Installing the Software
a.) In the Step 2 group box, enter the serial number for each analyzer to be attached to this
computer. The analyzer's serial number label is located near the power switch.
b.) Click Next
9. On the Ethernet Ports screen, select one option from the following
If...
the configured port is listed Select the port then click Next to proceed to the next step.
the configured port is not
listed
4-6
.
Click Specify.
On the Specify Ethernet Port screen, enter the remaining portion of
the IP address in the enabled fields then click Next.
table:
Then...
