Micromeritics Gemini VII 2390a Operator's Manual page 171

Gemini VII
Port Activity
window
Status
window
Field or Button
View dropdown
Edit button
Clear button
Density text field
Mass text field
239-42828-01 - Dec 2012
• Operation - displays the current mode of the operation.
• Instrument Log - displays a list of recent analyses, calibrations, and
error or messages. Refer to
• Instrument Schematic - displays a schematic of the analyzer. Refer to
Schematic, page 6-12.
Show Instrument
Click to edit information in the sample information file.
Click to clear all fields on the window.
Use to modify the sample mass density.
Use to modify the sample mass weight. If the field is disabled, click Edit
then click the Enter option in the Mass group box on the Sample
Description tab.
Description
Log, page 6-15.
Show Instrument
Start Analysis
6-3
