4) Redistribute direct routes
Configure BGP to redistribute direct routes on Switch B, so that Switch A can obtain the route to
9.1.1.0/24 and Switch C can obtain the route to 3.1.1.0/24.
# Configure Switch B.
[SwitchB] bgp 65009
[SwitchB-bgp] import-route direct
# Display the BGP routing table on Switch A.
[SwitchA] display bgp routing-table
Total Number of Routes: 4
BGP Local router ID is 1.1.1.1
Status codes: * - valid, ^ - VPNv4 best, > - best, d - damped,
h - history,
Origin : i - IGP, e - EGP, ? – incomplete
Network
*> 2.2.2.2/32
* 3.1.1.0/24
*> 8.1.1.0/24
*> 9.1.1.0/24
Two routes 2.2.2.2/32 and 9.1.1.0/24 have been added in Switch A's routing table.
# Display the BGP routing table on Switch C.
[SwitchC] display bgp routing-table
Total Number of Routes: 4
BGP Local router ID is 3.3.3.3
Status codes: * - valid, ^ - VPNv4 best, > - best, d - damped,
h - history,
Origin : i - IGP, e - EGP, ? - incomplete
Network
i 2.2.2.2/32
*>i 3.1.1.0/24
*>i 8.1.1.0/24
* i 9.1.1.0/24
You can find the route 8.1.1.0 becomes valid with the next hop as Switch A.
5) Verification
# Ping 8.1.1.1 on Switch C.
[SwitchC] ping 8.1.1.1
PING 8.1.1.1: 56 data bytes, press CTRL_C to break
Reply from 8.1.1.1: bytes=56 Sequence=1 ttl=254 time=2 ms
Reply from 8.1.1.1: bytes=56 Sequence=2 ttl=254 time=2 ms
Reply from 8.1.1.1: bytes=56 Sequence=3 ttl=254 time=2 ms
Reply from 8.1.1.1: bytes=56 Sequence=4 ttl=254 time=2 ms
Reply from 8.1.1.1: bytes=56 Sequence=5 ttl=254 time=2 ms
--- 8.1.1.1 ping statistics ---
5 packet(s) transmitted
5 packet(s) received
i - internal, s - suppressed, S - Stale
NextHop MED
3.1.1.1 0
3.1.1.1 0
0.0.0.0 0
3.1.1.1 0
i - internal, s - suppressed, S - Stale
NextHop MED
2.2.2.2 0
2.2.2.2 0
3.1.1.2 0
2.2.2.2 0
1-48
LocPrf PrefVal Path/Ogn
0 65009?
0 65009?
0 i
0 65009?
LocPrf PrefVal Path/Ogn
100 0 ?
100 0 ?
100 0 65008i
100 0 ?
