Page 1
Model No. WJ-NX410K Series For professional use only WJ-NX510K Series refer to WJ-NX510K, WJ-NX510KG and WJ-NX510KGV. WJ-NX410K Series refer to WJ-NX410K, WJ-NX410KG and WJ-NX410KGV. Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.
Open the fuse cover with a screwdriver and replace the fuse and close or attach the fuse cover. For U.S.A. Supplier's Declaration of Conformity Figure A Figure B Trade Name: i-PRO Model No. : WJ-NX410K, WJ-NX510K Responsible Party: i-PRO Americas Inc. 8550 Fallbrook Drive, Suite 200 Houston, Texas 77064 Support Contact: 1-800-513-5417...
Contents Important Safety Information ....................2 Introduction ..........................4 Preface ...................................... 4 Features ....................................4 System requirements for a PC ..............................6 Trademarks and registered trademarks ............................ 6 About HEVC (High Efficiency Video Coding) patents ....................... 6 Copyright ....................................6 Disclaimer of warranty ................................
Introduction Preface The network disk recorders WJ-NX510K Series equipped H.265 CODEC and are designed for use within a H.265 surveillance system, and record images/audio from up to 64 network cameras (hereinafter, cameras) on the hard disk drives (HDDs). Number of cameras to be used in the system can be increased to 128 (maximum) by purchasing the Additional Camera Kit (WJ-NXE52W, WJ-NXE53W).
Page 5
Introduction (continued) MP4 download function Recorded camera images can be copied to USB media or downloaded to a PC in MP4 format. Third-party cameras can be connected ® In addition to our cameras, third-party ONVIF compatible cameras can be connected. Third-party cameras can also be connected via RTSP by specifying the URL.
(for viewing the manuals) Important: • Refer to our support website (https://i-pro.com/global/en/surveillance/training_support/support/technical_information) for information about the latest operation verification of the supported operating systems and web browsers. • If using a PC that does not meet the above system requirements, it may cause problems such as slow imaging or the browser becomes inoperable.
(continued) Disclaimer of warranty IN NO EVENT SHALL i-PRO Co., Ltd. BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW: (1) ANY LOSS OR DAMAGE, INCLUDING WITHOUT LIMITATION, DIRECT OR INDIRECT, SPECIAL, CONSEQUENTIAL OR EXEMPLARY, ARISING OUT OF OR RELATING TO THE PRODUCT;...
Precautions Refer installation work to the dealer. Grounding Installation work requires technique and experiences. Failure Use this product after confirming that grounding is properly to observe this may cause fire, electric shock, injury, or installed. damage to the product. If grounding is not installed properly, it may cause ground •...
Page 9
Precautions (continued) Precautions for use Power source Hard disk drive (HDD) The input power source for this product is 100 V - 240 V AC • Hard disk drives are precision devices. Handle them with 50 Hz/ 60 Hz. care. It is possible to damage them if they are moved Do not connect to the outlet that provides the power to while their motors are still running.
Page 10
Disclaimer of warranty on recoded data i-PRO Co., Ltd. assumes no responsibility or liability, directly or indirectly, for failure of recording or editing including loss of data due to any reason or cause which does not exclude repair or maintenance of this product regardless whether the subject is hard disk or other parts.
Major operating controls and their functions Front view ➀ ➁ ➂ ➃ ➄ ⑥ ⑦ ⑫ ⑧ ⑨ ⑩ ⑪ ① Error indicator [ERROR] ⑤ HDD access indicator [1]~[9] Blinks when an error that can become a problem for the It transmits the HDD status indicator and the HDD recorder to run the system occurs.
Page 12
Major operating controls and their functions (continued) ⑧ Copy port (USB3.0) [COPY] Connect an external storage device (external Hard disk drive, USB memory) to this port and copy images and audio recorded on the hard disk drive. An external storage device can also be connected to the copy port on the rear.
Major operating controls and their functions (continued) Inside the front cover The following illustration shows that 9 HDD units are installed with the "HDD unit holding brackets" removed. ➀ ➁ ➂ ➃ ➄ ⑥ ① HDD units [Option] Lights red: Indicates that the respective hard disk drive is faulty (which can be recovered by replacing the Only the hard disk drive encased in the dedicated hard hard disk drive)
Major operating controls and their functions (continued) Rear view ➀ ➁ ⑰ ➂ ⑯ ➃ ➄ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ① Alarm/Control connector ALARM/CONTROL ⑧ Clamp mount (for fixing USB cable) This connector is used when connecting with an external Fit the power cord clamp (included) to fix the USB cable.
Page 15
Major operating controls and their functions (continued) How to fix the USB cable ⑭ Power cord inlet [AC IN] Connect the included power cord to this inlet. Fix the USB cable with the included power cord clamp passed through the slot on either the top or bottom of the ⑮...
User/Host management It is necessary to register users who directly operate this product, or PCs (hosts) that access through the network such as LAN. Up to 32 users can be registered. It is possible to register the following for the user information. Item Description User name...
HDD unit Handle the HDD units To install a hard disk drive in the recorder, it is necessary to assemble an HDD unit (encase the hard disk drive in the HDD canister). The HDD unit is designed to easily install/remove the hard disk drive in/from the recorder. Contact your dealer about purchasing, installing, and replacing the hard disk drives.
HDD unit (continued) How to attach the HDD unit holding bracket Angle ① ① Insert the HDD unit holding bracket into the angle hole. ② HDD unit holding bracket ② Fix the HDD unit holding bracket with a screw while sliding it to the left.
HDD unit (continued) Install the HDD unit in recorder Refer to the Installation Guide for installing the HDD unit to this recorder. Remove the HDD units from recorder When removing the HDD unit, it is necessary to perform the removal process in advance. When replacing the HDD unit, it is necessary to perform the removal process/the link process.
Specifications • General Power source: 100 V - 240 V AC 50 Hz/ 60 Hz Power consumption: 145 W (150 VA) Ambient operating temperature: Main body: 0 °C - +45 °C {32 °F - 113 °F} Mouse (included): +5 °C - +40 °C {41 °F - 104 °F} Ambient operating humidity: 5 % to 90 % (non condensing) Maximum operating altitude:...
Page 21
Specifications (continued) • Option (as of October 2023) Additional Camera Kit (license for 32 cameras) WJ-NXE42W (NX410) Additional Camera Kit (license for 32 cameras) WJ-NXE52W (NX510) Additional Camera Kit (license for 64 cameras) WJ-NXE53W (NX510) Secure Communication Kit (license for 1 camera) WJ-NXS01W Secure Communication Kit (license for 4 cameras) WJ-NXS04W...
