Start Po Measurement - Micromeritics Gemini VII 2390a Operator's Manual

Start Po Measurement

Start Po Measurement
Use to measure the saturation pressure.
Not displayed for
Model 2390a
Analyzer Model
Model 2390a
Models 2390p and
2390t
The window closes at the end of the measurement. The value obtained is stored and recorded on the
Unit Configuration window as the most recently measured Po and is available for subsequent sample
analyses. The Po option is selected from the Analysis Conditions tab by clicking the Po and T button.
6-6
Measure the Po only in the Sample tube. Ensure a sample tube with no
filler rod is attached to the sample port then click Start to begin the
measurement.
A Po tube is installed on the Model 2390p and 2390t. Measure the Po in
the Po tube or in the Sample tube. Ensure a sample tube with no filler rod
is attached to the sample port, then click Start to begin the measurement.
Description
239-42828-01 - Dec 2012
Gemini VII
