Feature Reference
The display ordinarily shows the Home screen; at other times, users access the
Home, Menu, Feature, and Inspect screens by pressing the corresponding fixed
Home, Menu, Feature, or Inspct button.
The fixed More button is used to read screens that include too much information
to fit on the display all at once. The availability of more information is indicated
by the appearance of a
character on the right side of the screen. On the 7-line
by 24-character display, in Release 2.0 and later, this More symbol appears on
Line 1, next to the More button. In Release 1.0 or Release 1.1, the More symbol
appears on Line 7.
Home Screen
The Home screen, illustrated in Figure 9 and Figure 10, is the display's home
base. It remains on the display unless the user selects another screen. If the
user has programmed a posted message and no call is active on the extension,
Line 1 shows the posted message. When the user makes or receives a call, Line
1 is overwritten with call-handling information, such as a number being dialed,
the name or number of a caller, and the type of incoming call. In Release 2.0
and later, the date is shown as pictured in Figures 9 and 10; in Release 1.0 or
Release 1.1, the date is shown as, for example,
.
IN CONFERENCE
MAR 15
12:30
Home
Menu
Inspct
More
Figure 14. 2-Line Display Home Screen
When the extension is idle, Line 2 of the Home screen shows the date and time.
If the timer is running or the user has programmed an Alarm button, this
information is also shown on Line 2.
207
