LEA IX/Y, IX+d
Load Effective Address
Operation
IX/Y ← IX+d
Description
The CPU adds the contents of the IX register to the signed displacement d and writes the
sum to the specified multibyte Index Register, IX or IY.
Condition Bits Affected
None.
Attributes
Mnemonic Operand
LEA
LEA.S
LEA.L
LEA
LEA.S
LEA.L
UM007714-0908
ADL Mode Cycle Opcode (hex)
IX,IX+d X
IX,IX+d 1
IX,IX+d 0
IY,IX+d X
IY,IX+d 1
IY,IX+d 0
3
ED, 32, dd
4
52, ED, 32, dd
4
49, ED, 32, dd
3
ED, 55, dd
4
52, ED, 55, dd
4
49, ED, 55, dd
®
