LD (IX/Y+d), r
Load Indirect with Offset
Operation
(IX/Y+d) ← r
Description
The r operand is any of the 8-bit CPU registers A, B, C, D, E, H, or L. The CPU writes the
contents of the r register to the memory location specified by the contents of the multibyte
Index Register, IX or IY, offset by the two's-complement displacement d.
Condition Bits Affected
None.
Attributes
Mnemonic Operand
LD
LD.S
LD.L
LD
LD.S
LD.L
identifies the A, B, C, D, E, H, or L register and is assembled into one of the opcodes
jj
indicated in
UM007714-0908
ADL Mode Cycle Opcode (hex)
(IX+d),r X
(IX+d),r 1
(IX+d),r 0
(IY+d),r X
(IY+d),r 1
(IY+d),r 0
Table 66.
4
DD, jj, dd
5
52, DD, jj, dd
5
49, DD, jj, dd
4
FD, jj, dd
5
52, FD, jj, dd
5
49, FD, jj, dd
®
