Configuring a Static Aggregation Group

Follow these steps to configure a static aggregation group:
To do...
Enter system view
Create a Layer 2
aggregate interface and
enter the Layer 2
aggregate interface view
Exit to system view
Enter Layer 2 Ethernet
interface view
Assign the Ethernet
interface to the
aggregation group
Removing a Layer 2 aggregate interface also removes the corresponding aggregation group. At
the same time, the member ports of the aggregation group, if any, leave the aggregation group.
To guarantee a successful static aggregation, ensure that the ports at the two ends of each link to
be aggregated are consistent in the selected/unselected state.

Configuring a Dynamic Aggregation Group

Follow these steps to configure a Layer 2 dynamic aggregation group:
To do...
Enter system view
Set the system LACP
priority
Create a Layer 2
aggregate interface and
enter the Layer 2
aggregate interface view
Use the command...
system-view
interface bridge-aggregation
interface-number
quit
interface interface-type
interface-number
port link-aggregation group number
Use the command...
system-view
lacp system-priority
system-priority
interface bridge-aggregation
interface-number
1-7
Remarks
—
Required
When you create a Layer 2
aggregate interface, a Layer 2
static aggregation group
numbered the same is created
automatically.
—
Required
Repeat the two steps to assign
multiple Ethernet interfaces to
the aggregation group.
Remarks
—
Optional
By default, the system LACP
priority is 32768.
Changing the system LACP
priority may affect the
selected/unselected state of the
ports in a dynamic aggregation
group.
Required
When you create a Layer 2
aggregate interface, a Layer 2
static aggregation group
numbered the same is created
automatically.
