Freundlich Report Options - Micromeritics Gemini VII 2390a Operator's Manual

Gemini VII

Freundlich Report Options

The Freundlich Isotherm is an empirical isotherm used to model low-pressure adsorption data. It can
also be applied to model some micropore isotherms. In the Selected Reports list box, highlight
Freundlich, then click Edit.
Field or Button
Specify monolayer
capacity checkbox
Absolute pressure
range text boxes
Tabular Report
checkbox
Overlay Samples
checkbox
Transform plot
checkbox
239-42828-01 - Dec 2012
Select and enter the monolayer capacity of the sample.
Enter a pressure range when calculation assignments are not used.
Refer to
BET/Langmuir Surface Area Report
Plots the log(P) vs log(Q) in a straight line.
• X-axis - The X-axis field shows the absolute pressure.
• Y-axis - The Y-axis field shows the quantity of gas adsorbed.
Description
Options, page 5-24.
Report Options Files
5-27
