In applications that run Z80 mode code exclusively, the interrupt vector address is
{MBASE, I[7:1], IVECT[8:0]}. A 16-bit word is fetched from the interrupt vector address
and loaded into the lower two bytes of the Program Counter, PC[15:0].
In mixed-memory or ADL mode applications, the interrupt vector address is {I[15:1],
IVECT[8:0]}. A 24-bit word is fetched from the interrupt vector address and loaded into
the Program Counter, PC[23:0].
Note: eZ80190, eZ80L92, and eZ80F92/F93 devices only support an 8-bit I register, an 8-bit
IVECT, and a 16-bit word fetch in ADL modes. Refer to the eZ80
product specifications for information on product specific vectored interrupt modes.
Table 25. Vectored Interrupt Operation
Memory Mode
Z80 Mode
ADL Mode
UM007714-0908
ADL MADL
Bit Bit Operation
0 0
Read the LSB of the interrupt vector placed on the internal
vectored interrupt bus, IVECT [8:0], by the interrupting
peripheral.
IEF1 ← 0
•
IEF2 ← 0
•
•
The starting Program Counter is effectively {MBASE,
PC[15:0]}.
•
Push the 2-byte return address PC[15:0] onto the
({MBASE,SPS}) stack.
•
The ADL mode bit remains cleared to 0.
•
The interrupt vector address is located at { MBASE,
I[7:1], IVECT[8:0] }.
PC[15:0] ← ( { MBASE, I[7:1], IVECT[8:0] } ).
•
•
The ending Program Counter is effectively {MBASE,
PC[15:0]}
•
The interrupt service routine must end with RETI.
1 0
Read the LSB of the interrupt vector placed on the internal
vectored interrupt bus, IVECT [8:0], by the interrupting
peripheral.
IEF1 ← 0
•
IEF2 ← 0
•
•
The starting Program Counter is PC[23:0].
•
Push the 3-byte return address, PC[23:0], onto the SPL
stack.
•
The ADL mode bit remains set to 1.
•
The interrupt vector address is located at { I[15:1],
IVECT[8:0] }.
PC[23:0] ← ( { I[15:1], IVECT[8:0] } ).
•
•
The ending Program Counter is { PC[23:0] }.
•
The interrupt service routine must end with RETI.
®
