i-PRO WJ-NX310K Series Installation Manual

Network disk recorder
Hide thumbs Also See for WJ-NX310K Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Installation Guide
Network Disk Recorder
WJ-NX310K Series
Model No.
For professional use only
WJ-NX310K Series refer to WJ-NX310K, WJ-NX310KG and WJ-NX310KGV.
The Operating Instructions and Important Information is on our support website
(https://i-pro.com/global/en/surveillance/documentation_database).
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
The model number is abbreviated in some descriptions in this manual.

Advertisement

Table of Contents
loading

Related Manuals for i-PRO WJ-NX310K Series

Summary of Contents for i-PRO WJ-NX310K Series

  • Page 1 Network Disk Recorder WJ-NX310K Series Model No. For professional use only WJ-NX310K Series refer to WJ-NX310K, WJ-NX310KG and WJ-NX310KGV. The Operating Instructions and Important Information is on our support website (https://i-pro.com/global/en/surveillance/documentation_database). Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.

  • Page 2: Table Of Contents

    Contents Introduction ..........................4 Standard accessories ................................4 About the user manuals ................................4 About the symbol mark ................................4 About Additional Camera Kit (option) ............................5 About Secure Communication Kit (option)..........................5 When the product is accessible from the Internet ........................5 Open Source Software ................................
  • Page 3 Contents (continued) Important Information Refer to the Important Information on our support website for the following items. Safety Information · Important safety information Introduction · Preface · System requirements for a PC · Network security, etc. Precautions · Precautions for use Major operating controls ·...

  • Page 4: Introduction

    PC, and "hard disk drive" referred to as HDD depending on where it is written. "NX310" in this manual refer to WJ-NX310K Series respectively. The external appearance in the document may differ from the actual product within no influence range on operation due to improvement of the product.

  • Page 5: About Additional Camera Kit (Option)

    "Click here for more information on the OSS used in this product." and then read the information displayed. • Please note that i-PRO Co., Ltd. shall not respond to any inquiries regarding the source code. AVC Patent Portfolio License...

  • Page 6: Precautions For Installation

    • Clear a space of more than 5 cm {2 inches} from both i-PRO Co., Ltd. assumes no responsibility for injuries sides, the top, and the rear of the product. Do not block or property damage resulting from failures arising out...

  • Page 7: Basic Operations

    Introduction (continued) Basic operations This section explains operation of a mouse and the soft keyboard, and setting screen only. The recorder can be operated using the mouse (included) connected to the mouse connection port on the front side of the recorder.

  • Page 8: Setup Menu

    Introduction (continued) Setup menu Configuration of each setting item in the setup menu should be completed in advance to use this recorder. The setup menu has the following levels for the setting items. On "Easy Start", the minimum settings required to operate the recorder will be performed, but other settings will remain default.

  • Page 9: Operations Flow

    Operations flow • Professional knowledge on and experience in network and the HDD are required for the settings and changes of the operation. • The main monitor is required for the settings. * The settings can be done through a web browser on the PC (Refer to the Operating Instructions).
  • Page 10 Operations flow (continued) Initialize the hard disk drives that were installed at step 2. Initialize the hard disk drive ☞ Page 27 Register the date & time and cameras on "Easy Start". Configure the minimum settings When it is not necessary to change other default settings, it [Easy Start] is possible to start operations.

  • Page 11: Obtain The License (Registration Key)

    1 Obtain the license (Registration Key) Keep the "Activation Key Card" included in the recorder nearby. Obtain the "Registration Key" of the recorder by following the instructions on the included Activation Key Card. To increase number of connected cameras, get the registration key number of the additional camera license according to the Additional Camera Kit (option).

  • Page 12: Installation Of The Hard Disk Drive

    2 Installation of the hard disk drive Before installing the hard disk drives, turn off the power of the recorder first. When replacing the hard disk drives, the procedures will be same as those of installation. When installing or replacing the hard disk drives for playback use only (hard disk drives that are formerly used for recording), perform the link process.

  • Page 13: (When Replacing The Hard Disk Drives)

    2 Installation of the hard disk drive (continued) Step 3 Step 4 Install the HDD in the bracket Install the HDD bracket Fix the HDD using 4 HDD fixing screws (included) and 4 Install the HDD bracket and tighten the HDD bracket screws Spring washers (included).

  • Page 14: Rack Mounting

    3 Rack mounting Install the recorder in an EIA standard 19-inch rack (Depth: Step 3 550 mm or more). Install the recorder in the rack by using four rack mounting screws. Note: Secure using the rack mounting screws (×4). • Use four M5 × 12 mm screws (locally procured) to install Tightening torque: 2.0 N·m ~ 2.4 N·m {1.48 lbf·ft ~ 1.78 lbf·ft} the recorder in a rack.

  • Page 15: Connections

    4 Connections Connection of cameras and a mouse Up to 32 cameras can be connected to the Camera/PC port of the recorder via a PoE Network switch (locally procured). Use a Ethernet cable (straight) to connect the recorder and the PoE Network switch. Connect the included mouse to the mouse connection port on the front side of the recorder.

  • Page 16: Connection Of Monitors

    4 Connections (continued) Connection of monitors The main monitor (HDMI), which displays live images as well as playback images and setting menus, is connected to the HDMI (AV MAIN) terminal using an HDMI cable (locally procured). The sub monitor (HDMI) is also connected to the HDMI (VIDEO SUB) terminal using an HDMI cable (locally procured).

  • Page 17: Connection Of A Pc

    4 Connections (continued) Connection of a PC When PC and the camera are in the same network When the PC and the camera are configured on the same network, connect the PC to the Camera/PC port via a PoE hub. Recorder IP address: 192.168.0.x (except 0, 1, 250 and 255)
  • Page 18 4 Connections (continued) When PC and the camera are in different networks When the PC and the camera are configured on different networks, connect the PC to the PC port via a switching hub. Recorder [Camera/PC port] IP address: 192.168.1.x IP address: 192.168.0.250 (except 0, 1, 250 and 255) Subnet mask: 255.255.255.0...

  • Page 19: How To Use The Terminals Of The Alarm/Control

    4 Connections (continued) How to use the terminals of the ALARM/CONTROL The ALARM/CONTROL connectors on the back is used when connecting an external device such as a sensor that outputs alarm signals or when installing an external alarm device such as a buzzer or a lamp outside. Insert the unarmored cable into the terminal plug and then mount it on the ALARM/CONTROL connector on the back.
  • Page 20 4 Connections (continued) Pin No. Signal Operation Remarks Alarm input 1 Alarm input 2 Alarm input 3 Alarm input 4 Event action will be performed according to the Non-voltage make contact input Alarm input 5 settings +3.3 V pull-up Approx. 23 kΩ Alarm input 6 Alarm input 7 Alarm input 8...
  • Page 21 4 Connections (continued) Alarm connection example When a signal output from the other device is supplied to the terminal B1~B9 (Alarm input 1 to 9), recording or an alarm action will be performed in accordance with the settings. When an alarm device such as a buzzer, a lamp, etc., is installed outside, con- nect them to the terminal B10 (Alarm output).

  • Page 22: Time And Polarities Of The Alarm/Control Connector

    4 Connections (continued) Time and polarities of the ALARM/CONTROL connector Terminal name Active Time Remarks Alarm input 100 ms or more N.O.: L active N.C.: H active Alarm reset input 100 ms or more L active Emergency recording input 100 ms or more L active External recording mode 100 ms or more...

  • Page 23: Turn On The Devices

    5 Turn on the devices Turn on the power of the recorder Turn on the power of the recorder. First, turn on the power of the monitor. When using the recorder for the first time, register the license for the recorder. (☞ Page 25) How to fix the power cord Step 1 Connect the included power cord to the power cord...
  • Page 24 5 Turn on the devices (continued) Step 2 Step 3 The administration registration window is displayed on If the license for the recorder has not been registered the main monitor. yet, the message asking you to register the "Registration Key" will be displayed after the completion of the system check and the administrator registration.

  • Page 25: Register The License (Registration Key)

    6 Register the license (Registration Key) When using the recorder for the first time, using the secure function, or increasing the number of the cameras to be connected, it is necessary to register the recorder license (Registration Key). Important: • In the following cases, the recorder must be rebooted by clicking the [Restart] button. The licenses will not be effective until the recorder is rebooted.
  • Page 26 6 Register the license (Registration Key) (continued) Step 7 Enter the "Registration key" for the recorder in the "Registration key" field using the on-screen keyboard, and click the [Registration] button. → The "Registration key input" window will return to the registration window.

  • Page 27: Initialize The Hard Disk Drive

    7 Initialize the hard disk drive Open the "HDD management" page from the setting screen and format the HDD. Step 1 Step 4 Click the [HDD management] button of the setup Click "Execute" next to "Format HDD" on the "HDD menu - the "Advanced setup"...

  • Page 28: Troubleshooting

    Troubleshooting Before asking for repairs, check the symptoms with the following table. Contact your dealer if a problem cannot be solved even after checking and trying the solution in the table or a problem is not described below. Symptom Cause/solution Ref.
  • Page 29 Troubleshooting (continued) Symptom Cause/solution Ref. pages The "Thermal error" indication • The ambient operating temperature is 0 °C to +45 °C. The – is displayed on the main "Thermal error" is displayed based on the internal thermal monitor. information of the HDD. If the "Thermal error" indication is displayed, it is recommended to change the installation environment so that the ambient temperature is maintained at approx.
  • Page 30 Authorised Representative in EU: i-PRO EMEA B.V. Laarderhoogtweg 25, 1101 EB i-PRO Co., Ltd. Amsterdam, Netherlands Tokyo, Japan i-PRO EMEA B.V. UK Branch 1010 Cambourne Business Park, https://www.i-pro.com/ Cambridgeshire CB23 6DP © i-PRO Co., Ltd. 2023 Ls1023-1103 Printed in China...
