Gemini VII
If overlaying this type of
report... (continued)
• BET Surface Area
• Langmuir Surface Area
• Freundlich
• Temkin
• t-Plot
• Alpha-S
• f-Ratio
• BJH Adsorption
• BJH Desorption
• Dollimore-Heal
Adsorption
• Dollimore-Heal
Desorption
• MP-Method
3. From the Report Options tab, click the Overlays button.
239-42828-01 - Dec 2012
a.) In the Selected Reports list box, highlight one of the report
options shown on the left and click Edit.
b.) On the Report Options window, select the Overlay samples
checkbox for the Transform plot and/or the Isotherm plot.
Verify other fields. Click OK to return to the Report Options
tab.
c.) Continue with Step 3.
a.) In the Selected Reports list box, highlight one of the report
options shown on the left and click Edit.
b.) Select the report variable from the Select Reports group box
and click Edit.
c.) Click the dropdown arrow on the Overlay field and select the
Samples option. Verify other fields. Click OK to return to the
Report Options window.
d.) Click OK again to return to the Report Options tab.
e.) Continue with Step 3.
Generating Graph Overlays
Then..
3-37
