Summary of Contents for i-PRO WJ-NX510K Series

  • Page 1 C o v e r Operating Instructions WJ-NX510K Series WJ-NX410K Series WJ-NX310K Series Ver 1.001.000...
  • Page 2: Table Of Contents

    Contents Contents Preface ………………………………………………………………………… About the user manuals ………………………………………………………… Abbreviations ……………………………………………………………………… About the settings and operation of the recorder …………………………… Restrictions when using this product …………………………………………… Before using this product ………………………………………………………… Motion detection (VMD) function ……………………………………………… Time display of recorded images ………………………………………………… Response to the mouse operations ………………………………………………...
  • Page 3 Contents Lists of the setting items (Setup menu) ………………………………………… About the error logs and the network logs ……………………………………… [Operation via recorder's main monitor] ………………………………… 229 Before operation ………………………………………………………………… Operation window ………………………………………………………………… Basic operations …………………………………………………………………… Login operation at startup ………………………………………………………… View ………………………………………………………………………………… Monitor live images ………………………………………………………………...
  • Page 4 Contents About the operation window …………………………………………………… View ………………………………………………………………………………… Monitor live images ……………………………………………………………… Operate the camera ……………………………………………………………… Event function …………………………………………………………………… About event function ……………………………………………………………… Play ………………………………………………………………………………… Play recorded images ……………………………………………………………… Play image recorded at a designated date & time ……………………………… Search and play recording events (REC event search) …………………………...
  • Page 5: Preface

    Preface Preface About the user manuals This operating instructions compatible with firmware version Ver.1.00 of WJ-NX510K Series, WJK-NX410K Series and WJ-NX310K Series. WJ-NX510K Series refer to WJ-NX510K, WJ-NX510KG and WJ-NX510KGV. WJ-NX410K Series refer to WJ-NX410K, WJ-NX410KG and WJ-NX410KGV. WJ-NX310K Series refer to WJ-NX310K, WJ-NX310KG and WJ-NX310KGV.
  • Page 6: Abbreviations

    The following abbreviations are used in this manual. WJ-NX310K Series is called NX310. WJ-NX410K Series is called NX410. WJ-NX510K Series is called NX510. Microsoft Windows 10 is described as Windows 10. Network cameras are described as cameras. Personal computers are called PCs.
  • Page 7: Restrictions When Using This Product

    Preface Restrictions when using this product When using this product, some functions have the following restrictions. Before using this product, keep the following in mind. Restrictions for individual cameras are posted on our support website. When connected to a monitor ●...
  • Page 8 Preface ・ When the first frame is displayed by starting the frame by frame playback during pausing ● Playback may be performed in several seconds intervals (*) when the following operations are performed. Refer to the description of operations during playback for how to control playback.
  • Page 9 Preface interval. ● Depending on the camera, setting the recording frame rate to 60 ips may cause interruption of audio or reduction of the recording frame rate. ● If you set the smart coding (GOP control), the pre-event recording and SD memory backup functions will not work properly.
  • Page 10 When using viewer software ● The playback speed may become slow when playing back high resolution high frame rate images. When using i-PRO Mobile APP ● When using a sub-monitor, the maximum number of mobile playback connections is one.
  • Page 11: Before Using This Product

    Preface Register for remote monitoring ● When the product is registered in the remote monitoring, the following restrictions will be applied. ・ Only “1-screen live sequence” and “Switch by alarm terminal input” are available for operation mode of the sub monitor. ・...
  • Page 12: Time Display Of Recorded Images

    Preface daytime and at night after appropriately configuring the area settings and the sensitivity settings according to the camera installation conditions and possible movement of subjects. When the detection function does not work or false detection occurs, use a sensor separately.
  • Page 13: Event Type

    Preface The following recording operations are available. Schedule recording: Recording that is automatically performed at the designated time range on the designated day(s) of the week Event recording: Recording that is automatically performed when an event occurs (such as terminal alarm/camera site alarm/command alarm, etc.) Emergency recording: Gives priority to recording video and audio at emergency using the external switch connected to the emergency record input terminal of the recorder.
  • Page 14: [Setup Via Recorder's Main Monitor]

    [Setup via recorder's main monitor] [Setup via recorder's main monitor] Setup via recorder's main monitor The Setup via recorder's main monitor using the mouse include [Quick setup] - [Easy Start], [Basic setup] and [Advanced setup].   [Quick setup] - Easy Start provides the minimum settings necessary to use this product, including date setting, camera registration, and recording settings.
  • Page 15: Configure The Basic Settings [Basic Setup]

    [Setup via recorder's main monitor] supported cameras. ● When using a camera other than ours or Panasonic cameras with ONVIF connection, [Quick setup] - Easy Start only cannot be used to start operation. After setting the date and time, fixed IP address, user name/password, etc.
  • Page 16 [Setup via recorder's main monitor] ■ Date & time [Date] Set the current date. Select the year, month and day from the calendar. [<<Y]/[Y>>] button: Selects the previous or next year. [<M]/[M>] button: Selects the previous or next month. [ Time ] Set the current time.
  • Page 17 [Setup via recorder's main monitor] ■ Display format Select a display format for the current date & time. Note: ● "Date & time display" on the [Camera setup] tab corresponds to the display format settings on this tab. ☞ Set up camera [Camera setup] [...
  • Page 18 [Setup via recorder's main monitor] 24 h: 15:00:00 12 h: 03:00:00 PM Default: 24 h ■ Time zone Select the time zone and shift to/from daylight saving time. [ Set time zone ] Select your time zone. GMT-12:00 - GMT+13:00 Default: GMT Important: ●...
  • Page 19: Camera Setup [Camera]

    [Setup via recorder's main monitor] Set up language [Language] Select the display language for the main monitor and for the web browser on the PC. [ Language ] Japanese/ English/ Français/ Español/ Deutsch/ Italiano/ Português/ ไทย / 簡体中文/ 繁體 中文/ Tiếng Việt Default: English Camera setup [Camera] The "Camera"...
  • Page 20 [Setup via recorder's main monitor] [Detect cameras] The cameras connected to a network can be detected for registration. ☞ Detect cameras for registration [Detect cameras] [Management of camera user] Set a user name/password of the camera in the camera. Change the password of camera [Management of camera user] ☞...
  • Page 21 [Setup via recorder's main monitor] Note: ● When an error message is displayed, check the camera connections and settings. (☞ operating instructions of the camera) If the problem cannot be solved, refer to "Easy Start Guide (included)" and register the camera again. ●...
  • Page 22 [Setup via recorder's main monitor] Note: ● Before the settings, register the cameras into the network. Even though it is possible to detect up to 192 cameras, only the maximum number of cameras per model can be registered. [Port selection] Select the port to which the camera to be detected is connected.
  • Page 23 [Setup via recorder's main monitor] [No.] Shows a number of detected cameras. The maximum number of detectable cameras will be 192 units. [Select] Mark the checkboxes of cameras to register. The vacant number will be fulfilled by the subsequent camera. [Model] If you are using a camera manufactured by us or Panasonic that is supported by this camera, the part number of the camera will be displayed.
  • Page 24 [Setup via recorder's main monitor] recorder will forcibly change the setting to "Off" to give the IP addresses automatically. ● If this product does not automatically assign an IP address to the camera, set a fixed IP address to the camera that can communicate with this product. ●...
  • Page 25 [Setup via recorder's main monitor] Register camera administrator: Registers a user name and password to a camera whose administrator is not registered. Enter a user name/password. Note: ● Cameras that already have the User name/Password registered cannot register another User name/Password. Change password: Changes the password of the camera user registered to the recorder only.
  • Page 26 [Setup via recorder's main monitor] Change the registered information [Registered information] Click the [Setup >] button for "Registered information" on the [Camera registration] tab to display the following items. After editing the settings, click the [OK] button to save the settings and return to the [Camera registration] tab.
  • Page 27 [Setup via recorder's main monitor] Note: ● The method of installation will be set to the default values of each mode if the options of the fisheye camera are changed. Please refer to our technical information web site for the default values of each mode. [Address] An address already in use will be displayed.
  • Page 28 [Setup via recorder's main monitor] ● Depending on the model of the camera, the camera may reboot when the compression method is changed. The reboot will be detected as a communication error, but that is not a malfunction. ● If the compression method is set to "MJPEG", the live image for remote monitoring will not be displayed.
  • Page 29 [Setup via recorder's main monitor] product and update the model number information. When the acquired model number is different from the registered one, as the image capture size is changed to the default, reset the image capture size in [REC & event]- [Recording setup] again.
  • Page 30 [Setup via recorder's main monitor] Select a camera which performs AI privacy guard recording [AI privacy guard recording camera] Click the [Setup >] button of [AI privacy guard recording camera] on the [Camera registration] tab to display the following screen. [Recording camera] For the registered cameras, select a camera to record the AI privacy guard image.
  • Page 31 [Setup via recorder's main monitor] Note: ● The camera no. selected on the recording camera changes to the AI privacy guard recording display on all settings screens of this recorder, as shown in the following screen. ● Select the camera and then click the [Clear] button to clear the assigned camera no.
  • Page 32 [Setup via recorder's main monitor] Set up date & time display [Date & time display] Select the date & time display position for each camera and transmit it to the cameras to change the camera settings. Clicking the [Setup >] button for "Date & time display" on the [Camera setup] tab will display the following items.
  • Page 33 [Setup via recorder's main monitor] [Position] Select the position to display the date & time on the images. If the setting is to be transmitted to the camera, mark this item to select the display position. L-Upper/ L-Lower/ R-Upper/ R-Lower ■...
  • Page 34 [Setup via recorder's main monitor] ■ Setting items [Display] Select whether or not to display the title on camera images. If title display is activated, the title will be displayed on camera images and will also be recorded with the recorded images.
  • Page 35 [Setup via recorder's main monitor] ● [Display Title]Enter a character string to be displayed on the image using the on-screen keyboard. (Up to 16 alphanumeric characters) Available characters: 0-9, A-Z, ! # $ % ( )* + , - . / : ; = ? ●...
  • Page 36 [Setup via recorder's main monitor] Once transmission is completed and the setting has been applied to the camera, "OK" will be displayed in the "Results" field. If the display reads "Authentication error", etc., the camera connection or the setting may have failed.
  • Page 37 [Setup via recorder's main monitor] Off: All the indicators will light off. ■ Camera Selection Select the camera to which the "Indicator" setting is to be sent. Mark the checkbox of the camera to which the setup information is to be transmitted. [Transmission] button Transmit the setting of the "Indicator"...
  • Page 38 [Setup via recorder's main monitor] ■ Setting items [Transmission priority] Select the transmission mode for H.264/H.265 images from the following. Frame rate: H.264/H.265 images will be transmitted with the frame rate specified in "Frame rate". Advanced VBR: H.264 images will be transmitted with the frame rate specified in "Frame rate".
  • Page 39 [Setup via recorder's main monitor] Note: ● Set up the transmission mode again when the camera is changed on the camera registration screen or change of the camera is detected. [Burst tolerance level] Select the allowance of "Max bit rate (per client)" for the H.264 bit rate from the following when the transmission priority is "Advanced VBR".
  • Page 40 [Setup via recorder's main monitor] [Transmission] button Transmit the setting of the "Transmission priority" to the camera. Once transmission is completed and the setting has been applied to the camera, "OK" will be displayed in the "Results" field. If the display reads "Authentication error", etc., the camera connection or the setting may have failed.
  • Page 41 [Setup via recorder's main monitor] frequent errors occur, shorten the refresh interval to reduce image distortions. However, the refresh interval may be longer than the set value. 0.2 s/ 0.5 s/ 1 s/ 2 s/ 3 s Note: ● Set up the refresh interval again when the camera is changed on the camera registration screen or change of the camera is detected.
  • Page 42 [Setup via recorder's main monitor] setup window. [Upside-down] On (desktop): Select this when the camera is to be installed with the dome side up. Off (ceiling): Select this when the camera is to be installed with the dome side down. Wall: Select this when the camera is to be installed on a wall.
  • Page 43 [Setup via recorder's main monitor] The screen returns to the [Camera setup] tab. Note: ● To flip the camera image vertically, select the "Off (ceiling)". ● If a fisheye camera is registered, "Off (ceiling)" will be set. Select "Wall" to install the camera on the wall.
  • Page 44 [Setup via recorder's main monitor] ■ Camera Selection Select the camera to which the setting of the "Image rotation" is to be sent. Mark the checkbox of the camera to which the setup information is to be transmitted. [Transmission] button Transmit the setting of the "Image rotation"...
  • Page 45 [Setup via recorder's main monitor] [Pan/tilt-flip] Select whether or not to activate the pan/tilt-flip function that can achieve camera controllability equal to 360° endless cameras. On: The pan/tilt-flip function will work. Off: The pan/tilt-flip function will not work. ■ Camera Selection Select the camera to which the setting of the "Pan/tilt-flip"...
  • Page 46 [Setup via recorder's main monitor] The screen returns to the [Camera setup] tab. Set self return [Self return] Select the self-return function for individual cameras and transfer it to the camera to change the camera settings. [Self return] After the manual operation is completed, once the time set by the "Self return time" is passed, any of the selected camera operation modes will be automatically returned.
  • Page 47 [Setup via recorder's main monitor] [Self return time] After the manual operation is completed, select the deadline time to return to the "Self return" setting from the following items. 10 s / 20 s / 30 s / 1 min / 2 min / 3 min / 5 min / 10 min / 20 min / 30 min / 60 min ■...
  • Page 48 [Setup via recorder's main monitor] [Super Dynamic (Wide dynamic range)] Select "On" or "Off" to determine whether or not to activate the super dynamic function. On (High): The super dynamic function will work. When "On (High)" is selected, the tone level will be compensated to emphasize the contrast.
  • Page 49 [Setup via recorder's main monitor] [Back] button Click the button after completing the settings. The screen returns to the [Camera setup] tab. Set the adaptive black stretch function of the camera [Adaptive black stretch] Determine whether to enable the adaptive black stretch function for each camera. The settings will be changed after the settings have been transmitted to the camera.
  • Page 50 [Setup via recorder's main monitor] ■ Camera Selection Select the camera to which the setting of the "Adaptive black stretch" is to be sent. Mark the checkbox of the camera to which the setup information is to be transmitted. [Transmission] button Transmit the setting of the "Adaptive black stretch"...
  • Page 51 [Setup via recorder's main monitor] [Back light compensation (BLC)] When "On" is selected for "Super Dynamic", this function is not available. The back light compensation function masks the brighter area in image and compensates exposure in silhouette created by back light. On: Mask area will automatically be set.
  • Page 52 [Setup via recorder's main monitor] [Back] button Click the button after completing the settings. The screen returns to the [Camera setup] tab. Set up Light control mode [Light control mode] Select how to control the amount of light for each camera and transmit the information to the cameras to change the camera settings.
  • Page 53 [Setup via recorder's main monitor] ■ Camera Selection Select the camera to which the setting of the "Light control mode" is to be sent. Mark the checkbox of the camera to which the setup information is to be transmitted. [Transmission] button Transmit the setting of the "Light control mode"...
  • Page 54 [Setup via recorder's main monitor] [Auto slow shutter (Maximum shutter)] The auto slow shutter adjusts the sensor storage time to enhance the electronic sensitivity. The following are available setting values. Off (1/30s)/ Max. 2/30s/ Max. 4/30s/ Max. 6/30s/ Max. 10/30s/ Max. 16/30s ■...
  • Page 55 [Setup via recorder's main monitor] The screen returns to the [Camera setup] tab. Important: ● When the auto slow shutter is set, the frame rate may drop. Noise or white dots (scratches) may also be seen in image. Note: ● When "Max. 16/30s" is selected, the electronic sensitivity will automatically be enhanced up to 16 times.
  • Page 56 [Setup via recorder's main monitor] [Day & Night (IR/electrical)] Select a method of how to switch between B/W image and color image from the following. Off: Color images will always be taken. On: B/W images will always be taken. On (IR Light On): B/W images will always be taken. Use it at night time or using near-IR lighting.
  • Page 57 [Setup via recorder's main monitor] Set the intelligent auto of camera [Intelligent auto] Select the intelligent auto for each camera and transmit it to the camera to change the camera settings. Clicking the [Setup >] button for "Intelligent auto" on the [Camera setup] tab will display the setup window.
  • Page 58 [Setup via recorder's main monitor] [Transmission] button Transmit the setting of the "Intelligent auto" to the camera. Once transmission is completed and the setting has been applied to the camera, "OK" will be displayed in the "Results" field. If the display reads "Authentication error", etc., the camera connection or the setting may have failed.
  • Page 59 [Setup via recorder's main monitor] a change (movement) is detected in the image. Refer to the operating instructions of the camera in use for how to configure the VMD alarm. On: Detects alarms. Off: Does not detect alarms. [Detection sensitivity] To transmit the settings to the camera, mark this item, and select either of the following.
  • Page 60 [Setup via recorder's main monitor] [Camera selection] Select the camera for which you want to set the VMD alarm. [Select a preset position] If the selected camera is a camera with preset function, the preset position is selected.
  • Page 61 [Setup via recorder's main monitor] [Model] [Error information] Refer to the following section. Camera setup [Camera] ☞ [Setup VMD area] Click the top left corner and bottom right corner of the square on the screen, set the specified position as area 1, and display the area box. Area will be set in numerical order starting form area number 1.
  • Page 62 [Setup via recorder's main monitor] [Schedule mode] Select the schedule operation. Off: Do not perform the schedule operation. Alarm permission (Terminal alarm 1,2,3): Allow the terminal to input an alarm during the set range of the schedule. Alarm permission (Terminal alarm 1): Allow Terminal 1 to input an alarm during the set range of the schedule.
  • Page 63 [Setup via recorder's main monitor] set. ■ Camera selection Select the camera to which the setting of the "Schedule" is to be sent. Mark the checkbox of the camera to which the setup information is to be transmitted. [Transmission] button Transmit the setting of the "Schedule"...
  • Page 64 [Setup via recorder's main monitor] ■ Connection method...
  • Page 65: Set Up Recording/Events [Rec & Event]

    [Setup via recorder's main monitor] [Connection method] Set the connection method for each camera. RTP: Connects with the RTP. RTSP: Connects with the RTSP. It is used for local camera connection and others. Internet mode: Connects in the Internet mode. It is used to connect remote cameras or for other connection.
  • Page 66 [Setup via recorder's main monitor] Set up recording [Recording setup] Configure the settings relating to schedule recording. Set the day(s), time table(s), frame rate and image quality for recording. ■ Schedules Recording will be performed according to the schedules set in advance. Select the day(s) of the week and the time table(s).
  • Page 67 [Setup via recorder's main monitor] Note: ● At the default, schedule recording and event recording have been set for 24 hours on Time table1. To delete the designated start and end time, right-click the timetable. ● The recording time table can be set by dragging the start and end time on the time bar with the mouse.
  • Page 68 [Setup via recorder's main monitor] Important: ● If the setting in any one of Schedule 1 to 16 is to notify an alarm notification, notification about camera site alarm inputs will be made even for cameras to which have been allocated the schedules in which alarm notification has not been set.
  • Page 69 [Setup via recorder's main monitor] Important: ● For a camera whose compression method is [MJPEG], "XF" cannot be set. ● If a camera whose compression method is [MJPEG] is included, [MJPEG] camera is set to "SF" even if "XF" is set by slider bar of image quality setting.
  • Page 70 [Setup via recorder's main monitor] ☞ Set up recording for individual cameras [Advanced recording setup] Configure the advanced settings for schedule recording [Advanced schedule setup] Up to 16 schedule patterns can be set. Up to 6 time zones of the schedule recording or event recording can be set for each schedule.
  • Page 71 [Setup via recorder's main monitor] before an alarm occurs. [Event recording duration] Set the recording duration in the event that an alarm occurs. 2 s/ 5 s/ 10 s/ 20 s/ 30 s/ 1 min/ 2 min/ 3 min/ 5 min/ 10 min/ 15 min Manual: Recording will continue while receiving an alarm input signal.
  • Page 72 [Setup via recorder's main monitor] [e-Mail] Refer to the following section. Set up recording [Recording setup] ☞ [Alarm notification] Refer to the following section. ☞ Set up recording [Recording setup] [Prev page] / [Next page] The schedule settings to be configured will be switched over. [Display the schedule list.] Display each time table from Schedule 1 to Schedule 16 and settings of the schedule recording, event recording, etc.
  • Page 73 [Setup via recorder's main monitor] Set up recording for individual cameras [Advanced recording setup] Set up items such as the image capture size, frame rate and image quality for individual cameras. Clicking the [Advanced >] button on the [Recording setup (All cameras)] tab will open the advanced setup page.
  • Page 74 [Setup via recorder's main monitor] HVGAW(640×360)/ HD(1280×720)/ FHD(1920×1080)/ WQHD(2560×1440)/ 4M (2688×1520)/ 5M(3072×1728)/ 6M(3328×1872)/ 4KUHD(3840×2160) <When the aspect ratio is 1:1> 1.4M(1200×1200)/ 1.6M(1280×1280)/ 2M(1440×1440)/ 4M(2048×2048)/ 5M (2192×2192)/ 8M(2816×2816)/ 9M(2992×2992) <When the aspect ratio is 9:16> 0.2M(360×640)/ 1M(720×1280)/ 2M(1080×1920)/ 4M(1440×2560)/ 4M(1520×2688)/ 5M(1728×3072)/ 6M(1872×3328)/ 8M(2160×3840) When the aspect ratio is set to portrait resolution, the image is rotated by 90 °.
  • Page 75 [Setup via recorder's main monitor] ☞ Set up recording [Recording setup] [Audio] Select whether or not to record audio together with images. On(AAC-LC): Audio will be recorded. Off: Audio will not be recorded. Default: Off [Schedule] Select a schedule in which the desired recording to be performed is included. Schedule1: Recording will be performed according to the settings for schedule1.
  • Page 76 [Setup via recorder's main monitor] ☞ Set up recording [Recording setup] [Back] button Click the button after completing the settings. The screen returns to the [Recording setup] tab. Set up event [Event setup] Configure event-related settings such as the alarm output duration and buzzer duration. ■...
  • Page 77 [Setup via recorder's main monitor] Rec.: Output of the alarm signal will continue during event recording. Default: 2 s [Buzzer duration] Set the duration of the buzzer sound when an alarm occurs. When "0 s" is selected, the buzzer will not sound. 0 s/ 2 s/ 5 s/ 10 s/ 20 s/ 30 s/ 1 min Ext.: The buzzer will keep on sounding until the alarm action is reset.
  • Page 78 [Setup via recorder's main monitor] On(ACK/RESET): Switches the monitor display linking with the alarm confirmation and resetting. Off: Does not switch the monitor display. Default: Off Note: ● For "On(ACK/RESET)", set the General purpose I/O terminals to "Alarm reset input". Configure the settings and operations relating to the system [System ☞...
  • Page 79 [Setup via recorder's main monitor] using AI privacy guard recording, select whether to display the camera (Recording camera) without privacy guard or the camera (AI privacy guard recording camera) with privacy guard. Default: Recording camera ■ Advanced event setup Configure advanced settings for individual alarm types (terminal alarm, camera site alarm, and command alarm).
  • Page 80 [Setup via recorder's main monitor] Default: Recording & alarm action [Alarm log] Determine whether or not to save the alarm log. Save: Logs will be saved. Not save: Logs will not be saved. Default: Save [Setup by terminal] Configure each setting for the alarm input terminal. Note: ●...
  • Page 81 [Setup via recorder's main monitor] [Terminal output] Choose whether or not to output an alarm signal from the alarm output terminal of the ALARM/CONTROL connector on the recorder’s rear panel when an alarm signal is received. On: Outputs the alarm signals from the alarm output terminal. Off: Does not output alarm signals.
  • Page 82 [Setup via recorder's main monitor] Refer to the following section for further information about the items available for "Advanced camera site alarm setup"; "Mode" and "Alarm log", and also "Recording camera", "Preset", "name" and "Terminal output" under "Setup by camera". Set up terminal alarm [Advanced terminal alarm setup] ☞...
  • Page 83 [Setup via recorder's main monitor] Refer to the following section for further information about the items available for "Advanced command alarm setup"; "Mode" and "Alarm log", and also "Recording camera", "Preset" and "Terminal output" under "Setup by command number". ☞ Set up terminal alarm [Advanced terminal alarm setup] [Back] button Click the button after completing the settings.
  • Page 84 [Setup via recorder's main monitor] [Recording mode] Determine whether or not to stop all recording actions. Set to "Off", primarily to stop access to the HDD before turning off the power. On: Performs recording. Off: Stops all recording actions. Default: On Important: ●...
  • Page 85 [Setup via recorder's main monitor] Note: ● When registering in the remote monitoring, the Alarm disarm duration operates at 30 seconds, regardless of the set value. [TCP alarm port number] Specify the number of the port to be used for receiving site alarm. Default: 1818 Note: ●...
  • Page 86 Search and play recording events (REC event search) ☞ ● Refer to the following URL for the message ID and detailed information of the Extension Software. https://i-pro.com/global/en/surveillance/trainingsupport/support/ technical-information <Control No.: C0328> [Emergency recording setup] Configure the settings related to emergency recording.
  • Page 87 [Setup via recorder's main monitor] [Recording time] Select a recording duration for the emergency recording. 30 s/ 1 min/ 3 min/ 5 min/ 10 min/ 15 min/ 30 min Manual: Records only while the connected external switch is being pressed. It records at least 8 seconds.
  • Page 88 [Setup via recorder's main monitor] Note: ●For cameras without audio recording, audio will not be recorded even when it is set to a value other than “Off”. ●Depending on the timing when emergency recording is started, audio may be recorded at the end of the previous recording data just before the emergency recording.
  • Page 89 [Setup via recorder's main monitor] Note: ●When many cameras are registered, the switchover of the schedule by the external recording input may be delayed. [SD backup rec.] Set whether to save the image on the SD memory card or not when the communication is disconnected during the recording.
  • Page 90 [Setup via recorder's main monitor] during the set recording time. The SD memory backup is only available if the camera supports the SD memory recording and the compression is set to H.264/H.265. The SD memory recording is done by the registered compression of the camera. Note: ●...
  • Page 91 [Setup via recorder's main monitor] Note: ● All images may not be acquired at one time due to the time between time tables of the schedule and the total capacity of the images. The remaining images will be acquired at the subsequent acquisition time. ●...
  • Page 92 [Setup via recorder's main monitor] For example, if you set "January 1st" to "Sunday", the recording will be performed as on Sunday, no matter which day of the week January 1st is actually on. The following screen of the special day will be displayed when the [Setup >] button is clicked.
  • Page 93 [Setup via recorder's main monitor] ■ Other setup [Make the frame rate of the pre-event recording to the frame rate of the event recording] Check to set the frame rate of the pre-event recording to the frame rate of the event recording.
  • Page 94: Configure The Advanced Settings [Advanced Setup]

    [Setup via recorder's main monitor] Note: ● Please be noted that if the communication is temporarily interrupted due to the network environment, the recording will continue until the alarm operation is canceled unless an end notification is received. ● In "Advanced camera site alarm setup", when one camera is set to "Recording Camera"...
  • Page 95 [Setup via recorder's main monitor] ■ Camera title [Display] Determine whether or not to display the camera title on the main monitor. On: Displays the camera title. Off: Does not display the camera title. Default: On [Position] Select the position to display the camera title on images. L-Upper/ L-Lower/ R-Upper/ R-Lower Default: R-Upper [Camera title]...
  • Page 96 [Setup via recorder's main monitor] Note: ● When using together with the date and time display to be set on the camera or OSD(Display Title), adjust the position to be displayed to not to overlap with them. Set up date & time display [Date & time display] ☞...
  • Page 97 [Setup via recorder's main monitor] [Keep aspect ratio] Select whether to change the aspect ratio of the displayed area if the aspect ratio of the image is different from the displayed area. Checked: Keep aspect ratio (Does not change the ratio automatically). Not checked: Does not keep aspect ratio (Changes the ratio automatically).
  • Page 98 [Setup via recorder's main monitor] ■ Detection frame information display Important: ● This recorder displays detection frame information for the AI video motiondetection (WV-XAE200W, WV-XAE300W) and the AI occupancy detection (WV-XAE207W, WV-XAE300W). Note: ● In the following cases, detection frame information is not displayed. ・During fisheye image correction display ・Digital zoom in use・Displaying live sequence ・When the information display screen or confirmation screen is displayed...
  • Page 99 [Setup via recorder's main monitor] [Frame display] Set whether to display the detection frame. You can select whether to display the detection frame before and after determination of the alarm, or display the detection frame only after determination of the alarm.  On: Displays the detection frame.
  • Page 100 [Setup via recorder's main monitor] * This is an example screen of NX410. [Select multiscreen buttons displaying on wide view operation panel] The button whose checkbox is marked will be displayed on the wide view operation panel. Note: ● [NX410/NX510] When using the sub monitor, 64-screen in wide view is not available on the main monitor.
  • Page 101 [Setup via recorder's main monitor] Note: ● If the image is expanded by this setting, the camera operation or the motion detection search in the image may not function as the specified coordinates or area. [Fix the HDMI output to the following video mode] Fixes the signal system of the HDMI output when it is checked.
  • Page 102 [Setup via recorder's main monitor] [Switch to 1-screen display when playing from alarm log] Select whether to switch to 1-screen display when selecting and playing back the row of the Date and Time you want to play on the alarm log panel of the main monitor. Checked: Switch to 1-screen display Unchecked: Do not switch to 1-screen display Default: Checked...
  • Page 103 [Setup via recorder's main monitor] Off: Does not display the camera title Default: On ■ Display settings Set the display sequence for camera images (image switching). [Mode] Select how to display images from the cameras. 1-screen live sequence: Images from the cameras will sequentially be switched and displayed on 1-screen.
  • Page 104 [Setup via recorder's main monitor] Note: ● Some cameras may take time to display images and the screen may be switched before images are displayed if the duration is short. In that case, set a longer time for the switching interval. ●...
  • Page 105 [Setup via recorder's main monitor] [Secret view] Secret view is a function that causes the camera image displayed on a 1-screen or the selected camera image on a multiscreen on the main monitor to be displayed as a black screen on the sub monitor. Determine whether or not to use secret view.
  • Page 106 [Setup via recorder's main monitor] Configure other settings relating to monitors [Advanced setup] Configure the audio output setting of the monitor and select the video format sent to the sub monitor. [Audio output camera] The camera channel whose audio is output from the recorder will be fixed. To fix the camera channel, select the camera whose audio is to be output from the recorder.
  • Page 107: Configure The Settings Relating To Network [Network]

    [Setup via recorder's main monitor] ■ Other setup [Detect a power-off of the sub monitor (HDMI)] If checked, when a sub-monitor is used in the configuration, the camera will notify you with an error behavior if the sub-monitor is not connected or powered off. Note: ●...
  • Page 108 [Setup via recorder's main monitor] Note: ● Enter the address octets and port numbers right-aligned. (Example: When the port number is 80, enter "00080".) The leading zeros are omitted here. ■ Network Setup Configure the network settings of the recorder. [Network settings] Select how the IP address is set up.
  • Page 109 [Setup via recorder's main monitor] [IP address] The IP address of the recorder will be displayed. To change the IP address, select each octet of the address, and click the [▲]/[▼] button. Default: 192.168.0.250 [Camera/PC port] 0.0.0.0 [PC port] [Subnet mask] Select the subnet mask in accordance with the recorder’s network environment.
  • Page 110 [Setup via recorder's main monitor] an alphabetical character. Enter 3 to 63 alphanumeric characters including hyphens (-) and periods (.). Default: localdomain ■ DDNS Setup Select the DDNS service to determine whether or not to use DDNS. Off: Does not use the DDNS function. Dynamic DNS update: Uses Dynamic DNS Update (RFC2136 compliant).
  • Page 111 [Setup via recorder's main monitor] another company's DDNS service. For information regarding the selection and setting of DDNS services of other companies, contact the service provider. [Host name] Enter the host name to use with the Dynamic DNS Update service. Available number of characters: 0 to 250 characters Enter in the format (Host name).(Domain name) Default: NWDR...
  • Page 112 [Setup via recorder's main monitor] * This is an example screen of NX410. ■ Network setup [Maintenance port] [NX410/NX510] Set the network for the maintenance port of the recorder. [IP address] [NX410/NX510] Default: 192.168.2.250 [Subnet mask] [NX410/NX510] Default: 255.255.255.0 ■ Other setup [HTTP port number] Specify the HTTP port number to be used to send images from the recorder.
  • Page 113 [Setup via recorder's main monitor] Note: ● Depending on the network settings, network communication may not be established if the HTTP port number has been changed. In this case, refer to the administrator of each network. ● The following numbers, the HTTPS port number, the site alarm receive port number and the port number of the port forwarding are unavailable.
  • Page 114 [Setup via recorder's main monitor] Important: ● Port forwarding cannot be used with cameras that connection method is set to HTTPS in "Security between this product and camera". [ Port forwarding ] Set whether to enable the port forwarding or not. On: Sets the port forwarding.
  • Page 115 [Setup via recorder's main monitor] Note: ● The following numbers, the HTTPS port number, the site alarm receive port number and the port number of the port forwarding are unavailable.20, 21, 23, 25, 42, 53, 67, 68, 69, 79, 105, 110, 123, 161, 162, 443, 546, 547, 995, 10001, 10002, 10003, 10004, 10005, 10006, 10007, 50000~50255 ■...
  • Page 116 [Setup via recorder's main monitor] Default: Off [Address] Set the destination address. To change the IP address, click the [▲]/[▼] button. [Subnet mask] Set the destination subnet mask. Enter in the same way as the address. [Gateway] Set the destination gateway. Enter in the same way as the address. [Back] button Click this button after completing the settings.
  • Page 117 [Setup via recorder's main monitor] [SMTP server address] Enter an IP address or a name of the SMTP server to send e-mails. The name of the SMTP server is available only when "Manual" is selected for "DNS" on the [Basic] tab accessed from the "Advanced setup"...
  • Page 118 [Setup via recorder's main monitor] [Sender’s address] Enter the mail address of a sender. Entered mail addresses will be displayed in the "From" (sender) line. Enter up to 127 alphanumeric characters including hyphens (-), periods (.), @, and _. Default: NWDR [Security] Alarm mails or warning mails will be encrypted and transmitted.
  • Page 119 [Setup via recorder's main monitor] [Port number(to PC)] Enter the port number of the recipient PCs. It is usually not necessary change the default. Default: 1818 [Retry] Set the number of retry attempts for the transmission to the PC. 0 - 8 (times) (In steps of times) Default: 2 Note: ●...
  • Page 120 [Setup via recorder's main monitor] Up to 8 destination addresses can be registered. Enter up to 255 alphanumeric characters including hyphens (-) and periods (.). Configure HTTP alarm notification settings [HTTP alarm] Configure the settings to notify the PC via HTTP when an event or error occurs. [Address 1] to [Address 5] Set the IP address or host name of the HTTP server for HTTP alarm notification.
  • Page 121 [Setup via recorder's main monitor] Default setting: Blank [Password] Enter the password to access the HTTP server. Available number of characters: 0 - 63 characters Unavailable characters: Full-width and half-width symbols " " " " & " Default setting: Blank Note: ●...
  • Page 122 [Setup via recorder's main monitor] Configure the settings relating to NTP/SNMP synchronization [NTP/ SNMP] The settings to synchronize the system clock with the NTP (Network Time Protocol) and SNMP (Simple Network Management Protocol) server can be configured on this tab. ■...
  • Page 123 [Setup via recorder's main monitor] [Primary server address] [Secondary server address] Enter the address or name of the NTP server when adjusting the time using the NTP server. The name of the NTP server is available only when "Manual" is selected for "DNS" on the [Basic] tab accessed from the "Advanced setup"...
  • Page 124 [Setup via recorder's main monitor] Checked: Prohibits access from the outside of subnet. Not checked: Allows access from the outside of subnet. Default setting: Checked Important: ● To ensure security, it is suggested to prohibit access from outside the subnet when SNMPv1/v2 is used. [SNMPv3 - User name] The user name of SNMPv3 will be set.
  • Page 125: Register For Remote Monitoring [Service Status]

    [Setup via recorder's main monitor] [Location] Enter a location where the recorder is installed. (up to 255 alphanumeric characters) Characters that cannot be input: half-width symbols " " " Example: 2F [Contact] Enter the contact information such as a mail address of an administrator of this recorder. (up to 255 alphanumeric characters) Characters that cannot be input: half-width symbols "...
  • Page 126 [Setup via recorder's main monitor] [Unregister for remote monitoring] Unregister the product from remote monitoring. [Update the service status] Click the [Update] button to update the registration status of the cameras connected and displayed in [Service Status] to the latest information. [Service status] Displays the registration status of each connected camera for remote monitoring.
  • Page 127 [Setup via recorder's main monitor] Register the product to the remote monitoring. Before carrying out registration, check the following: ● Check that the product is connected to the Internet from [Internet connection status]. When "Not connected" is displayed, connect the product to the Internet. ●...
  • Page 128: Configure The Settings Relating To The User Management [User Management]

    [Setup via recorder's main monitor] Click the [OK] button to register this product with the remote monitoring. Note: If the registration fails, check the following: ● Is the remote monitoring connected? ● Do you have a remote monitoring account? ● Is the email address/password for the remote monitoring account entered correctly? ●...
  • Page 129 [Setup via recorder's main monitor] ■ Operation Configure the settings to enable auto login when turning on the recorder. [Auto login] Select "On" or "Off" to determine whether or not to activate the auto login function. On: Logs in to the recorder automatically. Off: Does not log in to the recorder automatically.
  • Page 130 [Setup via recorder's main monitor] Off: User name needs to be entered. Default: Off [Auto logout] Set the time to wait until auto logout when no operations are made while displaying live images. Off: Does not logout to the recorder automatically. After 1 min/ After 3 mins/ After 5 mins/ After 30 mins Default: Off Note:...
  • Page 131 [Setup via recorder's main monitor] operating certain functions, do not check the respective function. The setting for the administrator cannot be changed. The system can also be set up to allow only live operation (image switching) after logout. Note: ● Only a user logged in as "Administrator/Manager" can change the user level settings.
  • Page 132 [Setup via recorder's main monitor] * Even if "Setup" is set to be available to each user, there will be some operations restricted to the administrator only. * If the user level is not displayed for the camera image, it is recommended that the "Copy" operation among same user level will not be allowed.
  • Page 133 [Setup via recorder's main monitor] Register, edit or delete the user information [User registration] Use this tab to register, edit or delete user names and passwords. ■ Register new user Register user information such as a user name, password and operation level. The maximum number of users that can be registered is 32.
  • Page 134 [Setup via recorder's main monitor] Important: ● For enhanced security, change the password on a regular basis. ● Do not reuse passwords on other recorders or devices. ● If you forget the administrator name and the password, the recorder must be initialized (repair).
  • Page 135 [Setup via recorder's main monitor] View/Operate: Enables display of live/recorded images and camera operation. View: Enables display of live/recorded images, but disables camera operation. Off: Disables display of live/recorded images and camera operation. Note: ● Camera operation is not available when "Camera control" is limited in "User level settings"...
  • Page 136 [Setup via recorder's main monitor] [Delete] button Deletes the selected user. Edit the administrator information [Administrator setup] The administrator information relating to the password and default screen, etc. can be registered on this tab. [Administrator name] Enter the administrator name using the on-screen keyboard. The administrator name must be between 1-32 characters including the half-width alphanumeric and the symbol excluding "...
  • Page 137 [Setup via recorder's main monitor] Important: ● For enhanced security, change the password on a regular basis. ● Do not reuse passwords on other recorders or devices. [Password (Retype)] Enter the password that has been set for "Password" again for confirmation. [Level] Display the operation level of an administrator.
  • Page 138 [Setup via recorder's main monitor] ■ Register new host Register the host information that uses the recorder such as the host IP address and the operation level. Up to 32 hosts can be registered. [Host IP address] Enter the IP address in IPv4 format. ●...
  • Page 139: Configure The Settings Relating To Maintenance [Maintenance]

    [Setup via recorder's main monitor] Since the parameters differ depending on the model, refer to the following section for details. Advanced setup ☞ Default: Cam.1 [Registration] button Registers the set host information as a new. ■ Edit host information Change or delete the registered host information. Select a host information to change or delete on [Host IP address].
  • Page 140 [Setup via recorder's main monitor] * This is an example screen of NX410. Note: ● System information will not be updated while the "Maintenance" page is being displayed. ● The actual line speed will be displayed in "( )" of the "Line speed" column. ●...
  • Page 141 [Setup via recorder's main monitor] ■ System device information Extension unit information (EXT) [NX410/NX510] Displays the version information of the extension unit, temperature information and recovery progress information. Click [View >] button to display the following screen. Note: ● The recovery progress information is displayed during the mirroring recovery or the RAID recovery.
  • Page 142 [Setup via recorder's main monitor] [Software] Displays the software version of the camera. [SD card model number] Displays the model number of the SD memory card used for the camera. [Operation time] Displays the operation time of the SD memory card used for the camera. [Overwrite time] Displays the number of the overwriting of the SD memory card used for the camera.
  • Page 143 [Setup via recorder's main monitor] Confirm the hard disk drive information [HDD information] Capacity of the hard disk drive and the running time of this product, time range of the recorded images, etc. will be displayed. * This is an example screen of NX410 in single mode. Note: ●...
  • Page 144 [Setup via recorder's main monitor] [Operation mode of HDD] Operation mode of HDD will be displayed. Refer to the following section for further information. ☞ About the setup of HDD operation mode [Capacity] Displays the capacities of the hard disk drives. [Operation] Displays the operating time of the hard disk drives.
  • Page 145 [Setup via recorder's main monitor] Note: ● While overwriting recording is being performed, the overwriting cycle will be calculated based on the date & time of the oldest recorded data and that of the newest recorded data. ● The more often the recording was performed in the past, the more accurate the calculation of overwriting cycle will be.
  • Page 146 [Setup via recorder's main monitor] * Example above shows the screen for single mode. [Capacity] Displays the capacity of HDD. [Remaining capacity] Displays remaining capacity of HDD. Note: ● Remaining capacity displayed does not include capacity used to manage data. Therefore, the displayed HDD capacity is less than the actual amount. ●...
  • Page 147 [Setup via recorder's main monitor] ■ HDD Maintenance Set a password for the HDD viewer, format and remove HDDs. Click the [Setup >] button for HDD maintenance. [Set password for HDD viewer] Set whether you will assign a password to the HDD mounted on the recorder. Setting it to "On"...
  • Page 148 (NX_HDD_Viewer.zip). Unzip the file to use it. The operating instructions of HDD viewer are available on our following website. https://i-pro.com/global/en/surveillance/documentation_database [Format HDD] Select a HDD to format and click the [Start] button to format the HDD.
  • Page 149 [Setup via recorder's main monitor] Important: ● HDDs in recording cannot be selected. If the HDD stand-by control mode is On, a HDD following the HDD in recording also cannot be selected. If the operation mode of HDDs is the mirroring mode, one of the two HDDs in recording may be removed.
  • Page 150 [Setup via recorder's main monitor] Note: ● Refer to the following section for how to reset the error. Cancel the error action ☞ [Error buzzer duration] Configure the settings to sound a buzzer at an error occurrence. When "0 s" is selected, buzzer will not sound.
  • Page 151 [Setup via recorder's main monitor] ● It may take time to play the data in the inactive HDD during the HDD stand-by control mode. ● During the HDD stand-by control mode, the date will not be displayed in white on the calendar of the date and time operation panel even if there isa recorded image.
  • Page 152 [Setup via recorder's main monitor] Note: ● If you change [Time adjustment] from Off to On on the [NTP/SNMP] tab on the "Network" page, the time before adjustment will be set on the camera. If you want to set the time, execute [Synchronize the camera's time with this unit] under [Other].
  • Page 153 [Setup via recorder's main monitor] ■ Logs The following logs can be checked. ● Access log: Logs of accessing the recorder ● Operation log: Logs of operating the recorder ● Network log: Logs of network errors To check each log, click the [View >] button. Note: ●...
  • Page 154 [Setup via recorder's main monitor] ** indicates a user name or an IP address. About the operation log The operation log displays specific operations of the recorder and their dates and time in a list. Up to 500 logs are saved. When more than 500 logs are filed, the older logs will be overwritten by the newer logs.
  • Page 155 [Setup via recorder's main monitor] to the following section for further information about the error logs. Error logs ☞ ■ Functions for maintenance License is added to operate the recorder. In addition, settings and operations are also performed for maintenance of the recorder. [Registration of license (This product, camera extension, etc.)] To use the recorder, it is necessary to obtain the "Registration Key"...
  • Page 156 [Setup via recorder's main monitor] The setting values for the past three days are stored as of 2:10 a.m. every day. If the setting has not been changed from the most recent setting at that time, it will not be saved. Select the date and time of the settings you wish to restore, then click the [Execute >] button to do so from the confirmation screen that appears.
  • Page 157 [Setup via recorder's main monitor] Note: ● The following setting items will not be reset to the default or loaded or restored. • HTTP port number • Network port • DNS Setup • License number • Operation mode of HDD •...
  • Page 158 [Setup via recorder's main monitor] ■ Entry information of the key management system This is the ID number required to obtain the "Registration Key". The Activation Key Card provided with the recorder describes how to access the key management system. ■...
  • Page 159 [Setup via recorder's main monitor] No Registration Key Registration Key 1 Registration Key 2 [NAS backup function - Registration Key] To use the NAS backup function, enter the "Registration Key" that can be obtained from the Key Management System. Refer to the following section for more details. NAS backup function ☞...
  • Page 160 [Setup via recorder's main monitor] [Synchronize the camera's time with this unit] Time and date of all the registered cameras will be synchronized with the clock of this product. The time and date synchronization will be executed when the setting is completed after executing on the confirmation window displayed by clicking the [Execute] button.
  • Page 161 [Setup via recorder's main monitor] [Reboot this product] Reboots the recorder. [Boot this product in the board replacement mode.] Used to replace the board. Note: ● The board replacement mode is used during maintenance. Do not use it in ordinary operation. ●...
  • Page 162: Manage The Hard Disk Drives [Hdd Management]

    [Setup via recorder's main monitor] Note: ● Measurement is made from about 8 seconds after setting is done and will continue measuring for 10 seconds. ● Status display area of operation screen will display " Measuring" while measuring. ● The result of measurement is the sum of all network ports. ●...
  • Page 163 [Setup via recorder's main monitor] Click the [OK] button after entering "Administrator name" and "Password" of an administrator. → The "HDD management" page will be displayed. Click the [Operation] button to return from the "HDD management" page to the operation screen.
  • Page 164 [Setup via recorder's main monitor]...
  • Page 165 [Setup via recorder's main monitor] Check the hard disk drive information [General] Displays the HDD capacity, operating time, date and time range of recorded images, etc. of this recorder and extension units. Refer to the following section for further information about the items displayed on the [HDD information] tab.
  • Page 166 [Setup via recorder's main monitor] → The window to format hard disk drives will be displayed.   STEP2 Check the HDDs to format in the "Format" field, and click the [Start] button. To start formatting, click the [OK] button on the confirmation window displayed. In Mirroring mode or RAID5/RAID6 mode, check each pair of HDDs.
  • Page 167 [Setup via recorder's main monitor] Click [Execute >] on the [Remove HDD]. → The HDD removing screen will be displayed. STEP2 Check the HDDs to remove and click the [Start] button to display the password confirmation window for the HDD viewer. When the entered value and the setting match, the HDD is removed.
  • Page 168 [Setup via recorder's main monitor] STEP2 Check the HDDs to add, and click the [Start] button. The process is completed when "OK" is displayed in the "Results" field and the HDDs are ready for recording. Click the [Back] button. Important: ●...
  • Page 169 [Setup via recorder's main monitor] like HDD1 and HDD2, HDD3 and HDD4. When one of the 2 HDDs is replaced with a new one, it is possible to copy data on the other HDD to the replaced HDD. This product or the extension unit requires 2 or more HDDs.
  • Page 170 [Setup via recorder's main monitor] [Change the operation mode of HDD] Select the desired operation mode of HDD, and then click the [Start] button. Important: ● When the operational mode of HDD is changed (except the case that the operational mode is changed from the Mirroring mode to the Singlemode), all data on the HDDs will be erased.
  • Page 171 [Setup via recorder's main monitor] Set the recording group [Recording group setup] You can set two groups of recording period and assign each camera to either one.Also, you can set a HDD used for recording of each group. STEP1 Click the [Execute >] button on the [Recording group setup]. →...
  • Page 172 [Setup via recorder's main monitor]  Unlimited/ 1 day/ …/ 10 days/ 14 days/ 30 days/ 31 days/ 45 days/ 60 days/ 62 days/ 90 days/ 92 days/ 120 days/ 123 days/ 150 days/ 153 days/ 180 days/ 184 days/ 365 days/ 366 days/ 730 days/ 731 days Default: Unlimited Note:...
  • Page 173 [Setup via recorder's main monitor] STEP6 Set the recording group of each HDD in a way that the HDD capacity displayed at the top of the screen exceeds the estimated required capacity. Note: ● In Mirroring mode, it is possible to set the recording group for each pair of two HDDs like HDD 1 and HDD 2 and HDD 3 and HDD 4.
  • Page 174 [Setup via recorder's main monitor] → The following screen of [Change the recording order] will be displayed. STEP2 Change the recording order and click the [Start] button. When the change of the recording order has completed, the screen indicating that the change is in progress will be closed. STEP3 Click the [Back] button to finish the change.
  • Page 175: Configure The Security Settings [Security]

    [Setup via recorder's main monitor] Configure the security settings [Security] Set the security settings on the security function page of [Advanced setup] on the setup menu. The "Security" page has [Communication], [Data encryption] and [Advanced setup] tabs. Important: ● A secure communication kit (option) is required to use the data encryption function.
  • Page 176 [Setup via recorder's main monitor] ■ Security between this product and PC Connect the recorder and the PC with the HTTPS. The HTTPS encodes the access to the recorder and enhances the safety of the communication. [Connection] Set the connection. HTTP &...
  • Page 177 [Setup via recorder's main monitor] ● Cameras whose part number is "RTSP" or "RTSP(FE)" may not be able to connect via HTTPS, depending on the camera used. [Connection] Set the connection method between this product and the camera. Clicking the [Settings>] button will open the "Change connection"...
  • Page 178 [Setup via recorder's main monitor] [Setup transmission] Select the camera to which you want to send the settings. Confirm the cameras to which you want to send the configured connection method. Setup of the data encryption [Data encryption] Set whether to encrypt images on the camera. Important: ●...
  • Page 179 [Setup via recorder's main monitor] [Setup of the data encryption] Configure the data encryption. Clicking the [Settings>] button will open the "Change data encryption" window, where you can change the settings. After changing the settings, click the "OK" button to save the settings and close the window. ■...
  • Page 180 [Setup via recorder's main monitor] [Compression] Displays the compression of the image data to be encrypted. Note: ● Cameras whose image compression is set to H.265(1), H.264(1) or MJPEG to use the data encryption. If the image compression is set to H.265(3), H.265(4), H.264(3) or H.264(4), the recorder cannot communicate with the camera.If the image compression is set to MJPEG, some cameras may not support the data encryption.
  • Page 181 [Setup via recorder's main monitor] * The black screen may not contain the key mark.    Please perform the following operation in order to continue the playback.  Playback using the main monitor   ①Pressing the left button of the mouse on the black screen (with the key mark) long displays a screen for entering a password to decrypt the image.
  • Page 182 [Setup via recorder's main monitor] Configure the advanced settings [Advanced setup] Set whether to operate the server installed in this recorder. [NTP Server] Set whether to operate the NTP server. On: Operate the NTP server Off: Do not operate the NTP server Default: On [HTTP/HTTPS Server] Set whether to operate the HTTP/HTTPS server.
  • Page 183: Configure The Settings Relating To The Extra Functions [Extra Function]

    [Setup via recorder's main monitor] Configure the settings relating to the extra functions [Extra function] Set the NAS backup function and Failover function settings on the extra function page of [Advanced setup] on the setup menu. Refer to the following pages for each function. Addendum ☞...
  • Page 184 [Setup via recorder's main monitor] Setting item (including those of the Available range Default "Advanced setup" menu) Set time zone GMT-12:00, GMT-11:00,   GMT-10:00, GMT-9:00, GMT-8:00, GMT-7:00, GMT-6:00, GMT-5:00, GMT-4:30, GMT-4:00, GMT-3:30, GMT-3:00, GMT-2:00, GMT-1:00, GMT, GMT+1:00, GMT+2:00, GMT+3:00, GMT+3:30, GMT+4:00, GMT+4:30, GMT+5:00, GMT+5:30, GMT+5:45, GMT+6:00,...
  • Page 185 [Setup via recorder's main monitor] Date/Language > Date & time adjustment Setting item (including those of the Available range Default Rema "Advanced setup" menu) Date & Time 2022/1/1 0:00 - 20nn/mm/1 0:00 ●◎ 2046/12/31 23:59 ("nn" and "mm" are calculated base on the serial number of the recorder.) Date/Language >...
  • Page 186 [Setup via recorder's main monitor] Date/Language > Language Setting item (including those of the Available range Default Rema "Advanced setup" menu) Language Japanese/ English/ Français/ English (Web ◎ Español/ Deutsch/ Italiano/ browser: English) Português/ ไทย / Tiếng Việt/ 简 体中文/ 繁體中文 (Web browser: Japanese/ English/ Français/ Español/ Deutsch/ Italiano/ Português/ Thai/...
  • Page 187 [Setup via recorder's main monitor] Camera > Camera setup Setting item (including those of the Available range Default Rema "Advanced setup" menu) Date & time display Display (check box) Checked/Not checked     Display (drop-down list) Off, On     Position (check box) Checked/Not checked  ...
  • Page 188 [Setup via recorder's main monitor] Camera > Camera setup (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Camera selection Checked/Not checked     Pan/tilt-flip Pan/tilt-flip Off, On     Camera selection Checked/Not checked    ...
  • Page 189 [Setup via recorder's main monitor] Camera > Camera setup (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Detection sensitivity 1(Low), 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13,     individual camera 14, 15(high) setup)
  • Page 190 [Setup via recorder's main monitor] REC & event > Recording setup (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Schedule1 Time table1 Schedule bar --:--, 00:00 - 24:00 Schedule bar   Schedule to record 00:00 - 24:00 Schedule bar...
  • Page 191 [Setup via recorder's main monitor] REC & event > Recording setup (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) 24:00 Schedule bar 2 - Schedule bar 6: --:-- - --:-- Time table1- Checked/Not checked Checked ◎...
  • Page 192 [Setup via recorder's main monitor] REC & event > Recording setup (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Schedule2 - Days to record (Mon, Tue, ..., Time table1, Time table2, Off Time table1 ◎...
  • Page 193 [Setup via recorder's main monitor] REC & event > Recording setup (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Time table2- Checked/Not checked Checked ◎ Event recording Time table2- Checked/Not checked Not checked ◎ e-Mail Time table2- Checked/Not checked...
  • Page 194 [Setup via recorder's main monitor] REC & event > Recording setup (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Image capture size When the aspect ratio is 4:3 HVGAW ◎ VGA(640×480)/ SVGA(800×600)/ (640×360) SXVGA(1280×960)/ UXGA (1600×1200)/ QXGA(2048×1536)/ 5M(2560×1920)/ 7M(3072×2304) When the aspect ratio is 16:9...
  • Page 195 [Setup via recorder's main monitor] REC & event > Recording setup (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Emergency 1 ips, 3 ips, 5 ips, 10 ips, 12.5 ips, 15 Same as the ◎...
  • Page 196 [Setup via recorder's main monitor] REC & event > Event setup (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Setup by terminal (Recording Off, Cam.1, ..., Cam.n, All Terminals 1 ◎ camera) to 4: Same camera number as...
  • Page 197 [Setup via recorder's main monitor] REC & event > Event setup (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Setup by command number (Text Input) CMD1, ..., ◎ (Name) CMD128 REC & event > Advanced setup Setting item (including those of the Available range Default...
  • Page 198 [Setup via recorder's main monitor] REC & event > Advanced setup (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Message ID 000 to 255, --- No.1: 50, ◎ No.2: 51, No.3: 52, No.4: 56, No.5: 98, No.6: 99, No.7: 100,...
  • Page 199 [Setup via recorder's main monitor] Advanced setup Monitor > Main monitor Setting item (including those of the Available range Default Rema "Advanced setup" menu) Camera title Display Off, On ◎ Position L-Upper, L-Lower, R-Upper, R-Lower R-Upper ◎ Camera title (Text will be entered.) CAM1, …, ◎...
  • Page 200 [Setup via recorder's main monitor] Monitor > Main monitor (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Checked/Not checked Not checked ◎ screen (unequal division) 3-screen Checked/Not checked Not checked ◎ (mixed ratio) 4-screen Checked/Not checked Not checked ◎...
  • Page 201 [Setup via recorder's main monitor] Monitor > Main monitor (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Switch to 1-screen display Checked/Not checked Checked ◎ when playing from alarm log Monitor > Sub monitor Setting item (including those of the Available range Default...
  • Page 202 [Setup via recorder's main monitor] Monitor > Web browser (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Grouping G1、G2、G3、G4、G5、 Cam.1 - Cam.16: G1 G6、G7、G8 Cam.17 - Cam.32: G2 Cam.33 - Cam.48: G3 Cam.49 - Cam.64: G4 Cam.65 - Cam.80: G5 Cam.81 - Cam.96: G6 Cam.97 - Cam.112: G7...
  • Page 203 [Setup via recorder's main monitor] Network > Basic (continued) Setting item (including those of the Available Default Rema "Advanced setup" menu) Subnet mask (IP address) 0.0.0.0 ◎ Network Setup Network settings (IP address) 192.168.0.1 ◎ DNS Setup Off, Manual, Auto ◎...
  • Page 204 [Setup via recorder's main monitor] Network > e-Mail Setting item (including those of the Available range Default Rema "Advanced setup" menu) e-Mail setup SMTP server address (Text will be entered.) (Blank) ◎ SMTP port number (Port No.) ◎ POP server address (Text will be entered.) (Blank) ◎...
  • Page 205 [Setup via recorder's main monitor] Network > HTTP alarm (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) HDD/Recording error Checked/Not checked Checked ◎ Network error Checked/Not checked Checked ◎ Network > NTP/SNMP Setting item (including those of the Available range Default Rema...
  • Page 206 [Setup via recorder's main monitor] User management > Basic (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Auto login user (Select from the (Administrator) ◎ registered user names.) Quick login Off, On ◎ Auto logout Off, After 1 min, After 3 ◎...
  • Page 207 [Setup via recorder's main monitor] User management > Basic (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Alarm reset Checked/Not checked Manager: (Checked, ◎ Fixed) Operator: Checked Viewer: Not checked Logged out: (Not checked, Fixed) Error reset Checked/Not checked Manager: (Checked,...
  • Page 208 [Setup via recorder's main monitor] User management > User registration (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Default screen* [NX310] 4Screen ◎ Cam.1, ..., Cam.32, 4Screen(1), ..., (Wide view) 4Screen(8), 9Screen(1), ..., 9Screen(4), 16Screen(1), 16Screen(2), Sequence(Wide view), 1screen(Wide view), 4Screen(Wide view), 6Screen(Wide view),...
  • Page 209 [Setup via recorder's main monitor] User management > User registration (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Camera partitioning Common setting, Individual setting Common ◎ setting Camera partitioning View/Operate, View, Off View/Operate ◎ (Individual setting) User management >...
  • Page 210 [Setup via recorder's main monitor] Maintenance > System information (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Communication speed (Indication only) (Indication only) ◎ (PC port) Current PoE total power supply (Indication only) (Indication only) ◎...
  • Page 211 [Setup via recorder's main monitor] Maintenance > HDD information (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Remove HDD (HDD number) (HDD number) ◎ Maintenance > System management Setting item (including those of the Available range Default Rema...
  • Page 212 [Setup via recorder's main monitor] Maintenance > System management (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Network log (Date & (Indication only) (Indication ◎ Time / Log) only) Entry information of MPR ID (None) (Unique ◎...
  • Page 213 [Setup via recorder's main monitor] Maintenance > System management (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Acquire the SD backup (None) (None) ◎ data from camera Reboot this product (None) (None) ◎ Boot this product in the [NX310] Single mode ◎...
  • Page 214 [Setup via recorder's main monitor] HDD management > General Setting item (including those of the Available range Default Rema "Advanced setup" menu) HDD information Capacity (Indication only) (Indication only) ◎ Operation (Indication only) (Indication only) ◎ Status (Indication only) (Indication only) ◎...
  • Page 215 [Setup via recorder's main monitor] HDD management > General (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) HDD information (Add) Checked/Not checked Not checked ◎ HDD information (Indication only) (Indication only) ◎ (Results) Change the HDD information (Indication only) (Indication only)
  • Page 216 [Setup via recorder's main monitor] HDD management > General (continued) Setting item (including those of the Available range Default Rema "Advanced setup" menu) Group2 Unlimited, 1 day, …, 10 Unlimited ◎ days, 14 days, 30 days, 31 days, 45 days, 60 days, 62 days, 90 days, 92 days, 120 days, 123 days, 150 days, 153 days,...
  • Page 217 [Setup via recorder's main monitor] Security > Data encryption Setting item (including those of the Available range Default Rema "Advanced setup" menu) Data encryption setting * Off, On ◎ * When registering the secure communication kit (option) license. Security > Advanced setup Setting item (including those of the Available range Default...
  • Page 218: About The Error Logs And The Network Logs

    [Setup via recorder's main monitor] Extra function > Failover Setting item (including those of the Available range Default Rema "Advanced setup" menu) Failover setup Off (not monitoring), Off (not monitoring) ◎ On (monitoring) Setup of recorder Address (Indication only) (Indication only) ◎...
  • Page 219 [Setup via recorder's main monitor] Description Display of the Error log Front LCD Display Output from status display panel connector Thermal error Thermal error: MAIN Thermal error: MAIN MAIN-t ERR Recorder error warning Thermal error: EXTx Thermal error: EXTx THERMAL ER ROR EXTx ERR...
  • Page 220 [Setup via recorder's main monitor] Description Display of the Error log Front LCD Display Output from status display panel connector NW camera error Communication Communication NW ERR Camera error detection (video) error: Cam.cc error: Cam.cc CAMERAcc   ERROR NW camera error – Video communication –...
  • Page 221 [Setup via recorder's main monitor] Description Display of the Error log Front LCD Display Output from status display panel connector SMART warning SMART warning: SMART warning: MAIN-y ERR [NX310] MAIN-y MAIN-y HDD error / SMART WARN SMART warning: SMART warning: ING Recording EXTx-y EXTx-y error...
  • Page 222 [Setup via recorder's main monitor] Description Display of the Error log Front LCD Display Output from status display panel connector Remove auto links HDD removed: HDD logically MAIN-y ERR [NX310] (per HDD) MAIN-y removed: MAIN-y HDD error / HDD REMOVED HDD removed: HDD logically Recording EXTx-y...
  • Page 223 [Setup via recorder's main monitor] Description Display of the Error log Front LCD Display Output from status display panel connector HDD read error – Read error: MAIN-y – – Parameter – Invalid unit: MAIN – MAIN ERR initialization error Invalid unit: EXTx INITIAL ERR...
  • Page 224 [Setup via recorder's main monitor] Description Display of the Error log Front LCD Display Output from status display panel connector Mirroring 1down RAID1 1down: RAID1 1down: MAIN-y,y E HDD error [NX410/NX510] MAIN-y,y MAIN-y,y RR RAID1 1down: RAID1 1down: RAID1 1DOWN EXTx-y,y EXTx-y,y EXTx-y,y E...
  • Page 225 [Setup via recorder's main monitor] Description Display of the Error log Front LCD Display Output from status display panel connector Starting mirroring – Starting mirroring MAIN-y,y – recovery recovery: MAIN-y,y RAID1 R-ST Starting mirroring ART recovery: EXTx-y,y EXTx-y,y RAID1 R-ST ART Starting RAID5 –...
  • Page 226 [Setup via recorder's main monitor] Description Display of the Error log Front LCD Display Output from status display panel connector Complete RAID5 – Complete RAID5 MAIN – recovery recovery: MAIN RAID5R-COM [NX410/NX510] Complete RAID5 PLETE recovery: EXTx EXTx RAID5R-COM PLETE Complete RAID6 –...
  • Page 227 [Setup via recorder's main monitor] Description Display of the Error log Front LCD Display Output from status display panel connector RAID6 Recovery RAID6 Recovery RAID6 Recovery MAIN ERR HDD error failure failure: MAIN failure: MAIN RAID6 R-FA [NX410/NX510] RAID6 Recovery RAID6 Recovery ILURE...
  • Page 228 [Setup via recorder's main monitor] Description Display of the Error log Front LCD Display Output from status display panel connector When time is not Skip time adjustment Skip time adjustment NW ERR – adjusted due to the NTP ADJUST time difference of  ...
  • Page 229 [Setup via recorder's main monitor] Description Display of the Error log Front LCD Display Output from status display panel connector Other error: HTTP – Other error: HTTP – Network error alarm address alarm Undetected sub Undetected sub Undetected sub – ERR...
  • Page 230 [Setup via recorder's main monitor] Description Display of the Error log Front LCD Display Output from status display panel connector Camera SD memory SD undetected: [SD]undetected: CAMERAcc Camera error card undetected Cam.cc Cam.cc SD CARD ERR OR Camera SD memory SD capacity [SD]capacity –...
  • Page 231 [Setup via recorder's main monitor] Description Display of the Error log Front LCD Display Output from status display panel connector Failover (Alternative – Failover: Recorder-m - - operation) Rollback startup Rollback Rollback Recorder error ERR (startup with spare ROLLBACK software) Starting remote –...
  • Page 232 [Setup via recorder's main monitor] Description Network log Output from connector Failed to find SMTP server <SMTP>SMTP_SVR_ERR Network error MAIL FROM command error <SMTP>MAIL_FROM_ERR Network error RCPT TO command error <SMTP>RCPT_TO_ERR Network error Other errors for SMTP <SMTP>OTHER_ERR Network error Synchronization with the NTP server complete <NTP>GET_TIME_OK –...
  • Page 233: [Operation Via Recorder's Main Monitor]

    [Operation via recorder's main monitor] [Operation via recorder's main monitor] Before operation Operation window The recorder can be operated using the included mouse connected to the mouse connection port on the recorder. When operating the recorder using a web browser, refer to "[Setup Network]".
  • Page 234 [Operation via recorder's main monitor] ① Image display area Displays images from the camera. Monitor live images ☞ ② Status display panel Displays the statuses of the recorder. Also displays alarm/error status and remedies. ☞ Main monitor (A monitor to display the live image, the playback image and the setup menu) ③...
  • Page 235 [Operation via recorder's main monitor] ② Status display panel Displays the statuses of the recorder. Also displays alarm/error status and remedies. Main monitor (A monitor to display the live image, the playback image and the setup ☞ menu) When clicking alarm button or error button, this panel may be displayed overlapped on the operation panel.
  • Page 236 [Operation via recorder's main monitor] The number of images that can be displayed on the multiscreen differs for the control screen and the wide view screen. Note: ● It is possible to select whether to display or hide the wide view multi- screen selection button.
  • Page 237 [Operation via recorder's main monitor] ☞ Register, edit or delete the user information [User registration] Note: ● If the default screen other than "Cam.1" - "Cam.128" is selected, the default screen of the web browser on the PC will automatically display 1-screen display for Cam.1.
  • Page 238 [Operation via recorder's main monitor] ① Status display area Recorder status indications and their details are shown in the table below. In the event that the recorder enters several statuses at the same time, these are displayed in their order of priority. If both statuses have the same priority, the one that occurred last will be displayed.
  • Page 239 [Operation via recorder's main monitor] Indicate that an alarm has occurred. Turn red in the alarm state. Clicking the buttons will toggle between displaying/not displaying buttons such as the alarm log button and the alarm reset button.   ④ Error button ...
  • Page 240 [Operation via recorder's main monitor] Sub monitor (monitor for display of live images only) Important: ● Configuration and operation of the recorder from the sub monitor is not possible. Live images from the specified cameras can be displayed on 1-screen or multiscreen on the sub monitor, or camera images will be switched sequentially at the selected switching interval (sequence display).
  • Page 241: Basic Operations

    [Operation via recorder's main monitor] Basic operations To operate, use the mouse connected to the recorder to move the mouse cursor displayed on the main monitor and left-click the buttons or tabs displayed on the screen. (Hereinafter, "Left-click..." will be described as "Click..." in this document.) In lines where the [▲]/[▼] buttons are displayed, the value on which the cursor is placed can be changed by turning the mouse wheel.
  • Page 242: Login Operation At Startup

    [Operation via recorder's main monitor] Note: ● If "On" is selected for the "Auto login", login will be automatically performed by the user registered in "Auto login user" in the logged-out state. Refer to the following section for "Auto login". Configure the settings relating to the user management [User ☞...
  • Page 243 [Operation via recorder's main monitor] ● Refer to the following section for how to register users. Register, edit or delete the user information [User registration] ☞ Note: ● When "On" is selected for "Quick login", the user name can be selected from the pull-down menu.
  • Page 244: View

    [Operation via recorder's main monitor] Note: ● The administrator is not registered when the recorder is purchased. Enter an administrator name, a password and the password retyping following the instruction on the display and click [Registration] as "Administrator registration" screen is displayed on the main monitor when you first launch the recorder.
  • Page 245 [Operation via recorder's main monitor] It is possible to display live images on a 1-screen or on a multiscreen. Depending on the configuration of the sub monitor, the cameras can automatically be switched and images from the cameras can be displayed on 1-screen or multiscreen. ☞...
  • Page 246 [Operation via recorder's main monitor] About the operation panel Operations with live images differ depending on whether they are performed on the control screen or on the wide view screen. Control screen / Operation panel ① Multiscreen buttons The buttons switch the number of split screens in the image display area. ②...
  • Page 247 [Operation via recorder's main monitor] ⑤ Camera number tab : Displays the camera number panel to display. ⑥ Camera number panel Camera number: (Character color) White: Camera is registered. Gray: Camera is not registered. (Background color) Aqua: Image display area is displaying images Blue: Camera is registered and image display area is not displaying images.
  • Page 248 [Operation via recorder's main monitor]   Gray: Camera is not registered.   Red: Event recording is being performed. ● [NX510] When the camera number tab "1-64" and "65-128" is pressed, the camera number panel will not display camera title, and will only display camera number and recording indicator.
  • Page 249 [Operation via recorder's main monitor] Note: ● It is possible to hide/display the multi-screen selection buttons on the operation panel. Refer to the following section for further information. Set up the main monitor [Main monitor] ☞ ● When 5 or more multi-screen selection buttons are displayed, it is possible to switch the position of displayed buttons using the left/right buttons or the slider.
  • Page 250 [Operation via recorder's main monitor] ・Play in browser ・Perform mobile playback of smartphone applications Change the camera display position on the screen The default camera display positions are as follows: *64-screen can be selected for NX410/NX510. It is possible to change the camera image by dragging & dropping the number of the camera number panel onto the desired display position.
  • Page 251 [Operation via recorder's main monitor] Note: ● When a camera is assigned to a screen segment to which another camera is already assigned, the image of the camera originally assigned to that position will disappear. ● The assigned camera position is retained even if the recorder is rebooted (note however that initializing the settings will also reset the camera positions to the defaults).
  • Page 252 [Operation via recorder's main monitor] [No sub-monitor display, no re-encoding transmission] (continued) Multiscreen Image capture size QXGA display HVGAW(640×360)~ 1.4M(1200×1200)~ (2048×1536)~ 9M(2992×2992) SXVGA(1280×960) FHD(1920×1080) 4KUHD (3840×2160) 9-screen to 16-screen display, × × ○ ○ 9-screen sequence, 16-screen sequence 24-screen to ×...
  • Page 253 [Operation via recorder's main monitor] Sub monitor Multiscreen display Image capture size HVGAW(640×360)~ SVGA(800×600)~ QXGA(2048×1536)~ 0.4M(640×640) FHD(1920×1080) 9M(2992×2992) 1-screen display, 1-screen sequence, ○ ○ ○ 4-screen sequence (4K monitor connection) 4-screen display (1080p ○ ○ × monitor connection) 9-screen, 16-screen display, 24-screen, 32-screen, 9-screen ×...
  • Page 254 [Operation via recorder's main monitor] [No sub-monitor display, no re-encoding transmission] (continued) Multiscreen Image capture size QXGA display HVGAW(640×360)~ SVGA(800×600)~ (2048×1536)~ 9M(2992×2992) 0.4M(640×640) FHD(1920×1080) 4KUHD (3840×2160) 5-screen to 7-screen display, 4-screen sequence ○ ○ *1 ○ *2 × (1080p monitor connection) 9-screen to 16-screen display,...
  • Page 255 [Operation via recorder's main monitor] [Sub-monitor display available] (continued) Multiscreen Image capture size QXGA display HVGAW(640×360)~ SVGA(800×600)~ (2048×1536)~ 9M(2992×2992) 0.4M(640×640) FHD(1920×1080) 4KUHD (3840×2160) 5-screen to 16-screen display, 4-screen sequence (1080p monitor × × × ○ connection), 9-screen sequence, 16-screen sequence 24-screen to ○...
  • Page 256 [Operation via recorder's main monitor] [Re-encoding transmission available] (continued) Multiscreen Image capture size QXGA display HVGAW(640×360)~ SVGA(800×600)~ (2048×1536)~ 9M(2992×2992) 0.4M(640×640) FHD(1920×1080) 4KUHD (3840×2160) 5-screen to 24-screen display, 4-screen sequence (1080p monitor × × × ○ connection), 9-screen sequence, 16-screen sequence 32-screen ○...
  • Page 257 [Operation via recorder's main monitor] Multiscreen display Image capture size HVGAW(640×360)~ SVGA(800×600)~ QXGA(2048×1536)~ 0.4M(640×640) FHD(1920×1080) 9M(2992×2992) 9-screen, 16-screen display, 9-screen × × ○ sequence, 16-screen sequence 24-screen, 32-screen ○ *2 × × *1 If the frame rate setting for recording exceeds 30 ips, the display will follow the refresh interval set for the camera.
  • Page 258 [Operation via recorder's main monitor] Note: ● Clicking the [Wide view] button again will switch to the multiscreen displayed before. 1-screen display Live images from cameras can be displayed on a 1-screen. Displaying images on a control screen Step 1 When displaying in a multi-screen, click the 1-screen button of the "Multiscreen select".
  • Page 259 [Operation via recorder's main monitor] ● At the default, black zones will be displayed on the top and bottom of images with the aspect ratio of 16:9. Refer to the following section for the setting to enlarge the vertical size of displayed images. Set up the main monitor [Main monitor] ☞...
  • Page 260 [Operation via recorder's main monitor] → Live images from cameras will be displayed on a multi-screen. Displaying images on a control screen ● 4-Screen button 4-screen display includes the currently selected camera. Each time the button is clicked, the display switches between four screens: Cam.1 - 4 → Cam.5 - 8 → Cam.9 - 12 →...
  • Page 261 [Operation via recorder's main monitor] Displaying images on a wide view Step 1 Click one of the [Multiscreen select] buttons. → Live images from cameras will be displayed on a multiscreen.   [Multiscreen select] button of the wide view screen Note: ●...
  • Page 262 [Operation via recorder's main monitor] (when displaying on the 4-screen, select the camera whose image is to be zoomed) Step 2 Click the digital zoom buttons → The displayed image will be enlarged ×1, ×1.25, ×1.50, ×1.75, ×2, ×2.5, ×3, ×3.5, ×4, ×5, ×6, ×7, ×8 centering on the center point of the screen.
  • Page 263 [Operation via recorder's main monitor] Click of the image during zoom display changes the center to the clicked position. Note: ● The magnification is displayed around the camera title during the zoom display. If the camera title is not displayed, the zoom magnification will not be displayed.
  • Page 264 [Operation via recorder's main monitor] ■4-Screen PTZ display Fisheye correction display button Note: ● Double-click of the right mouse button on the fisheye image can correct the image and display on the 1-Screen PTZ centering the cursor position. ● Click on the image during the 1-Screen PTZ correction display can change the center to the clicked position.
  • Page 265: Operate The Camera

    [Operation via recorder's main monitor] operating the buttons on the camera control panel. Camera control panel ☞ ● Double-click on the image during the 4-Screen PTZ correction display can switch the screen to the 1-Screen PTZ correction display (and vice versa). ●...
  • Page 266 [Operation via recorder's main monitor] image by clicking it in the image display area. Control buttons ( ① ) Move (pan/tilt) the camera in the clicked direction. Keeping the button pressed will move the camera continuously. [Zoom] button Adjusts the zoom factor. [Home position/Call] button Move the camera to the home position.
  • Page 267 [Operation via recorder's main monitor] turning the mouse wheel even when the checkbox is checked. Use digital zoom ☞ [Detail] button Display the "Camera control [Advanced]" panel, and perform any of the following camera operations. [Focus] button Adjust the focal point. [Brightness] button Adjusts the lens iris of the camera.
  • Page 268 [Operation via recorder's main monitor] [AUX] button Sets the device connected to the AUX terminal of the camera to the open/closed state. If the camera is a network camera, AUX1, 2 and 3 is controlled with only AUX1 of the camera.
  • Page 269 [Operation via recorder's main monitor] [Back] button Closes the "Camera control [Advanced]" and returns to the camera control panel. Note: ● Controlling the camera is not possible on the wide view screen or 9-screen/16-screen display. Camera operation is as follows. Note: ●...
  • Page 270 [Operation via recorder's main monitor] Functi Function Description Operation Pan/Tilt Adjusts the horizontal/ Click the control button on the camera control panel. Also, if you vertical position of the have checked "Operate camera with mouse", when you click the camera image. position in the camera image that you want to use as the center of the angle of view, the direction of the camera moves to center on the clicked position.
  • Page 271 [Operation via recorder's main monitor] Functi Function Description Operation in advance in the camera, starting with the lowest preset number. ● Patrol: Performs the operations recorded in advance by the camera. Note Set the Auto mode in the camera menu before use. Preset Registers the current Perform pan/tilt operations on the advanced camera control panel to...
  • Page 272 [Operation via recorder's main monitor] Functi Function Description Operation ● Low-speed: Continuous wiping operation. (once every 8 seconds) ● Temporary control: Performs 5 wiping operations at high speed (once every 4 seconds). ● Washer: Performs the specified washer/wiper operation. Note ●...
  • Page 273 [Operation via recorder's main monitor] Functi Function Description Operation Mask Sets the mask area of the Click the [Set] button on the advanced camera control panel. When area camera. you click the [Start] button in [Mask area] on the displayed camera setup setup screen, a grid-like boundary line is displayed in the image display area, and the squares set as the mask area become white and...
  • Page 274: Event Function

    [Operation via recorder's main monitor] Event function About event function The recorder will take an event action when any of the following events occur. ● Terminal alarm: An event when an alarm input signal is supplied from an external device such as a door sensor to the alarm input terminal on the rear of the recorder.
  • Page 275 [Operation via recorder's main monitor] Event action Description Mode*1 Alarm Move the camera to the Move the camera to the preset position registered in ● ● × action preset position advance. Blink the alarm indicator The alarm indicator on the front panel will start blinking. ×...
  • Page 276 [Operation via recorder's main monitor] ×: takes no action *2 When "On" is selected for the "Additional alarm data" setting of the camera, i-VMD type information will be displayed in the alarm log. For further information, refer to the operating instructions of the camera in use. *3 The extension software alarm is displayed by name.
  • Page 277 [Operation via recorder's main monitor] ● The alarm indicator on the front panel will stop blinking and light steadily. ● The alarm status display on the main monitor will disappear. ● The sounding buzzer and the alarm output will stop. Step 1 Click the [Alarm] button displayed on the main monitor, and click the alarm [Reset] button.
  • Page 278: Record

    [Operation via recorder's main monitor] Record Record images Live images can be recorded on the recorder. The image of 4 to 16 cameras can be recorded in the recorder. Record images (Schedule recording) Recording can be automatically started and stopped according to a previously specified schedule.
  • Page 279 [Operation via recorder's main monitor] on the hour. In that moment, recording may sometimes be interrupted around for 1 second. Recording mode and its priority There are 4 recording modes. The recording modes and their priority levels are as follows. When two or more recordings with different recording modes started simultaneously, only recording with the higher priority will start.
  • Page 280: Play

    [Operation via recorder's main monitor] Step 2 The emergency recording will automatically be terminated when the recording time set for the emergency recording is over. Set the recording time of emergency recording at "Recording time of emergency recording" of "REC & event" - "Advanced setup" tab on the setting menu. Configure the advanced settings for recording and events [Advanced setup] ☞...
  • Page 281 [Operation via recorder's main monitor] Note: ● Images can be played on 1-screen and 4-screen in the control screen. ● Images can be played back on 1-screen to 4-screen in the wide view. ● The audio of the displayed image is output on 1-screen display and the audio of the selected camera is output on multi-screen display of the control screen.
  • Page 282 [Operation via recorder's main monitor] [No sub-monitor display, no re-encoding transmission] Multiscreen display Image capture size HD(1280×720) FHD(1920×1080) 1-screen, 2-screen display (N/A) 3-screen, 4-screen display 30 ips [Sub-monitor display or re-encoding transmission available] Multiscreen display Image capture size HD(1280×720) QXGA(2048×1536)~ FHD(1920×1080) 4KUHD(3840×2160) 1-screen display...
  • Page 283 [Operation via recorder's main monitor] Image playback status Playback pause status Wide view playback status (Image playback Wide view playback status (Playback pause status) status) Wide view playback status (Minimized mode, Wide view playback status (Minimized mode, playback pause status) image playback status) Click the minimizing button on the playback operation panel in the wide view playback...
  • Page 284 [Operation via recorder's main monitor] Function Example Operation Captured image button Saves images paused during playback on USB medium.* Clickable only while playback is paused on a 1-screen. Click to save the file. Remove the USB media after saving is complete.
  • Page 285 [Operation via recorder's main monitor] Function Example Operation Next record/Previous Clicking the next record button will play back the next later record button recording. Clicking the previous record button will play back the next earlier recording. When there is no next/previous recorded image to be skipped to, the current playback will continue.
  • Page 286: Play Images From A Designated Point

    [Operation via recorder's main monitor] Play images from a designated point It is possible to start playback from a designated date & time or the latest recorded image. Play image recorded at a designated date & time Start playback by designating the date & time of a recorded image on the date & time operation panel.
  • Page 287 [Operation via recorder's main monitor] Note: ● Unless you want to change the date & time on the calendar, click the playback button. Step 4 To stop playback and return to live images, click the [Live] button or the stop button on the playback operation panel.
  • Page 288 [Operation via recorder's main monitor] The date & time operation panel will change to playback display. At the same time, the playback operation panel is displayed at the bottom of the date & time operation panel. Playback by designating a timeline  ☞...
  • Page 289 [Operation via recorder's main monitor] Date & time operation panel (playback display) In the playback display, the presence or absence of recording and its type are displayed on the timeline (③). It is possible to change the type of recorded images displayed on the timeline, change the timeline scale, and designate the recorded image to play.
  • Page 290 [Operation via recorder's main monitor] be paused.) Periods for which no recorded images are available will be displayed in black. Note: ● To display motion detection information, a camera that supports the function of adding motion detection information is required. For more information about this function, refer to the Operating Instructions of the camera.
  • Page 291 [Operation via recorder's main monitor] [Advanced setup] button Display the advanced setup panel and change event types and other information displayed on the timeline. Playback will be paused. [Scale selection] button ( ① ) Select a timeline display covering 2 hours (2 h), 8 hours (8 h) or 24 hours (24 h). [Display range selection] button ( ②...
  • Page 292 [Operation via recorder's main monitor] Change event types and other information displayed on the timeline [Advanced setup] [Event type] Set event types to be displayed on the timeline. To display event-recorded images on a timeline, mark their checkboxes. Refer to the following section for further information about each alarm. Action to be taken upon an event occurrence ☞...
  • Page 293: Search And Play

    [Operation via recorder's main monitor] [Back] button/[×] button Click this button to return to the date & time operation panel (playback display). Search and play Search a desired recorded image and play it. There are the following 3 searching methods. ●...
  • Page 294 [Operation via recorder's main monitor] Note: ● Up to 1000 alarm logs are saved. When more than 1000 logs are filed, the older logs will be overwritten by the newer logs. In this case, the oldest log is the first to be overwritten.
  • Page 295 [Operation via recorder's main monitor] Note: ● Up to 1000 error logs are saved. When more than 1000 logs are filed, the older logs will be overwritten by the newer logs. In this case, the oldest log is the first to be overwritten. Step 3 Select the line with the desired list, and click the playback button on the playback operation panel.
  • Page 296 [Operation via recorder's main monitor] "Pre-event duration" setting is longer than 5 seconds, click the playback button, and then click the previous record button. ● If no recorded image is available for 5 seconds from the date & time, image will be played from the date & time. Step 4 To stop playback and return to live images, click the stop button on the playback operation panel.
  • Page 297 [Operation via recorder's main monitor] Step 2 Select a camera that you want to search on the camera number panel. Step 3 Designate a date and time for the start date and time (Start). Set the "Start" using the [▲]/[▼] buttons of the date and time. Step 4 Assign the display interval of thumbnails.
  • Page 298 [Operation via recorder's main monitor] Note: ● It may take time to display all thumbnails. ● The date and time display until thumbnails are displayed is a provisional date and time calculated from the starting date and time and the display interval.
  • Page 299 [Operation via recorder's main monitor] Note: ● You can start the playback by double-clicking a thumbnail that you want to play back. Step 7 To stop playback and return to live images, click the stop button on the playback operation panel.
  • Page 300 [Operation via recorder's main monitor] Step 2 Select a camera that you want to search on the camera number panel. Step 3 Designate the time range to search. Set the year, month, day and time of the start and end point by clicking the respective [▲]/ [▼] buttons.
  • Page 301 [Operation via recorder's main monitor] [Change list size] button (①) Displays/Hides the list. Note: ● Up to 100 logs are displayed in the list. When more than 100 logs are filed in the search result, "> 100" will be displayed. ●...
  • Page 302 [Operation via recorder's main monitor] ☞ Playback operation panel → Playback will start from the date & time selected. Note: ● Playback can also be started by double-clicking the desired date & time line. Step 6 To stop playback and return to live images, click the stop button on the playback operation panel.
  • Page 303 [Operation via recorder's main monitor] [Designate the search range] Designate the time range to search. → Set the "Start" and "End" by clicking [▲]/[▼] button of the date and time respectively.   [Detection area setup] Click 2 points of the upper left and lower right to create a square to be set as the area on the displayed image.
  • Page 304 [Operation via recorder's main monitor] Note: ● As the detection areas will be set up to match the image display area divided into 16×16 segments, the top left and bottom right detection areas may not be exactly as designated. ● It is impossible to delete the detection area that has been set. To change the area, re-set the detection area.
  • Page 305: Useful Functions

    [Operation via recorder's main monitor] Useful functions Copy recorded images Copy the recorded image on the recorder to an external storage device (external HDD, USB memory stick) or NAS. In this document, external storage devices are also referred to as media.Refer to the following section for the details of copying with the NAS (NAS backup function).
  • Page 306 [Operation via recorder's main monitor] set for copying. ● Copying of recorded images may sometimes be performed incorrectly when there exist 2 or more images recorded at the same date & time resulting in change of the date & time setting or the auto time adjustment function.
  • Page 307 [Operation via recorder's main monitor] Note: ● The copy panel cannot be displayed in the web browser when it has already been opened by another user. When copying is already underway, the copying window will be displayed. ● If the NAS setup has been completed on the recorder, the copy destination of the copy panel becomes the pulldown display and USB or NAS can be selected.
  • Page 308 [Operation via recorder's main monitor] Item Description Camera selection Check the number of the camera whose recorded data is to be copied. Checking [All] will copy the recorded data of all cameras. Data & Time range Specify times and dates to define the range for copying recorded data. Set the year, month, date &...
  • Page 309 [Operation via recorder's main monitor] remaining volume, it means that over 10000 of recorded data exists as target. Note: ● Images recorded in H.264 or H.265 can be copied in MP4 format. If audio is recorded in AAC-LC, the image is copied in MP4 format with audio. ●...
  • Page 310 [Operation via recorder's main monitor] Step 5 Enter the password using on-screen keyboard, and then click the [Next] button. → The copy start confirmation window will be displayed. ● Enter 5 to 8 alphanumeric characters for a password. ● To confirm the password, enter the same password again into the "Retype password" column.
  • Page 311 [Operation via recorder's main monitor] → Switches to the copying window and displays copying progress. Important: ● Do not disconnect the external storage device when copying is being performed. Otherwise the data stored on the external storage device could be lost. ●...
  • Page 312 [Operation via recorder's main monitor] Step 7 Once the copying process is completed, the copy complete window will be displayed. Click the "Close" button and remove the external storage device. Format USB medium USB medium recognizable by the recorder can be formatted by the recorder. Important: ●...
  • Page 313 [Operation via recorder's main monitor] Step 3 Click the [Execute] button for "Format USB medium". → The confirmation window will be displayed. Step 4 Click the [OK] button. → Formatting of the USB medium will start, and a window indicating that formatting is in progress will be displayed.
  • Page 314: Play Back Copied Images With This Recorder

    [Operation via recorder's main monitor] Play back copied images with this recorder Display recording images copied to the external storage device (copy data) on the list, select among them and playback. It is possible to search for copied data using filters. Important: ●...
  • Page 315 [Operation via recorder's main monitor] Note: ● When copying large amounts of data, more time is needed to display the list. ● Original format (n3r/n3a) and MP4 format files can not be displayed on the list at the same time. ●...
  • Page 316 [Operation via recorder's main monitor] Filter by designating date & time Specify the filter range by designating a date & time. To specify the filter range, set the year, month, day and time of the start and end point by clicking the respective [▲]/[▼] buttons.
  • Page 317: List Of Operation Items

    [Operation via recorder's main monitor] device or the recording content. Retry again later if you fail in operation. ● If you play multiple data files continuously, the audio may not be synchronized. In this case, pause and then restart playback. Step 6 To stop playback and return to live images, click the stop button on the playback operation panel.
  • Page 318 [Operation via recorder's main monitor] Top items: Live image display (continued) Middle Bottom items Details Remarks Main Browser items body * The setup of the sub monitor - - monitor is possible, but the actual image on the sub monitor ○...
  • Page 319 [Operation via recorder's main monitor] Top items: Camera operation (continued) Middle Bottom items Details Remarks Main Browser items body Preset position Register camera   ○ ○ preset positions Move camera   ○ ○ preset positions Move to home   ○ ○...
  • Page 320 [Operation via recorder's main monitor] Top items: Recording Middle items Bottom Details Remarks Main Browser items body Record images (schedule - -   ○ ○ recording) Top items: Search/ Playback Middle Bottom items Details Remarks Main Browser items body Play Playback operation Playback  ...
  • Page 321 [Operation via recorder's main monitor] Top items: Search/ Playback (continued) Middle Bottom items Details Remarks Main Browser items body Play back recorded -   images by × ○ designating in REC & event list Play images -   selected from alarm ○...
  • Page 322: [Setup Network]

    [Setup Network] [Setup Network] Configure the network settings The recorder can be operated using a mouse or from a web browser on a PC (excluding certain functions and settings). On the following pages, operation from a web browser, setting up the PC and related matters will be described.  ...
  • Page 323 [Setup Network] address". If a DHCP server is connected to the network environment, the product uses the IP address automatically obtained from the DHCP server. The acquired IP address can be found in the settings menu - [Maintenance] - [System information] tab. The settings described in these operating instructions are based on the standard settings for Windows 7.
  • Page 324 [Setup Network] Step 2 Click "View network status and tasks". → The "Network and Sharing Center" window will be displayed. Step 3 Click "Local Area Connection".
  • Page 325 [Setup Network] → The "Local Area Connection Status" window will be displayed. Step 4 Click [Properties] → The "Local Area Connection Properties" window will be displayed. Step 5 Click "Internet Protocol Version 4 (TCP/IPv4)", and then [Properties].
  • Page 326 [Setup Network] → The "Internet Protocol Version 4 (TCP/IPv4) Properties" window will be displayed. Step 6 Select [Use the following IP address] and set "IP address" and "Subnet mask" as follows: ・ IP address: 192.168.0.9 ・ Subnet mask: 255.255.255.0...
  • Page 327: Network Security Of The Recorder

    [Setup Network] Depending on the network configuration, it is necessary to configure "Default gateway". Contact the system administrator for further information about the settings. Step 7 Click the [OK] button and close the window. Network security of the recorder The security function of the recorder ①...
  • Page 328: Enhance Network Security

    [Setup Network] Important: ● Image data, authentication information (user name, password), alarm mail information, etc. may be leaked over the network. Take measures such as restricting access through user authentication. ● After accessing this product as an administrator, be sure to close all web browsers to strengthen security.
  • Page 329 [Setup Network] enhance the network security. [Connection example]...
  • Page 330: [Operation Via Pc Web Browser]

    [Operation via PC web browser] [Operation via PC web browser] Before operation Display the operation window Boot the PC and operate the recorder using a web browser. Step 1 Start the web browser.   Step 2 Enter the IP address or URL assigned to the recorder into the address box, and then press the [Enter] key.
  • Page 331 [Operation via PC web browser] protected with this connection" may appear, but HTTPS communication is possible. Step 3 Enter the user name and password registered in the recorder, and then click the [Login] button. → The top page will be displayed. Important: ●...
  • Page 332: About The Operation Window

    [Operation via PC web browser] About the operation window Top Page [Control] tab Displays operations such as searching for and copying recorded images, search results and log information. [Cam. select] tab Can be used for switching camera images. [Setup] tab Can be used to configure the settings of the recorder.
  • Page 333 [Operation via PC web browser] ① Status display area The current status of the recorder such as playback status, recording status, etc. will be displayed. ② Current time display area The current date & time will be displayed. ③ [Wide view] button Displays the camera's live and playback images on the entire screen.
  • Page 334 [Operation via PC web browser] [Search] box Use this button to search recorded images. The search result will be displayed in the list display area. ● [REC event] button Select [HDD] for "Disk/Medium" to display this button. The recording event search window will be displayed.
  • Page 335 [Operation via PC web browser] Displays the copy window. Use this button to copy the recorded images to an external storage device. List display area Total: Displays the total number of listed data. No.: The number will be displayed in the order of occurrence. Date &...
  • Page 336 [Operation via PC web browser] Camera selection box ( ① ) Clicking the camera title will display images from the selected camera on a 1-screen in the image display area. Setting the [Group display] of [Monitor] - [Web browser] to "On" enables the group display of cameras.
  • Page 337 [Operation via PC web browser] [Date/Language] button Displays the "Date/Language" page. Perform settings such as date & time and daylight saving time. [Camera] button Displays the "Camera" page. Perform registration of network cameras. [REC & event] button Displays the "REC & event" page. Configure the settings relating to the recording schedules and alarms.
  • Page 338 [Operation via PC web browser] Register for the remote monitoring and check the service status. [User management] button Register, edit or delete the user information. The administrator information can also be changed. [Maintenance] button Displays the system information of the recorder. It is used for initialization of settings and firmware update.
  • Page 339 [Operation via PC web browser] : Indicates that downloading of recorded images/audio is completed.   Indicates the playback speed. : Normal playback speed (1x) : Approx. 2x playback speed : Approx. 4x playback speed : Approx. 8x playback speed : Approx. 16x playback speed : Approx.
  • Page 340 [Operation via PC web browser] Error button [ERR] This button will be displayed when an error occurs. The error action will be canceled by clicking this button. Note: ● Once an emergency recording starts, it will not stop even by clicking the [ALM] button.
  • Page 341: View

    [Operation via PC web browser] [HDD] tab Playback camera images recorded on the HDD of this product. Refer to "Play recorded images" for operation. Play recorded images ☞ View Monitor live images Live images will be displayed in the web browser window on a 1-screen. It is possible to display live images to expand the image display area across the full screen.
  • Page 342 [Operation via PC web browser] displayed. In this case, close the browser and start it again. ● If the frame rate setting is changed between scheduled recording, event recording, emergency recording, or between pre-recording and event recording, the live image may not be displayed smoothly if the frame rate is switched during the live image display.
  • Page 343: Operate The Camera

    [Operation via PC web browser] Note: ● Clicking the [Go to last] button on the [HDD] tab while displaying live images will start playback from a point around 30 seconds before the latest recorded image of the camera currently being displayed. Depending on the recording settings, images may be played back more than 30 seconds before.
  • Page 344 [Operation via PC web browser] Function Function Description Operation Zoom The camera image Click the [-] button or the [+] button. Click the [×1] button to will be enlarged or return the zoom magnification to 1×. compressed in the display. Focus Adjusts the focus of Click the [Far] or [Near] button.
  • Page 345 [Operation via PC web browser] Function Function Description Operation AUX operation The device connected Select "AUX" as the operation mode and click the [▼] button to to the AUX terminal select the AUX terminal number. of the camera is set to ●...
  • Page 346: Event Function

    [Operation via PC web browser] Event function About event function The recorder will take an event action when any of the following events occur. Terminal alarm: An event when an alarm input signal is supplied from an external device such as a door sensor to the alarm input terminal on the rear of the recorder.
  • Page 347 [Operation via PC web browser] Display the alarm button The [ALM] button will be displayed in the status display area. The alarm action will be canceled by clicking [ALM] button. ☞ Cancel the alarm action Display the error button The [ERR] button will be displayed in the status display area. The error action will be canceled by clicking [ERR] button.
  • Page 348: Play

    ● The maximum number of browser connections that can play simultaneously is two. The number of connections includes the number of mobile regenerations of the i-PRO Mobile APP smartphone application. When two browsers are running, a user at the same level cannot run a third browser.
  • Page 349 [Operation via PC web browser] Step 2 Click the [Play] button. → Playback of a recorded image will be performed. The "Playback" indication and the "Step 1" indication will be displayed on the status display area. Playback will start from the point at which the last playback was stopped (date & time). Step 3 Click the [Stop] button on the [HDD] tab.
  • Page 350 [Operation via PC web browser] than 30 seconds before. ● When load to be processed is too heavy for the recorder (such as when many cameras are connected, images (live/playback) are displayed on many windows (segments)), playback speed may become slow or playback may stop for a while.
  • Page 351 [Operation via PC web browser] Function Example Operation [FF]/[FR] button ● Playback speed of fast playback will be changed in the following order each time the [FF] button is clicked: Step2 (Approx. ×2) → Step3 (Approx. ×4) → Step4 (Approx. ×8) →...
  • Page 352: Play Image Recorded At A Designated Date & Time

    [Operation via PC web browser] Function Example Operation [Go to last] button ● When this button is clicked, playback of the latest recorded images will start. The starting point is around 30 seconds before the date & time of the latest recorded images. While recording, the playback starts 30 seconds prior to the current time.
  • Page 353: Search And Play Recording Events (Rec Event Search)

    [Operation via PC web browser] ☞ About playback operation Note: ● When playing H.264/H.265 image by designating date & time, playback may start from a point several seconds before or after the designated date & time. ● When no recorded image found at the designated date & time, playback of images recorded after and at the closest to the designated date &...
  • Page 354 [Operation via PC web browser] Step 2 Specify the search conditions (filters). [Date & time range] Select a time range by designating a start and end date & time. The designated time range will be searched. [REC event] Searches for images recorded by the selected recording mode only. Check the checkbox corresponding to the desired event type.
  • Page 355 [Operation via PC web browser] Command alarm [COM]: Recording triggered by a command alarm Camera site alarm [CAM]: Recording triggered by camera site alarm Emergency [EMR]: Recording triggered by the emergency recording event SD backup rec. [SD]: Recording by the SD memory backup function Extension software alarm [SW1~SW16]: Record by extension software alarm Note: ●...
  • Page 356 [Operation via PC web browser] [Total] Displays the total number of searched data. When more than 10001 data matched, the "> 10000" indication will be displayed. [All list] button Cancels filtering and displays all recording events. [Refresh] button Updates the list to the latest one. [Prev page (<)] button Displays the previous page of the list.
  • Page 357: Useful Functions

    [Operation via PC web browser] [Cam] The camera which recorded the images will be displayed. [Evt] Event type will be displayed. Search and play recording events (REC event search) ☞ [HDD] The hard disk drive number in which the corresponding recorded images are stored will be displayed.
  • Page 358 [Operation via PC web browser] Refer to the following section for the details of copying with the NAS (NAS backup function) NAS backup function ☞ Step 1 Click the [Control] tab on the top page of the operation window. Top Page ☞...
  • Page 359 [Operation via PC web browser] [Camera] Select the camera you wish to copy. Mark the checkbox next to the desired camera. When the checkbox for [All] is marked, the checkboxes of all cameras can be marked. [Date & time range] Designate the start point (start date &...
  • Page 360 [Operation via PC web browser] [Password] To copy with password protection, mark the corresponding checkbox and enter 5 to 8 alphanumeric characters for the password. However, passwords cannot be assigned to MP4 files. The password will be required to play back the copied data. [Data size] When the [Measurement] button is clicked, size of the data to be copied will be displayed.
  • Page 361: Check A List Of Copied Recorded Images

    [Operation via PC web browser] become unusable. ● Recorded images (data) of up to 1 million can be copied onto the external device connected to the copy port "COPY". However, it is impossible to copy any more data exceeding these limits even when there is a sufficient remaining capacity.
  • Page 362 [Operation via PC web browser] → The copy data search window will be displayed.   Step 4 Specify the search conditions (filters). [Camera] Searches for images recorded with each selected camera. Mark the checkbox corresponding to the desired camera. When the checkbox for [All] is marked, the checkboxes of all cameras can be marked.
  • Page 363 [Operation via PC web browser] [Total] Displays the total number of searched data. When more than 10001 data matched, the "> 10000" indication will be displayed. [All list] button Cancels filtering and displays all recording events. [Refresh] button Updates the list to the latest one. [Prev page (<)] button Displays the previous page.
  • Page 364: Download Recorded Images Currently Being Played

    [Operation via PC web browser] [Date] Start time of recording will be displayed. [Cam] The camera number of the recorded data will be displayed. [Format] Displays a file format. Important: ● Do not remove the external storage device during playback of the list of copied data.
  • Page 365 [Operation via PC web browser] Click the [HDD] tab on the top page of the operation window. Top Page ☞   Step 2 Play back the recorded images. Click the [Start] button in the download operation area at the playback point where the download is to start.
  • Page 366 [Operation via PC web browser] However, passwords cannot be assigned to MP4 files. When the setting is completed, click the [OK] button. → The file download will be started. Note: ● Images recorded in H.264 or H.265 can be downloaded in MP4 format. If audio is recorded in AAC-LC and "With audio"...
  • Page 367: Play Back The Copied/Downloaded Images On A Pc

    [Operation via PC web browser] when the camera is registered. Refer to the Operating Instructions of the camera for the refresh cycle settings. Play back the copied/downloaded images on a PC The original file or MP4 file is copied to the destination when the playback image is copied or downloaded.
  • Page 368 [Operation via PC web browser] Important: ● When using the viewer software on more PCs than the number of connected cameras, a license is required for each PC. Refer to your dealer for the software licensing. Note: ● The license agreement window will be displayed when you first launch the viewer.
  • Page 369 [Operation via PC web browser] ④Search box ⑤List display area Select playback images Step 1 Click the button. → The "Open" window will be displayed. Note: ● When you run the executable file copied to the external storage device, the file open window will be automatically displayed.
  • Page 370 [Operation via PC web browser] way to clear the list is to right-click the list and select [Clear all list]. ● Image data after 2038 cannot be played back. Playback downloaded images Use the playback operation button to play downloaded images. If the same camera channel is displayed on the list, the next list image in playback mode or the previous list image in reverse playback mode will be played back consecutively.
  • Page 371 The fast playback speed may be limited depending on the performance of the PC in use or process status. Plays the fisheye image of the fisheye network camera (made by i-PRO or Panasonic, hereinafter called "fisheye camera") When you select a fisheye image which can be corrected, the image will be corrected and displayed on 1-screen PTZ/4-screen PTZ.
  • Page 372 [Operation via PC web browser] Adjust the volume When the audio data is available, a button to adjust the audio will be displayed. Adjusts the volume. Clicking the button can switch the volume in three levels. Toggles Audio playback/Silent. If the audio is controlled or adjusted by another application, the audio may not be played correctly on the viewer software.
  • Page 373 [Operation via PC web browser] Designate the folder name and destination drive and click the [Save] button. → Starts saving the image data and displays results once the saving has been completed. Print the displayed image Print the image displayed in the image display area. : Prints the image on pause with the date and time.
  • Page 374: [Setup On Browser]

    [Setup on browser] [Setup on browser] Setup Basic operations Step 1 Click the [Setup] tab. Step 2 Click the button for the desired menu.
  • Page 375: Configure The Settings

    [Setup on browser] Step 3 Click the button for the desired submenu.   Step 4 Configure each setting item. Click the [Set] button after completing the settings. → The settings will be applied. When moving to another page without clicking the [Set] button, the configured settings will be canceled.
  • Page 376 [Setup on browser] and their further information. Lists of the setting items (Setup menu) ☞ Set the web browser [Web browser] Set the settings related to the display of the web browser such as a group title of the camera. Click the [Monitor] button on the setup menu and then click the [Web browser] tab.
  • Page 377 [Setup on browser] [Group title] Enter a group title to display for each group (G1 ~ G8)(within 16 characters). [Grouping] Assign the camera to each group (G1 ~ G8). Configure the ONVIF setup Click the [Setup>] button of "ONVIF Setup" in [Camera] - [Advanced Setup] tab to display a...
  • Page 378: Update The Firmware

    [Setup on browser] menu related to ONVIF connections. Normally there is no need to change the default settings. Do not normally use it. Display data output logs Click the [View>] button of [Data output logs] in [Maintenance] - [System administration] to check the history of users who have copied or downloaded data.
  • Page 379 [Setup on browser] Step 3 Designate the downloaded firmware by clicking the [Browse...] button of "Firmware update".   Step 4 Click the [Execute >] button. → The confirmation window will be displayed to start the update procedure. Note: ● [NX410/NX510] Depending on the firmware to be updated, it may take up to 30 minutes for upgrading, leaving the start screen displayed.
  • Page 380: Others

    Others Others Notification by e-mail Alarm mail The recorder address are indicated in an alarm mail as follows.   Contents of the alarm mail (example) In NWDR (192.168.0.250), alarm was occurred. Occurrence date and time: xxxx-xx-xx xx:xx:xx GMT+xx:xx (Example. 2023-10-18 12:00:00 GMT+9:00) Alarm descriptions: Alarm descriptions, camera channel or alarm number will be described.
  • Page 381 Others EXTx THERMAL ERROR   Fan error: MAIN FANz ERROR   EXTx FANz ERROR   NW camera error detection: CAM ccc COMMUNICATION ERROR     NW camera error recovery: CAM ccc COMMUNICATION RECOVERED NW camera error detection (audio): CAM ccc COMMUNICATION ERROR(AUDIO)  ...
  • Page 382 Others MAIN RAID5 FORMAT ERROR   MAIN RAID6 FORMAT ERROR   EXTx-y SINGLE FORMAT ERROR   EXTx-y,y FORMAT ERROR     EXTx RAID5 FORMAT ERROR EXTx RAID6 FORMAT ERROR     RAID1 1down [NX410/NX510]: MAIN-y RAID1 1 DOWN   EXTx-y RAID1 1 DOWN RAID5 1down [NX410/NX510]: MAIN-y RAID5 1 DOWN  ...
  • Page 383 Others EXTx RAID5 RECOVERY FAILURE   RAID6 Recovery failure [NX410/ MAIN RAID6 RECOVERY FAILURE   NX510]: EXTx RAID6 RECOVERY FAILURE   Copy media FULL: COPY MEDIUM FULL   Number of data on the copy medium OVER LIMITATION ON COPY MEDIUM  ...
  • Page 384: Addendum

    Others Failover (Alternative operation): FAILOVERSWITCHED TO RECORDER-m   Rollback: ROLLBACK   Addendum NAS backup function This section provides an explanation of how to use the NAS backup function with this recorder. Professional knowledge and experience with the NAS are required for the operation of the NAS backup function.
  • Page 385 Others ● For the data copied to the NAS, it is not possible to playback on the recorder. Also, it is not possible to display the list of backup data on the recorder or the PC web browser. Playback the backup data with viewer software.
  • Page 386 Others [NAS backup] On: Enables the NAS backup function. Off: Disables the NAS backup function. Default: Off [Selection of storage destination] Check the storage destination used for backup. When two storage destinations are set, the backup will be written to the other storage destination once the remaining capacity of the initial storage destination during backup runs out.
  • Page 387 Others ■ Schedule setup of the NAS backup Click the [Setup >] button to set cameras to be backed up, a file format and a schedule. Configure the schedule settings ☞ ■ Schedule setup of the NAS backup [Current backup status] Displays the storage destination connection status.
  • Page 388 Others [Recording date and time when the backup was interrupted.] Displays the time range that could not be backed up. [Log] Displays the reason why the backup could not be done.  Not backed up yet (No remaining capacity) : The remaining capacity of the storage destination ran out during backup.
  • Page 389 Others [Camera] Check cameras to be backed up. [File format] Select a file format used for saving. Original (n3r/n3a) / MP4 Default: Original (n3r/n3a) [Time (indication) required for backup one day’s data] Displays the indication time. When you click the [Refresh] button, the indication time at the point will be re-displayed. Note: ●...
  • Page 390 Others [Backup execution date] Select a day to be backed up. 1 day before / 2 days before / 3 days before Default: 3 days before Note: ● The backed up data is saved in the schedule backup directory. ● If power to the recorder is turned off and then resumed while the backup process is being executed, any data backed up before the power was turned off will be backed up again from the beginning.
  • Page 391 Others Select [NAS (Storage-1)] or [NAS (Storage-2)] as the copy destination of the copy panel, and click the [Copy] button.Refer to the following section for the details. Copy recorded images ☞ ■ Operation via PC web browser Click the [Control] tab on the top page of the operation window, then click the [Copy] button of the copy box.
  • Page 392: Failover Function

    Others Select [NAS (Storage-1)] or [NAS (Storage-2)] as the copy destination of the copy panel and click the [OK] button, then click the [OK] button when the confirmation window is displayed. → The data copy window will close. Copying will start and the "COPY" icon will be displayed in the status display area.
  • Page 393 Others recorder)substitutes for the recorder in operation (master recorder) and continues recording if the master recorder has an error. Explanation of the failover operation ・ The slave recorder monitors the state of each master recorder. ・ If the master recorder has an error, the slave recorder stops operation of the master recorder.
  • Page 394 Others Important: ● The settings of the failover function are made for the slave recorder only. ● Up to 5 master recorders can be set for one slave recorder. ● The software versions of the slave recorder and master recorder must be same.
  • Page 395 Others Note: ● When the master recorder executes failover operation, the "Recording mode" setting will be turned to OFF. Set it to On to return to normal operation. About license registration Register the license of the failover function to use it. To register the options, the "Registration Key"...
  • Page 396 Others [Failover setup] Select the operational settings. On (monitoring): Master recorders are monitored to switch recording of the recorder if an error occurs. Off (not monitoring): The failover function is not used. Default: Off (not monitoring) [Registered information] Click the [Setup >] button to set the master recorders. Configure the settings of the monitoring target recorder ☞...
  • Page 397 Others Note: ● When the status indicates Not available, check the version and the number of licenses of the recorder and match them. ● The [Update] button can be clicked only when the failover operation is set to On. [Manually execute the failover] Select a recorder No.
  • Page 398 Others [Address] Enter the IP address of the recorder. [Administrator name] Enter the administrator name of the recorder. [Password] Enter the password of the recorder. [Table to delete] Select a recorder No. and click the [Delete] button to delete the recorder information.
  • Page 399: Troubleshooting

    Others Display in the failover mode During operation as the slave recorder, it can not perform recording, playback, camera operation and camera setting etc. Troubleshooting Before asking for repairs, check the symptoms with the following table. Contact your dealer if a problem cannot be solved even after checking and trying the solution in the table or a problem is not described below.
  • Page 400 Others Symptom Cause/solution Reference settings for schedule recording [Advanced schedule setup] Cannot play back ● Are there any recorded images on the hard disk drives? Check the ☞ images. Check if there are recorded images. hard disk drive information [General] ●...
  • Page 401 Others Symptom Cause/solution Reference ● Check if the user name and password has correctly been Change the ☞ entered on the setup menu - the "Advanced setup" menu - registered the [Camera] page - [Camera registration] tab. information [Registered information] The message ●...
  • Page 402 Others Symptom Cause/solution Reference command prompt as follows. >ping "IP address of this unit" If there is reply from this unit, the connection is normal. If not, check the settings of the IP address and the subnet mask. ● Is the same IP address provided to other devices? Configure ☞...
  • Page 403 Others Symptom Cause/solution Reference Cannot play the ● When any setting of the setup menu has been changed − downloaded during the download, the download will be canceled recorded images. automatically. In this case, the downloaded file is not a complete file and it is impossible to play it.
  • Page 404 Others Symptom Cause/solution Reference The live image or ● The PC memory may be insufficient. End the web browser and − the playback image unnecessary software, launch the web browser again and turns to the black then connect to the recorder. screen on the web browser.
  • Page 405 Others Symptom Cause/solution Reference Copying progress ● If the data of our network microphone is copied in original Copy ☞ can at times stop format, copying will continue even though progress remains recorded images for a while at 99.9 at 99.9 %, as the calculation error of the audio data is large. %, or jump from 70 Make sure to copy data to media with enough storage ~ 80 % to 100 %.
  • Page 406 Others Symptom Cause/solution Reference are not displayed target cameras in AI privacy guard settings, the H.264 (2) and registered on the monitor as H.265 camera resolutions become the same as those of H.264 information split screens, but (1) and H.265 (1). Accordingly, depending on the number of [Registered are displayed as split screens, live images may not be displayed or playback...
  • Page 407 Others Symptom Cause/solution Reference The thumbnail ● Check that the JPEG data encryption is not set to "On" in the − image of the camera setup menu. camera is displayed broken in the setup menu of the web browser. Camera settings do ●...
  • Page 408: Glossary

    Others Glossary Bit rate Indicates how many bits of data can be processed or transmitted in a unit of time. Generally, the units are in bps, or bits per second. Used to indicate the compression rate of video and audio data, and how much data a communications line can send and receive in 1 second.
  • Page 409 Others Fisheye correction This is a function to correct the fisheye image of our and Panasonic fisheye camera to a 1-screen PTZ or 4-screen PTZ image. Frame rate (ips) Refers to the unit that determines the smoothness with which the recorded images are played back.
  • Page 410 Others VMD (Motion detection) search The function that automatically detects motion in images. In this product, it is possible to search for date & time of motion detection in recorded images. Re-encoding transmission When playing back recorded images in a web browser, remote monitoring or application, this function re-encodes the recorded images to the resolution and frame rate supported by the respective application.
  • Page 411: Change History

    Change history Change history Ver 1.000.000 (Nov/01/2023) ・ First edition Ver 1.001.000 (Feb/13/2024) ・ Added DHCP related items to network log ・ Correction of errors...

Table of Contents
