To do...
Configure the match criteria
Return to system view
Create a traffic behavior and
enter traffic behavior view
Configure the traffic mirroring
action for the traffic behavior
Return to system view
Create a QoS policy and
enter QoS policy view
Associate the class with the
traffic behavior
Return to system view
Apply the QoS policy
Among the LPUs supported by S7900E switches, the SC, SD, and EB series LPUs support mirroring
incoming packets and outgoing packets; the SA and EA series LPUs only support mirroring incoming
packets.

Configuring Remote Traffic Mirroring

To implement remote traffic mirroring, perform the following configurations on the source device and
destination device:
Configurations on the source device
Traffic mirroring configuration: configure traffic mirroring on the source device to mirror packets
matching certain criteria to the port connecting to the destination device (assuming the port is Port
A). For the detailed configuration procedure, refer to
Remote source mirroring group configuration: configure a remote source mirroring group on the
source device, and configure the destination port in traffic mirroring (that is, Port A) as the egress
port. For the detailed configuration procedure, refer to
You should specify an arbitrary port as the mirroring port. To prevent packets received/sent by the port
from being mirrored to the destination device by the remote source mirroring group, you are
recommended to configure an unused port as the mirroring port.
Use the command...
if-match match-criteria
quit
traffic behavior behavior-name
mirror-to { cpu | interface
interface-type interface-number }
quit
qos policy policy-name
classifier classifier-name
behavior behavior-name
quit
Refer to QoS Configuration in the
QoS Volume
2-2
Required
—
Required
Required
—
—
Required
—
You can apply a QoS policy to
a port, VLAN, or globally on
an S7900E switch.
Configuring Traffic Mirroring.
Creating a remote source mirroring
Remarks
group.
