Configuring OSPF Network Management

After trap generation is enabled for OSPF, OSPF generates traps to report important events. Traps fall
into the following levels:
Level-3, for fault traps
Level-4, for alarm traps
Level-5, for normal but important traps
Level-6, for notification traps
The generated traps are sent to the Information Center of the device. The output rules of the traps,
namely, whether to output the traps and the output direction, are determined according to the
Information Center configuration. (For Information Center configuration, refer to "Information Center
Configuration" in the System Volume.)
Follow these steps to configure OSPF network management:
To do...
Enter system view
Bind OSPF MIB to an
OSPF process
Enable OSPF trap
generation

Enabling Message Logging

Follow these steps to enable message logging:
To do...
Enter system view
Enter OSPF view
Enable message
logging
Use the command...
system-view
ospf mib-binding process-id
snmp-agent trap enable ospf
[ process-id ] [ ifauthfail | ifcfgerror |
ifrxbadpkt | ifstatechange |
iftxretransmit |
lsdbapproachoverflow |
lsdboverflow | maxagelsa |
nbrstatechange | originatelsa |
vifcfgerror | virifauthfail |
virifrxbadpkt | virifstatechange |
viriftxretransmit |
virnbrstatechange ] *
Use the command...
system-view
ospf [ process-id | router-id router-id |
vpn-instance instance-name ] *
enable log [ config | error | state ]
1-43
Remarks
—
Optional
The OSPF process with the
smallest process-id is bound
with OSPF MIB by default.
Optional
Enabled by default
Remarks
—
—
Required
Not enabled by default.
