Preparing for Analysis

6. Select the Show graphic checkbox to insert a graphic in the report header. Use the Browse button
to locate a .BMP or a .EMF file. Specify the graphic size in the Height and Width text fields.
Deselect this option to omit a report graphic.
7. The Selected Reports list box displays the reports that may be generated.
a.) Select the checkbox to the left of the report to include in this file. A selected box displays a
checkmark in the box.
b.) To specify report options, highlight the report in the Selected Reports list box and click
Edit. Makes changes as necessary. Click OK.
8. Click Save, then click Close. The file saves with a .RPO file extension.
Preparing for Analysis
The following table outlines the tasks to properly prepare for an analysis and the location of the task
procedure. It is recommended to perform the tasks in the following order:
Task
Clean the sample tube
Create the sample file
Weigh the sample
Degas the sample
Load sample on sample port
Fill Dewar and check LN2 level
3-16
Name and Location
Cleaning and Labeling Sample
Defining Sample Information
Determining the Sample
Sample, page
Degassing the
Tube, page
Installing the Sample
Installing the Analysis
Tubes, page
3-17
Files, page
3-6
Mass, page
3-18
3-20
3-21
Dewar, page
3-22
239-42828-01 - Dec 2012
Gemini VII
