Specifications For The Smart Vacprep - Micromeritics Gemini VII 2390a Operator's Manual

Related Topics
See "QuickStart Degas Conditions" on page 3 - 2
See "Start Smart VacPrep Degas" on page 3 - 5
See "Set the Voltage for the Smart VacPrep" on the next page
S
PECIFICATIONS FOR THE
The Smart VacPrep degasser has been designed and tested to meet the following specifications:

Specifications for the Smart VacPrep

Specification
Backfill Options
Capacity
Degas Method
Physical Dimensions
Evacuation Period
Evacuation Rate
Heating of Samples
Heating Ramp Rate
Soak Time
Temperature Accuracy
Temperature Control
Temperature Range
Vacuum Control
Windows 7 Professional or higher operating system is recommended for the best user
experience. If the computer is to be connected to a network, a second Ethernet port on the
computer must be used for that purpose.
Smart VacPrep Operator Manual
S V
MART AC
Description
Automatically backfill or wait for user command
6 ports
Heat and vacuum
Height: 69 cm (27 in.)
Width: 53 cm (20.75 in.)
Depth: 44 cm (17 in.)
Weight: 32 kg (70 lbs)
Determined by selected elapsed time or achievement of selected low pres-
sure target
Selectable evacuation rate from 1.0 to 50.0 mmHg/s
Heating mantles
o
Selectable from 0.1 C per minute to 10
Zero to 999 minutes in one minute increments (Zero = Manual Cancel).
Deviation less than ±10
heating mantle
One ramp during evacuation phase, five additional ramps during sub-
sequent phases
o
40 to 450 C in one degree increments
Selectable target pressure controls switchover from restricted to unres-
tricted evacuation.
Computer
Specifications for the Smart VacPrep
P
REP
o
C per minute
o
C at the sensing thermocouple embedded in the
1 - 3
