5 Smart VacPrep Diagnostics
Schedule Diagnostics Fields and Buttons Table
Field or Button
Available Tests drop-
down list
Cancel
Intervention Required
OK
Start Test Sequence if
Instrument is Idle Any
Time Between
Test Frequency
Test Sequence
5 - 2
Description
Select one or more tests to run unattended. Select the test and click the
Insert button for the test to display in the Test Sequence box.
Discards any changes or cancels the current process.
Check this option if any test requiring operator intervention should be
skipped if the operator does not respond within the specified time.
Saves and closes the active window.
Enter a From and To time for an unattended test to begin if the instrument
is idle at any time during the entered time frame.
Select how often the test is to run unattended.
Provides the test file identification and estimated run time. A check mark
in the Intervention Required column indicates that operator intervention is
required. Click Delete to remove the selected test or Clear to clear the
entire table of all entries. To add a test to the test sequence, highlight a
row in the Test Sequence box, select a test from the Available Tests list
and click Insert. The new test will be inserted above the highlighted row.
Select a row and click Delete to remove the test from the sequence.
Select Clear to remove all entries from the Test Sequence box.
