INIMR
Input from I/O and Increment with Repeat
Operation
repeat {
(HL) ← ({UU, 00h, C})
B ← B – 1
C ← C+1
HL ← HL+1
} while B ≠ 0
Description
The CPU places the contents of register C onto the lower byte of the address bus,
ADDR[7:0], and places a 0 onto the High byte of the address bus, ADDR[15:8]. The
upper byte of the address bus, ADDR[23:16] is undefined for I/O addresses. The CPU
reads the byte located at I/O address {UU,
places the contents of HL onto the address bus and writes the byte to the memory address
specified by the HL register. The B register decrements. The C and HL registers incre-
ment. Next, the CPU sets the Z Flag to 1 if the B register decrements to 0. The instruction
repeats until the B register equals 0.
Condition Bits Affected
S
Z
H
P/V
N
C
Attributes
Mnemonic Operand
INIMR
INIMR.S
INIMR.L
UM007714-0908
Not affected.
Set if B – 1 = 0; reset otherwise.
Not affected.
Not affected.
Set if msb of data is a logical 1; reset otherwise.
Not affected.
ADL Mode Cycle
— X
— 1
— 0
, C} into CPU memory. The CPU next
00h
Opcode (hex)
2 + 3 * B ED, 92
3 + 3 * B 52, ED, 92
3 + 3 * B 49, ED, 92
®
eZ80 CPU
User Manual
176
CPU Instruction Set
