Flexible static memory controller (FSMC)
16-bit NAND Flash
FSMC signal name
A[17]
A[16]
D[15:0]
NCE[x]
NOE(= NRE)
NWE
NWAIT/INT[3:2]
There is no theoretical capacity limitation as the FSMC can manage as many address
cycles as needed.
16-bit PC Card
FSMC signal name
A[10:0]
NIORD
NIOWR
NREG
D[15:0]
NCE4_1
NCE4_2
NOE
NWE
NWAIT
INTR
1586/1749

Table 248. 16-bit NAND Flash

I/O
O
O
I/O
O
O
O
I
I/O
O Address bus
O Output enable for I/O space
O Write enable for I/O space
O Register signal indicating if access is in Common or Attribute space
I/O Bidirectional databus
O Chip select 1
O Chip select 2 (indicates if access is 16-bit or 8-bit)
O Output enable in Common and in Attribute space
O Write enable in Common and in Attribute space
PC Card wait input signal to the FSMC (memory signal name
I
IORDY)
PC Card interrupt to the FSMC (only for PC Cards that can generate
I
an interrupt)
PC Card presence detection. Active high. If an access is performed
CD I to the PC Card banks while CD is low, an AHB error is generated.
Refer to
NAND Flash address latch enable (ALE) signal
NAND Flash command latch enable (CLE) signal
16-bit multiplexed, bidirectional address/data bus
Chip select, x = 2, 3
Output enable (memory signal name: read enable, NRE)
Write enable
NAND Flash ready/busy input signal to the FSMC
