Micromeritics TriStar II 3020 Service Manual

Hide thumbs Also See for TriStar II 3020:
Table of Contents

Advertisement

Quick Links

TriStar II 3020
Analyzer
Service Manual
July 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TriStar II 3020 and is the answer not in the manual?

Questions and answers

Related Manuals for Micromeritics TriStar II 3020

Summary of Contents for Micromeritics TriStar II 3020

  • Page 1 TriStar II 3020 Analyzer Service Manual July 2009...
  • Page 2 Windows is a registered trademark of Microsoft Corporation. © Micromeritics Instrument Corporation, 2009. All rights reserved.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1. GENERAL INFORMATION Organization of the manual ........... . . 1-1 Using This Manual.
  • Page 4 Table of Contents TriStar II 3020 Service Manual 6. OPERATOR TRAINING 7. MAINTENANCE DOCUMENTS 8. CALIBRATION PROCEDURE MECHANICAL AND ELECTRICAL DRAWINGS Mechanical ..............9-1 Electrical .

  • Page 5: General Information

    Organization of the manual 1. GENERAL INFORMATION This service manual contains information and instructions for providing instrument service on the Micromeritics TriStar II 3020 Analyzer and is intended for use by Micromeritics' factory-trained and supported service personnel. Organization of the manual...

  • Page 6: Using This Manual

    Provides a syllabus for training service personnel. Using This Manual This manual is most efficiently used from the Micromeritics web site. However, it can be downloaded to a portable media device, such as a CD or a USB stick. Jul 09...

  • Page 7: Functional Description

    Overview As the latest addition to the TriStar Analyzer family, the TriStar II 3020 is a fully automated, three-station physisorption instrument that provides high-quality surface area and porosimetry measurements on solid materials by using the gas adsorption technique.

  • Page 8: New Product Features

    TriStar II 3020Service New Product Features Cabinetry & Sample Chamber • The TriStar II 3020 is smaller than the TriStar 3000 due to elimination of the vacuum pump cavity. • The vacuum pump is now located external to the cabinet.

  • Page 9: Instrument Components

    Interior • Printed Circuit Boards (PCBs) • Power Module Cabinetry/Sample Chamber Due to the elimination of the vacuum pump cavity, the redesigned TriStar II 3020 analyzer is significantly smaller than its predecessor. Top Panel Communications status indicator Sample Tubes Door...

  • Page 10: Instrument Back

    Cabinetry/Sample Chamber TriStar II 3020Service Elevator The TriStar II 3020 elevator raises the dewar to the sample tubes. During analysis, it is automatically raised and lowered. The elevator can be manipulated by the user when the system is in manual mode.

  • Page 11: Side Panels

    Oil/ Wet pump Oil-free / Dry Pump A new feature of the TriStar II 3020 is that the vacuum system is outside the instrument cabinet. Wet and dry pumps are available for nitrogen systems, while the krypton option must use a dry pump.

  • Page 12: Interior Modules

    Interior Modules TriStar II 3020Service Interior Modules The analysis module consists of three subassemblies discussed below. Gas entrance manifold Transducer Servo valve Solenoid valves Vacuum pump connector Gas inlet ports Gas Inlet Photo Gas Inlet CAD The Gas Entrance Manifold provides four gas inlet ports, that face the rear of the instrument. The inlets have dust filters (frits) to prevent dirt from gas lines getting into the system.

  • Page 13: Sample Analysis Manifold

    TriStar II 3020 Service Interior Modules local fluctuations of temperature, which would reduce the precision of gas measurements. There is a temperature sensing device (RTD) mounted to the chamber. Sample analysis manifold 10-Torr Transducer (Krypton units only) Dosing volume manifold...

  • Page 14: Schematic Board & Software

    TriStar 3000 and Gemini for analysis and comparison with TriStar II 3020 plots. For more instructions on how to use the software and run the TriStar analyzer, refer to Chapter 3 - Operational Procedures in the Operator’s Manual.

  • Page 15: Printed Circuit Boards (Pcbs)

    TriStar II 3020 Service Printed Circuit Boards (PCBs) Printed Circuit Boards (PCBs) Analysis Transducer Interface PCB Analysis Transducer Interface PBC Transducer Interface CAD Transducer Interface Photo The Analysis Transducer Interface PCB is responsible for controlling most functions throughout the analysis module. This includes actions performed by the gas inlet, dosing, and sample manifolds.

  • Page 16: Dsp-Isa Cpu

    Printed Circuit Boards (PCBs) TriStar II 3020Service The card cage is the main assembly of electrical systems and the connection between those systems and other components inside and outside of the instrument. The card cage is comprised of three boards: Backplane, CPU, and Digital Interface PCBs. DSP-ISA CPU The DSP-ISA CPU PCB provides control of the instrument.

  • Page 17: Power Module

    TriStar II 3020 Service Power Module Power Module Power supply (from interior of instrument) Power switch (from rear of instrument) Power supply (from rear of instrument) The TriStar’s power supply assembly is the same model as used in the SediGraph 5120. The power supply is mounted at the rear of the instrument providing access to the power switch.
  • Page 18 Power Module TriStar II 3020Service 2-12 Jul 09...

  • Page 19: The Analysis Sequence

    TriStar II 3020 Service Analysis Sequence 3. THE ANALYSIS SEQUENCE The analysis sequence describes what is taking place throughout the instrument during an analysis.The instrument schematic, shown below, will be used to show the state of the system components during the various phases of an analysis.

  • Page 20: Analysis Technique

    Servo Analysis Technique The TriStar II 3020 Analyzer uses physical adsorption and capillary condensation principles to obtain information about the surface area and porosity of a solid material. The analytical technique is simple: a sample contained in an evacuated sample tube is cooled (typically) to cryogenic temperature, then is exposed to analysis gas at a series of precisely controlled pressures.

  • Page 21: Analysis Sequence

    TriStar II 3020 Service Analysis Sequence Analysis Sequence 1. Create and save up to three sample files for use during an analysis. 2. Place a plug in any port that is not being used for analysis. 3. Prepare samples to be analyzed. This may include weighing the sample and degassing the sample.
  • Page 22 Analysis Sequence TriStar II 3020 Service 7. The system begins to evacuate the manifold at a rate and time specified in the sample file. 8. All valves close, then the N2 valve opens and the Po tube is filled to the target pressure.
  • Page 23 TriStar II 3020 Service Analysis Sequence 10. A series of manifold dosings and port equilibrations begin to take place on each port to prepare for analysis under cryogenic conditions. Helium warm free space is measured. Then the elevator is raised to measure cold freespace.
  • Page 24 Analysis Sequence TriStar II 3020 Service 11. Helium is evacuated from the samples and the Dewar is lowered if specified in the sample file. 12. Samples are evacuated for the amount of time specified in the sample file. Jul 09...
  • Page 25 TriStar II 3020 Service Analysis Sequence 13. The Po tube is dosed and allowed to equilibrate. 1000.00 14. If the pressure does not change measurably, the Psat measurement is taken. If the pressure changes measurably, another dose may be required.
  • Page 26 Analysis Sequence TriStar II 3020 Service 15. After evacuation, the analysis phase begins. The instrument starts dosing to the set point specified in the sample file and continues until the specified number of data points have been collected. Data points are displayed in a graph as they are collected.

  • Page 27: Preinstallation

    Preinstallation 4. PREINSTALLATION This chapter contains the Preinstallation Instructions and Checklist for the TriStar II 3020. This document helps to ensure that the customer has prepared the laboratory for installation of the instrument and that the supplies, equipment, and personnel are available for installation.
  • Page 28 Preinstallation TriStar II 3020 Service Jul 09...
  • Page 29 5. INSTALLATION Typically, the TriStar analyzers are customer-installed, except for the Confirm version which usually is installed by a qualified Micromeritics service representative. Installation instructions for the TriStar analyzers are located as follows: • TriStar II 3020 Standard Windows version: This is a user-installed product;...
  • Page 30 Installation TriStar II 3020 Service Jul 09...

  • Page 31: Operator Training

    TriStar II 3020 Service Operator Training 6. OPERATOR TRAINING The Operator Training Checklist is used in conjunction with the operator’s manual and soft- ware to train the person(s) who will be operating the analyzer. Click below to access the Operator Training Checklist.
  • Page 32 Operator Training TriStar II 3020 Service Jul 09...

  • Page 33: Maintenance Documents

    TriStar II 3020 Service Maintenance Documents 7. MAINTENANCE DOCUMENTS The documents listed below are included in Service PM kits, which may be purchased by the user for proper maintenance of his analyzer. Use of these PM plans also help to prolong the life of the analyzer.
  • Page 34 Maintenance Documents TriStar II 3020 Service Jul 09...

  • Page 35: Calibration Procedure

    Calibration Procedure 8. CALIBRATION PROCEDURE This chapter contains the calibration and test procedure used in Micromeritics’ Final Assem- bly Department. It is provided as a reference so that you will be familiar with the calibration procedures and instrument tests that are performed on the instrument during manufacture.
  • Page 36 Calibration Procedure TriStar II 3020 Service Jul 09...

  • Page 37: Mechanical And Electrical Drawings

    Mechanical 9. MECHANICAL AND ELECTRICAL DRAWINGS This section contains mechanical and electrical drawings for the TriStar II 3020. These draw- ings show assemblies in great detail. Some parts listed in these prints may be available only as an assembly or in a kit. Do not provide copies of these drawings to a customer.
  • Page 38 Electrical TriStar II 3020 Service Jul 09...

  • Page 39: Service Parts

    TriStar II 3020 Service Service Parts 10. SERVICE PARTS This section contains a list of approved repair parts for this instrument. The items with an asterisk (*) are included in the Service Parts Kit, P/N: 302-33680-00. Part Number Description 003-17642-011*...
  • Page 40 Service Parts TriStar II 3020 Service Part Number Description 004-25466-00* O-ring, -010 70 Dura Buna-N 004-25468-01* O-ring, -007 70 Dura Buna-N 004-25471-00* O-ring, -018 70 Dura Buna-N 004-25583-01* Nut, Swaging 1/8 Brass 004-25583-10 Plug, 1/8 Gas Port 004-25626-07 Flex Tube, 3/4 OD x 20 Lg, NW-16, NW-40...
  • Page 41 TriStar II 3020 Service Service Parts Part Number Description 300-60800-00 Cable, Servo Valve 300-63805-00 Cable, BP Power to Elevator 302-17701-011 Backplane 302-17702-011 Digital Interface 302-17703-011 Analysis Module 302-33680-00 3020 Repair Parts Kit 302-46000-04 TriStar 3020 Service Agreement 04 302-46000-05 TriStar 3020 Service Agreement 05...
  • Page 42 Service Parts TriStar II 3020 Service 10-4 Jul 09...

  • Page 43: Software

    Software 11. SOFTWARE A demo version of the software for is available for either the standard version or the Confirm version of the TriStar II 3020 system. Double-click the demo software version you wish to view. • TriStar II 3020 standard software •...

  • Page 45: Operator's Manual

    TriStar II 3020 Service Operator’s Manual 12. OPERATOR’S MANUAL A printed operator’s manual is shipped with every Gemini analyzer. Analyzers operated in a Windows environment also have an electronic copy accessible from the Help menu. Listed below are the operator manuals available for the Gemini II 2390 series analyzers. Click the document you wish to view: •...

  • Page 47: Service Training

    TriStar II 3020 Service Service Training 13. SERVICE TRAINING Service Training is provided to service personnel so that they can become familiar with the TriStar system. Click Service Training below to view a syllabus of the training class. • Service Training...
  • Page 48 Service Training TriStar II 3020 Service 13-2 Jul 09...
