Gemini VII
Refer to
Enable Manual
Valve State

Show Status

Unit [n] > Show Status
Use to show only the status window of the analyzer.
If multiple instruments are attached to the computer, the status window for each
instrument is displayed in a different color.
The buttons across the bottom of the window are described in
The status window shows the current status for each port. Use this option if:
• there is an automatic operation in progress and the sample file needs to be edited.
• there are multiple units attached to the computer. Select Show Status on each unit menu and have
the status for all units displayed at one time.
239-42828-01 - Dec 2012
Control, page for additional details on this schematic.
6-8
Green indicates an open valve.
Yellow indicates a closed valve.
Description
Control, page 6-8.
Enable Manual
Show Status
6-13
