Unit Configuration

Unit Configuration
Unit [n] > Unit Configuration
Use to display hardware/software configurations, calibrations and gas selections of the connected
analyzer.
Field or Button

Configuration
group box
Software Versions
group box
Last Measured Po
Volume
Correction text box
Change IP button
Restore Factory
Defaults button
Cancel button
OK button
6-16
Displays the IP address used by the analysis program and the serial number
of the selected analyzer.
Displays the software versions of the MIC BIOS, controller and analysis
program.
Displays the value for the last measured saturation pressure.
Displays the volume correction of the attached analyzer. If a different value
is entered in this field, it is stored with sample data at the start of an
analysis. The value in this field is used in a calculated free space.
Click to display the Unit IP Setup window. Shows the IP address and
Subnet mask assigned during installation. Do not edit these fields unless
instructed by a Micromeritics service representative.
Deletes all stored analysis data and resets instrument parameters to factory
defaults. It does not affect sample and parameter files.
Refer to
Common Fields and Buttons - Unit Menu
Description
Options, page 6-2.
