Flexible memory controller (FMC)

Figure 475. Synchronous multiplexed write mode waveforms - PSRAM (CRAM)

HCLK
CLK
A[25:16]
NEx
Hi-Z
NOE
NWE
NADV
NWAIT
(WAITCFG = 0)
A/D[15:0]
1 clock 1 clock
1. The memory must issue NWAIT signal one cycle in advance, accordingly WAITCFG must be programmed
to 0.
2. Byte Lane (NBL) outputs are not shown, they are held low while NEx is active.
Bit No.
31-20
20
19
18-16
15
14
13
12
1638/1749
Memory transaction = burst of 2 half words
addr[25:16]
(DATLAT + 2)
CLK cycles
Addr[15:0]

Table 287. FMC_BCRx bit fields

Bit name
Reserved
0x000
CCLKEN
As needed
CBURSTRW
0x1
CPSIZE
As needed (0x1 for CRAM 1.5)
ASYNCWAIT
0x0
EXTMOD
0x0
to be set to 1 if the memory supports this feature, to be kept at 0
WAITEN
otherwise.
WREN
0x1
RM0090 Rev 18
inserted wait state
data
Value to set
RM0090
data
ai14731f
