ADC HL, SP
ADD with Carry
Operation
HL ← HL+SP+C
Description
The Stack Pointer and the Carry Flag (C in the F register) are added to the contents of the
HL register. The result is stored in the HL register. In ADL mode, or when the .L suffix is
employed, SPL is used for SP. In Z80 mode, or when the .S suffix is employed, SPS is
used for SP.
Condition Bits Affected
S
Z
H
P/V
N
C
Attributes
Mnemonic
ADC
ADC.S
ADC.L
UM007714-0908
Set if result is negative; reset otherwise.
Set if result is 0; reset otherwise.
Set if carry from bit 11; reset otherwise.
Set if overflow; reset otherwise.
Reset.
Set if carry from MSB; reset otherwise.
Operand ADL Mode
HL,SP X
HL,SP 1
HL,SP 0
Cycle Opcode (hex)
2
ED, 7A
3
52, ED, 7A
3
49, ED, 7A
®
