Immediate Addressing
The memory operands immediately follows the instruction. The memory operand can be
8, 16, or 24 bits, depending on the instruction and the memory mode in use. Immediate
addressing is displayed in
UM007714-0908
BC (16- or 24-Bit)
DE (16- or 24-Bit)
HL (16- or 24-Bit)
Figure 6. Register Indirect Addressing
Figure
Op Code
nn
Op Code
nn
mm
Op Code
nn
mm
MM
Figure 7. Immediate Addressing
Operand
Memory Space
7.
8-bit operand
16-bit operand
24-bit operand
®
