ZiLOG eZ80 User Manual page 252

LEA IX/Y, IY+d
Load Effective Address
Operation
IX/Y ← IY+d
Description
The CPU adds the contents of the IY register to the two's-complement displacement d and
writes the sum to the specified multibyte Index Register, IX or IY.
Condition Bits Affected
None.
Attributes
Mnemonic Operand
LEA
LEA.S
LEA.L
LEA
LEA.S
LEA.L
UM007714-0908
ADL Mode Cycle Opcode (hex)
IX,IY+d X
IX,IY+d 1
IX,IY+d 0
IY,IY+d X
IY,IY+d 1
IY,IY+d 0
3
ED, 54, dd
4
52, ED, 54, dd
4
49, ED, 54, dd
3
ED, 33, dd
4
52, ED, 33, dd
4
49, ED, 33, dd
®
eZ80 CPU
User Manual
243
CPU Instruction Set
