Table 24. Interrupt Mode 2 Operation
Memory Mode
Z80 Mode
ADL Mode
UM007714-0908
ADL MADL
Bit Bit Operation
0 0
Read the LSB of the interrupt vector placed on the data bus,
D[7:0], by the interrupting peripheral.
IEF1 ← 0
•
IEF2 ← 0
•
•
The starting Program Counter is effectively {MBASE,
PC[15:0]}.
•
Push the 2-byte return address PC[15:0] onto the
({MBASE,SPS}) stack.
•
The ADL mode bit remains cleared to 0.
•
The interrupt vector address is located at { MBASE,
I[7:0], D[7:0] }.
PC[15:0] ← ( { MBASE, I[7:0], D[7:0] } ).
•
•
The ending Program Counter is effectively {MBASE,
PC[15:0]}
•
The interrupt service routine must end with RETI.
1 0
Read the LSB of the interrupt vector placed on the data bus,
D[7:0], by the interrupting peripheral.
IEF1 ← 0
•
IEF2 ← 0
•
•
The starting Program Counter is PC[23:0].
•
Push the 3-byte return address, PC[23:0], onto the SPL
stack.
•
The ADL mode bit remains set to 1.
•
The interrupt vector address is located at { I[15:0], D[7:0]
}.
PC[23:0] ← ( {I[15:0], D[7:0] } ).
•
•
The ending Program Counter is { PC[23:0] }.
•
The interrupt service routine must end with RETI.
®
