eZ80Acclaim!™ Development Kit s
Quick Start Guide
Introduction
Congratulations on your smart decision to purchase this eZ80Acclaim!™ Development Kit from ZiLOG .
U se this Quick Start Guide as a handy reference for each of the devices in the eZ80Acclaim!™ family of
microcontrollers. This document g uides the user through:
•
Software installation and online registration
•
Hardware installation and configuration
•
Running sample projects in SRAM o n the eZ80
•
O btaining software updates via the
Kit Contents
eZ80Acclaim!™ Development Kit
• Includes development platform,
development module, and 9V AC power
supply with adapters
ZPAKII Debug Interface Module
• Includes ZDI TIM, 40-connector ribbon
cable, DB9 serial I/O cable, ID10 to DB9
cable, and 5V AC power supply with
adapters
Ethernet hub
• Includes two AC power supplies (one
international)
S ystem Requirements
Recommended Configuration
• PC running MS Windows 98SE/WinNT 4.0–SP6/
Win2000–SP3/WinXP–SP1
• Pentium III/500 MHz processor
• 128 MB RAM
• 40 MB hard disk space
• Super VGA video adapter
• CD-ROM drive
• Ethernet port
• One or more RS-232 communications ports
• Internet browser (Internet Explorer or Netscape)
Install the Software
Follow these steps to install ZDS II with the A NSI C-Compiler .
1. Insert the ZDS II CD into your computer ' s CD-ROM drive. DemoShield launches automatically .
Note:
The DemoShield installer a utomatically launches each time the CD-ROM is inserted into the
drive. The i nstaller may not l aunch automatically on some W indows 2000 systems. If this issue
ZiLOG W orldwide Headquarters • 532 Race Street • San Jose, CA 95126
T elephone: 408.558.8500 • Fax: 408.558.8300 •
®
Development Platform
ZiLOG website.
CD-ROM
• ZDS II for the eZ80Acclaim!™ with ANSI C-Compiler
• ZP AK II
• Sample software projects
Minimum Configuration
• PC running MS Windows 98SE/WinNT 4.0–SP6/
Win2000–SP3/WinXP–SP1
• Pentium II/233 MHz processor
• 96 MB RAM
• 25 MB hard disk space
• Super VGA video adapter
• CD-ROM drive
• Ethernet port
• One or more RS-232 communications ports
• Internet browser (Internet Explorer or Netscape)
QS002005-0703
www .zilog.com
Advertisement
Related Manuals for ZiLOG eZ80Acclaim!
Summary of Contents for ZiLOG eZ80Acclaim!
- Page 1 QS002005-0703 Introduction Congratulations on your smart decision to purchase this eZ80Acclaim!™ Development Kit from ZiLOG . U se this Quick Start Guide as a handy reference for each of the devices in the eZ80Acclaim!™ family of microcontrollers. This document g uides the user through: •...
- Page 2 Page 2 should occur , please visit the Microsoft support W eb site at h ttp://support.microsoft.com/ default.aspx?scid=KB;en-us;q155217 2. ZiLOG recommends registering your new ZDS II software. Registering ZDS II is quick and easy! Please see the online registration page on the ZiLOG website and enter the requested information.
- Page 3 eZ80Acclaim!™ Development Kits Quick Start Guide Page 3 ® 1. Each eZ80Acclaim!™ Development Module mounts onto connectors JP1 and JP2 of the eZ80 Development Platform. Ensure that the Module is properly seated by matching pin 1 of the JP1/JP2 ® connectors on the Module to pin 1 of JP1/JP2 on the eZ80 Development Platform.
- Page 4 eZ80Acclaim!™ Development Kits Quick Start Guide Page 4 1. Open the Windows Control Panel and double-click the Network and Internet Connections icon. The Network Connections dialog box appears, as shown in Figure 3. Figure 3. The Network Dialog 2. In the panel labeled LAN or High-Speed Internet, double-click the Local Area Connection icon. The Local Area Connection Status dialog box appears, as shown in Figure 4.
- Page 5 eZ80Acclaim!™ Development Kits Quick Start Guide Page 5 3. In the Local Area Connection Status dialog box, click the Properties button. The Local Area Con- nection Properties dialog box appears, as shown in Figure 5. Figure 5. The Local Area Connection Properties Dialog 4.
- Page 6 eZ80Acclaim!™ Development Kits Quick Start Guide Page 6 5. Enter values for the IP address and subnet mask to match those shown in Figure 6. Leave any remain- ing fields blank. In this example, an IP address of 192.168.1.21 and a subnet mask of 255.255.255.0 are being assigned to the PC.
- Page 7 Pool 4096 8 IP Address: 192.168.1.50 IP Subnet: 192.168.1.0/255.255.255.0 IP Gateway: 192.168.1.254 netstart exiting, stack extent 379/2048 ZPAKII version y.y Copyright © 2001-2002 ZiLOG, Inc. All Rights Reserved. ZPAKII Console version 1.5 Type 'H' for help ZPAKII:> Note:...
- Page 8 1. Launch ZDS II by navigating from the Start menu to Programs → ZiLOG ZDS II–eZ80_<Version> → ZDS II–eZ80_<Version>. 2. From the File menu in ZDS II, choose Open Project, and navigate to the following file path: c:\Program Files\ZiLOG\ZDSIIeZ80_<Version>\samples\eZ80Acclaim!<Processor...
- Page 9 Related Documents The documents listed in Tables 2 and 3 apply to the eZ80F92 and eZ80F91 microcontroller devices, mem- bers of the eZ80Acclaim!™ product family. Each document in Table 2 is valid for ZiLOG part numbers eZ80F92 and eZ80F93. Table 2. eZ80F92 Documentation eZ80Acclaim!™...
- Page 10 The documents listed in Table 4 apply to all eZ80 devices. ® Table 5. eZ80 Documentation eZ80 CPU User Manual UM0077 ZiLOG Developer Studio—eZ80 User Manual UM0123 ZPAK II Product User Guide PUG0015 eZ80 C-Compiler User Manual UM0055 eZ80 Connectivity: PPP Operation Application Note...
- Page 11 Document Disclaimer ZiLOG is a registered trademark of ZiLOG Inc. in the United States and in other countries. All other products and/or service names mentioned herein may be trademarks of the companies with which they are associated. ©2003 by ZiLOG, Inc. All rights reserved. Information in this publication concerning the devices, applications, or technology described is intended to suggest possible uses and may be superseded.
