Bit b, r
Bit Test
Operation
←
Z ~ r
Description
The r operand is any of the 8-bit CPU registers A, B, C, D, E, H, or L. This instruction
tests bit b in the specified register and sets the 0 Flag (Z) if the bit is 0. The Z Flag is reset
if bit b of register r is a one.
Condition Bits Affected
S
Z
H
P/V
N
C
Attributes
Mnemonic
BIT
= binary code
jj
identifies the bit tested and assembled into the object code, as indicated in
bbb
UM007714-0908
[ b ]
Undefined.
Set if bit b is 0; reset otherwise.
Set.
Undefined.
Reset.
Not affected.
Operand ADL Mode
X
b,r
; where
01 bbb rrr
Cycle Opcode (hex)
2
CB, jj
identifies the A, B, C, D, E, H, or L register and
rrr
®
