The memory mode can be changed by adding a suffix to a CALL, JP, RST, or RET,
RETI, or, RETN instruction. Tables 14 through 20 describe how each of these 4 instruc-
tions function. The individual instructions may perform additional operations that are not
described here. These tables are focused only on the memory mode switching. For more
detailed information, see
Table 14. CALL Mmn Instruction
User Code
CALL mn
CALL Mmn 1
CALL.IS
mn
CALL.IS
mn
UM007714-0908
®
eZ80 CPU Instruction Set Description
ADL Assembled
Mode Code
0
CALL mn
assembles to
CD nn mm
CALL Mmn
assembles to
CD nn mm MM
0
CALL.SIS mn
assembles to
40 CD nn mm
1
CALL.LIS mn
assembles to
49 CD nn mm
Operation
The starting program counter is {MBASE,
PC[15:0]}. Push the 2-byte return address
PC[15:0] onto the SPS stack. The ADL mode bit
remains cleared to 0. Load 2-byte logical address
{mm, nn} from the instruction into PC[15:0]. The
ending program counter is {MBASE,
PC[15:0]} = {MBASE, mm, nn}.
The starting program counter is PC[23:0]. Push the
3-byte return address PC[23:0] onto the SPL
stack. The ADL mode bit remains set to 1. Load 3-
byte address {MM, mm, nn} from the instruction
into PC[23:0]. The ending program counter is
PC[23:0] = {MM, mm, nn}.
The starting program counter is {MBASE,
PC[15:0]}. Push the 2-byte logical return address
PC[15:0] onto the {MBASE, SPS} stack. Push a
02h byte onto the SPL stack, indicating a call from
Z80 mode, (because ADL = 0). The ADL mode bit
remains cleared to 0. Load 2-byte logical address
{mm, nn} from the instruction into PC[15:0]. The
ending program counter is {MBASE, PC[15:0]}.
The starting program counter is PC[23:0]. Push the
2 LS bytes of the return address, PC[15:0], onto
the {MBASE, SPS} stack. Push the MS byte of the
return address, PC[23:16], onto the SPL stack.
Push a 03h byte onto the SPL stack, indicating a
call from ADL mode (because ADL = 1). Reset the
ADL mode bit to 0. Load 2-byte logical address
{mm, nn} from the instruction into PC[15:0]. The
ending program counter is {MBASE,
PC[15:0]} = {MBASE, mm, nn}.
®
eZ80 CPU
User Manual
on page 77.
