance menu, and, if necessary, change any of the values
displayed for the applications.
3. Select
menu. This step reads the system extension directory (including any
labels already programmed on the switch) into the application database.
Trunks
1 to 6
7 to 18
19 to 24
25 to 42
Over 42
Mode of operation (Hybrid/PBX or Key only for Integrated
Administration)
System renumbering
System operator positions
Phantom extensions
Assignment of trunks to pools
Subscribers Busy-Hour Calls
1 to 20
21 to 60
61 to 80
81 to 200
201 to 300
from the IS III Technician
from the Technician Maintenance
Integrated Administration
1 to 20
21 to 60
61 to 80
81 to 200
201 to 300
301
