Generating Graph Overlays
2. Click the Report Options tab at the top of the screen. Refer to the following table for instructions
for the selected report.
Highlight the report to
overlay, then click Edit.
If overlaying this type of
report...
• Isotherm
3-36
a.) In the Selected Reports list box, highlight Isotherm and
click Edit.
b.) On the Isotherm Report Options window, select a plot in
the Selected Reports group box then click the Options
button to the right of the selected plot.
c.) On the Plot Options window, select the Overlay samples
checkbox and verify other fields. Click OK to save and close
the window.
d.) Click OK again on the Isotherm Report Options window to
return to the Report Options tab.
e.) Continue with Step 3.
Then..
