Gemini VII

Match Transducers

Use this option to zero and match the selected transducers to the main manifold transducer.
A sample or Po tube must be installed on each selected port before clicking Start.

Sample Servo

Ensure the pressure transducer has been calibrated before performing this procedure.
Go to Unit [n] > Unit Configuration and view the calibration information. Contact your
service representative if calibration dates are not listed.
Use to calibrate the servo valve to the sample pressure transducer.
1. Select Unit [n] > Calibration > Sample Servo.
2. Click Start. The window closes when the calibration is complete.
