Gemini VII
Field or Button
Pressures button
239-42828-01 - Dec 2012
Click to enter a range of pressure points or to modify table values for
pressure points.
If Use calculation assignments is not selected on the Analysis
Conditions window, the isotherm is interpolated to these pressure points.
The interpolated values are used in the BET (or Langmuir) calculations.
If Use calculation assignments is selected, collected data are used.
• Use pressure range option- select and enter the pressure range to be
used in the text boxes if not using the Interpolate pressures table.
• Interpolate pressures option- select to indicate if the system should
use the table or entered data.
• Insert Predefined button - click to insert a predefined (default) set of
points into the report. This button does not display for the Langmuir
report. Interpolate pressures checkbox must be selected to enable this
button.
Description (continued)
Report Options Files
5-25
