EX (SP), IX/Y
Exchange Stack and Index Register
Operation
if ADL = 1 {
(SPL) ↔ IX/Y[7:0]
(SPL+1) ↔ IX/Y[15:8]
(SPL+2) ↔ IX/Y[23:16]
}
else if ADL = 0 {
SPS ↔ IX/Y[7:0]
(SPS+1) ↔ IX/Y[15:8]
}
Description
The CPU exchanges the contents of the multibyte Index Register, IX or IY, with the mem-
ory location specified by the Stack Pointer (SP). In ADL mode, or when the .L suffix is
employed, SPL is used for SP. In Z80 mode, or when the .S suffix is employed, SPS is
used for SP.
Condition Bits Affected
None.
Attributes
Mnemonic
EX
EX.S
EX.L
EX
EX.S
EX.L
UM007714-0908
Operand ADL Mode
0/1
(SP),IX
1
(SP),IX
0
(SP),IX
0/1
(SP),IY
1
(SP),IY
0
(SP),IY
Cycle Opcode (hex)
6/8
DD, E3
7
52, DD, E3
9
49, DD, E3
6/8
FD, E3
7
52, FD, E3
9
49, FD, E3
®
