# Configure the tunnel encapsulation mode.
[SwitchB-Tunnel1] tunnel-protocol gre
# Configure the source address for interface Tunnel 1.
[SwitchB-Tunnel1] source vlan-interface 101
# Configure the destination address for interface Tunnel 1.
[SwitchB-Tunnel1] destination 1.1.1.1
[SwitchB-Tunnel1] quit
# Create service loopback group 1, setting the service type to tunnel.
[SwitchB] service-loopback group 1 type tunnel
# Add interfaceGigabitEthernet 2/0/3 to service loopback group 1.
[SwitchB] interface GigabitEthernet 2/0/3
[SwitchB-GigabitEthernet2/0/3] undo stp enable
[SwitchB-GigabitEthernet2/0/3] port service-loopback group 1
# Apply service loopback group 1 to the tunnel in tunnel interface view.
[SwitchB-GigabitEthernet2/0/3] quit
[SwitchB] interface tunnel 1
[SwitchB-Tunnel1] service-loopback-group 1
[SwitchB-Tunnel1] quit
# Configure a static route from Switch B through interface Tunnel 1 to Group 1.
[SwitchB] ip route-static 10.1.1.0 255.255.255.0 Tunnel 1

Configuring a GRE over IPv6 Tunnel

EB boards and SD boards support only the GRE over IPv6 Tunnel.

Configuration Prerequisites

Interfaces on a device, such as VLAN interfaces, and loopback interfaces, are configured with IPv6
addresses and can communicate. These interfaces can serve as the source of a virtual tunnel interface
to ensure the reachability of the destination address.

Configuration Procedure

Follow these steps to configure a GRE over IPv6 tunnel:
To do...
Enter system view
Enable the IPv6 packet
forwarding function
Use the command...
system-view
ipv6
1-41
Remarks
—
Required
Disabled by default
