LD (IX/Y+d), IX/Y
Load Indirect with Offset
Operation
(IX/Y+d) ← IX/Y
Description
The CPU writes the contents of the Index Register, IX or IY, to the memory location spec-
ified by the contents of the multibyte Index Register, IX or IY, offset by the two's-comple-
ment displacement d.
Condition Bits Affected
None.
Attributes
Mnemonic
LD
LD.S
LD.L
LD
LD.S
LD.L
LD
LD.S
LD.L
LD
LD.S
LD.L
UM007714-0908
Operand ADL Mode
(IX+d),IX 0/1
(IX+d),IX 1
(IX+d),IX 0
(IX+d),IY 0/1
(IX+d),IY 1
(IX+d),IY 0
(IY+d),IX 0/1
(IY+d),IX 1
(IY+d),IX 0
(IY+d),IY 0/1
(IY+d),IY 1
(IY+d),IY 0
Cycle Opcode (hex)
5/6
DD, 3F, dd
6
52, DD, 3F, dd
7
49, DD, 3F, dd
5/6
DD, 3E, dd
6
52, DD, 3E, dd
7
49, DD, 3E, dd
5/6
FD, 3E, dd
6
52, FD, 3E, dd
7
49, FD, 3E, dd
5/6
FD, 3F, dd
6
52, FD, 3F, dd
7
49, FD, 3F, dd
®
