Feature Reference
In Release 2.1 and later (see Table 38), in Basic format:
C
D
In ISDN format (see Table 39):
I
(Release 3.0 and later only) facility if the Calling Party Number is
received.
C
non-Caller ID facility, an outgoing voice call on a PRI or Caller ID
facility, or an incoming call on a Caller ID facility if no Caller ID
information is received.
D
DATE (Column 2). The date of the connection is shown in mm/dd/yy
format. Leading zeros are not suppressed.
TIME (Column 3). The time of the connection is shown in hh:mm format.
The system time is used and is shown in 24-hour (military) form.
CALLED NUMBER (Column 4). For an outgoing call, this is the dialed
number or, if the number has been suppressed for reasons of privacy or
security, the marked System Speed Dial code associated with that
number. In Basic format, an incoming call has only the word
field. In ISDN format, for an incoming call on a PRI facility with Automatic
Number Identification (ANI), or a loop-start trunk with the Caller ID service
provided through the CO and the system's 800 GS/LS-ID module
(Release 3.0 and later on loop-start lines only), the calling telephone
number, if available, is included here. If the calling party number was not
available for a call on one of these facilities, the word
field. In Release 2.1 and later, all incoming calls on non-PRI facilities
without identification services also have the word
maximum number of digits for the field is 15. An asterisk (*) indicates
far-end disconnect if the call is on a supervised facility. A question mark
(?) indicates that the number overflowed (was more than 15 digits).
DUR. (Column 5). The duration of the call is shown in hh:mm:ss format.
LINE (Column 6). This is the facility number or outside trunk used to
make or receive the reported call.
STN. (Column 7). This is the extension that first answered or made the
recorded call. The exception is an incoming call that is transferred to
another extension or is parked and picked up by another extension; the
destination extension or the extension that picked up is then recorded.
indicates a voice call or a data call on an analog facility.
indicates a data call on a digital facility.
indicates an incoming voice or data call on a PRI or Caller ID
indicates an outgoing or incoming voice call on a non-PRI or
indicates an outgoing data call on a digital facility.
Station Message Detail Recording (SMDR)
in this
IN
appears in this
IN
in this field. The
IN
