Common Fields and Buttons - Unit Menu Options

Common Fields and Buttons - Unit Menu Options
The following fields and buttons are common to many of the Unit menu options. References are made
to these fields and buttons throughout this manual.
Field or Button
Browse button
Cancel button
Close button
OK button
Start button

Start Analysis

Unit [n] > Start Analysis
Use to begin an analysis. Select an existing analysis file or create a new one. Then specify analysis
defaults.
6-2
Click to search for a file. Select from a file in the Name column and click
Open or double click the file name in the Name column to open (or
import) the file.
Discards any changes made to the screen or cancels the current process.
Click to close the active window.
Click to save and close the active window.
Click to start the analysis.
Description
239-42828-01 - Dec 2012
Gemini VII
